- Page 1 AES-8i/09 INSTRUCTION MANUAL FOR USE AND MAINTENANCE STERILIZING AUTOCLAVES Model: AES-8 1/16...
- Page 2 AES-8i/09 It is very important to keep this instruction booklet with the unit in case you need to refer to it. If the appliance is sold or transferred to another person, remember to hand it over with the appliance so that the new owner is familiar with the operation of the appliance and its warnings.
-
Page 3: Table Of Contents
AES-8i/09 12) Do not put your face or hands close to the chamber when lifting the lid after operations are complete; steam will gush out of the chamber. 13) The lid, chamber, gasket, and top casing are extremely hot immediately after the completion of operation. Don’t touch the equipment or you may get burned. -
Page 4: Description
AES-8i/09 DESCRIPTION 1.- Safety valve. It unloads the pressure of the autoclave in case of failure in the temperature regulation or by pressure exceeding. 2.- Microprocessor controller for time and temperature (see specific instructions below). 3.- Main switch. When pressed, it activates all the circuits of the autoclave and, at the same time, it lights up. -
Page 5: Technical Specifications
AES-8i/09 TECHNICAL SPECIFICATIONS Apparatus: Autoclave steam sterilization. Air purge: Automatic, controlled by the microprocessor. Maximum pressure: 1,5 bar. Voltage: 230 V Frequency: 50/60 Hz Consume: 1000 W Temperature: adjustable up to 127 ºC Time: adjustable from 0 to 500 hours CHARACTERISTICS - AISI 304 stainless steel outer case, with protection lid painted with epoxy resin - Pressure vessel tank and lid of 18/12 stainless steel... -
Page 6: Connection To The Mains
AES-8i/09 CONNECTION TO THE MAINS There is a characteristics plate at the rear of the apparatus, this indicates the power and voltage. Check that the electrical installation meets the characteristics plate. The plug of the apparatus is “SCHUKO” with central or lateral ground connection. For safety reasons this apparatus must be grounded START UP INSTRUCTIONS PRESSURE VESSEL OPENING AND LOCKING... -
Page 7: Microprocessor's Description
AES-8i/09 MICROPROCESSOR’S DESCRIPTION 1.- TEMPERATURE’S DISPLAY: 3 digits display of 7 segments of 12mm. for the visualisation of the temperature of the different messages and values of the edition and configuration variables. 2.- RUN INDICATOR PILOT: it will light up when the controller will be executing the program. -
Page 8: Operation Modes
AES-8i/09 6.- “START/STOP” KEY: key to start or to stop the execution program. It is, also, to leave the edition of the orders or variables of configuration without keeping the modified value. 7.- UP KEY: key to increase the values of the variables of edition and configuration. 8.- DOWN KEY: key to decrease the values of the variables of edition and configuration. - Page 9 AES-8i/09 Other temperature programs: press the thermometer key to enter in the edition of the temperature. The pilot “thermometer” will start blinking and the display will show the selected value. To modify it, press the “UP” and “DOWN” keys until the wanted value in grades appear.
- Page 10 AES-8i/09 not be visualised. If any of these two values is modified and kept, it will be operative during this run because. When completed the regulator recovers the programmed value STERILIZATION Set the three position valve (4) on CLOSED position. Press main switch (3) and it will light up, and the microprocessor display will show the temperature of the equipment.
-
Page 11: Precautions Before Opening The Lid
AES-8i/09 PRECAUTIONS BEFORE OPENING THE LID If you have been sterilizing LÍQUIDOS (liquids), you must let the autoclave cool down until the manometer indicates 0, and that the temperature is below 100ºC. If you find difficulties in opening the lid, you must put the three-position valve to STEAM position to break the vacuum inside the tank. -
Page 12: Cleaning And Maintenance
AES-8i/09 CLEANING AND MAINTENANCE Check regularly the steal of the lid, if you find any cuts or lacerations it must be replaced. To clean the inside of the autoclave, turn the three-position valve (4) to the DRAIN position, connect a hose to the drain terminal (7) and place a container. Clean with soapy water. -
Page 13: Declaration Of Conformity
AES-8i/09 DECLARATION OF CONFORMITY 13/16... - Page 14 AES-8i/09 14/16...
- Page 15 AES-8i/09 15/16...
- Page 16 AES-8i/09 16/16...
