Contents
- Buzzer sounds/Indicator on
- If the outboard motor was submerged
- Emergency gear shifting (DBW types)
This troubleshooting guide is for reference purposes and
supplements the owner's manual that came with your
outboard motor. Always refer to the owner's manual for
clarification and more detail on the processes shown in this
document.
Photos in this guide may not match your actual model.
It is recommended that you download this PDF and store it in
your device.
Web instruction manual, official owner's manual PDF
available at:
https://www.hondappsv.com/
Troubleshooting Guide
BF115JK1, BF135DK1, BF150DK1
EN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Honda BF115JK1
Summary of Contents for Honda BF115JK1
- Page 1 Troubleshooting Guide BF115JK1, BF135DK1, BF150DK1 Contents - Buzzer sounds/Indicator on - If the outboard motor was submerged - Emergency gear shifting (DBW types) This troubleshooting guide is for reference purposes and supplements the owner’s manual that came with your outboard motor. Always refer to the owner’s manual for clarification and more detail on the processes shown in this document.
- Page 2 Buzzer sounds/Indicator on Warning System Activation Engine Oil Pressure Warning System Informs low engine oil pressure with indicator and buzzer sounds. Overheat Warning System Informs engine overheats with indicator and buzzer sounds. Multi-function Display Low oil pressure indicator (red)+Buzzer continuously on Overheat indicator (red)+Buzzer continuously on R1, R2, R3 types Oil pressure indicator (off)+Buzzer continuously on...
- Page 3 Buzzer sounds/Indicator on PGM-FI Warning System Informs PGM-FI malfunction with indicator and buzzer sounds. ACG Warning System Informs AC generator malfunction with indicator and buzzer sounds. Multi-function Display PGM-FI Indicator (red) +Buzzer continuously on (at long intervals) ACG Indicator (red) +Buzzer continuously on (at long intervals) R1, R2, R3 types PGM-FI Indicator (red)
-
Page 4: Warning Level
Buzzer sounds/Indicator on Water Separator Warning System Informs water contamination in the water separator with buzzer sounding (at short intervals). Warning Level Warning level is shown as the warning system activates. ・Warning Level 1: an errors that require special attention ・Warning Level 2: except Level 1 warnings Power reduction This outboard motor is equipped with the power... - Page 5 Buzzer sounds/Indicator on Battey switch notification This function alerts the operator that the battery switch is OFF and must be turned to the ON position. If the battery switch is OFF, a buzzer will sound three times during the following situations. When starting the engine When using the power trim/tilt switch When turning the battery switch OFF while the...
-
Page 6: Overheat Warning System
If the overheat warning system stays activated, stop the engine. Tilt up the outboard motor and check the water intakes for obstructions. If there are no obstructions at the water intakes, return to the closest boat landing and contact your closest authorized Honda outboard motor dealer. - Page 7 Check the battery. If the battery is OK, consult with an authorized Honda outboard motor dealer. PGM-FI warning system Consult with an authorized Honda outboard motor dealer. When the water separator buzzer sounds Check the water separator for water contamination.
- Page 8 A submerged outboard motor must be serviced immediately after it is recovered from the water in order to minimize corrosion. As soon as possible, take the outboard motor to a Honda outboard motor dealer for inspection and service. Step 1 – Cleaning 1. Rinse the outboard...
- Page 9 If the outboard motor was submerged Step 2 – Draining fuel 3. Loosen the vapor separator drain bolt. As the fuel flows out, tilt up the outboard motor. 4. Place a drain pan under the drain tube. Catch the petrol in the drain pan.
- Page 10 If the outboard motor was submerged 6. After draining, tighten the drain bolt. 7. Clamp the drain tube to the clip on the engine.
- Page 11 If the outboard motor was submerged Step 3 – Changing the engine oil Refer to the owner’s manual or https://www.hondappsv.com/...
- Page 12 If the outboard motor was submerged Step 4 – Lubricating the engine cylinder 8. Remove the emergency stop switch clip. Remove the spark plug. 10. Operate the starter to expel water from the engine cylinder.
- Page 13 If the outboard motor was submerged 11. Put a teaspoon of engine oil into each spark plug hole to lubricate the inside of the cylinders. Reinstall the spark plugs. 12. Install the engine cover and lock the latch securely. 13. Attempt to start the engine. If the engine fails to start, remove the spark plugs, clean and dry the electrodes, then reinstall the spark plugs and attempt to start the engine again.
- Page 14 Emergency gear shifting (DBW types) If the gear cannot be shifted, try following procedure to shift the gear manually. If the shift operation can be performed, return to your base at possible engine speed. 1. Set the shift lever or remote control lever to the neutral position.
- Page 15 Emergency gear shifting (DBW types) 4. Shift gear into neutral by moving the shaft. - Grasp the shaft of the inserted Phillips screwdriver close to the shift pivot. Operate in a stable posture that makes it easy to apply force. 5.
