Summary of Contents for Siemens Sliding Gantry
- Page 1 Sliding Gantry Instructions for Use – SOMATOM Scope...
- Page 3 Sliding Gantry Instructions for Use – SOMATOM Scope...
- Page 4 Legend Indicates a hint Is used to provide information on how to avoid operating errors or information emphasizing important details Indicates the solution of a problem Is used to provide troubleshooting information or answers to frequently asked questions Indicates a list item Indicates a prerequisite Is used for a condition that has to be fulfilled before starting a particular operation Indicates a one-step operation...
- Page 5 Indicates a hazardous situation which, if not avoided, could result in death or serious injury. WARNING consists of the following elements: ◾ Information about the nature of a hazardous situation ◾ Consequences of not avoiding a hazardous situation ◾ Methods of avoiding a hazardous situation Sliding Gantry Print No. HC-C2-X05.610.73.01.02...
- Page 6 Legend SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
-
Page 7: Table Of Contents
Table of contents 1 Introduction Compatible systems Applicability 2 Safety Safety information Gantry movements Measurement related safety information 3 Description Purpose of the Sliding Gantry System overview Components 3.3.1 Gantry display 3.3.2 Gantry operator panels 3.3.3 Auxiliary column 3.3.4 Rail system CT mode restrictions 3.4.1... - Page 8 Table of contents 6 Location of labels Sliding Gantry Control cabinet Index SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
-
Page 9: Introduction
Introduction This document provides detailed information about your accessories and system components. Compatible systems The Sliding Gantry option is available for the following CT system: ◾ SOMATOM Scope (Power configuration) Applicability This document is valid only in conjunction with the Instructions for Use of the corresponding SOMATOM CT system. - Page 10 Introduction SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
-
Page 11: Safety
Note, that the emergency STOP switches at the gantry work only in conjunction with the gantry and are not related to any other equipment, e.g., the patient table. When the gantry is in the park position, all emergency stop switches are disabled. Sliding Gantry Print No. HC-C2-X05.610.73.01.02... - Page 12 Safety CAUTION Tripping because of uneven floor! Risk of injury of user. ◆ When crossing the gantry rails, take care not to injure yourself. CAUTION Pinching of fingers in cableguide! Risk of injury to the patient and personnel. ◆...
-
Page 13: Gantry Movements
CAUTION Collision with cable guide! Injury to the patient or personnel. ◆ Avoid collision of the gantry and the patient, or collision of other objects in the examination room with the gantry. Sliding Gantry Print No. HC-C2-X05.610.73.01.02... - Page 14 Safety CAUTION Collision between gantry and bolus injector! Pulled out catheter. ◆ Avoid patient collision with the gantry, or collision of other objects in the examination room with the gantry. Collision protection Movement of the gantry stops when the bumper at the gantry front or at the gantry back is obstructed, for example by the foot of the operator.
- Page 15 CAUTION Table not in CT position! Injury to the patient or personnel. ◆ Avoid collision of the gantry and the patient, or collision of other objects in the examination room with the gantry. Sliding Gantry Print No. HC-C2-X05.610.73.01.02...
-
Page 16: Measurement Related Safety Information
Safety CAUTION Sideways motion of table in gantry! Injury to the patient or personnel. ◆ Move the table sideways with care. CAUTION Incorrect positioning of the patient! Injury to the patient or personnel. ◆ Ensure that the patient is correctly positioned. Measurement related safety information ... - Page 17 Safety Positioning aids CT positioning aids are not included in the delivery of sliding gantry systems. The accessories used with the patient table must meet CT requirements with respect to artifacts and absorption. CAUTION Image artifacts! X-ray not, or only partially, usable.
- Page 18 Safety CAUTION Wrong scan position after CARE Vision or manual table motion! Incorrect diagnosis resulting from incorrect positioning of the tomograms. ◆ Note, that manual table movements during a CARE Vision examination are not registered by the system. SOMATOM Scope | Instructions for Use Print No.
-
Page 19: Description
Sliding Gantry. Purpose of the Sliding Gantry The Sliding Gantry is available as an option and allows the operation of a CT scanner in conjunction with one or two separate patient tables. These patient tables can be part of a completely independent medical system. -
Page 20: Components
Description (1) Gantry display (2) CT auxiliary column (3) Gantry operator panel (4) Bumper for collision protection (5) Rail system Components The following elements of the Sliding Gantry option have specific functions: ◾ Gantry display ◾ Gantry operator panels ... -
Page 21: Gantry Display
The relative gantry position is also displayed on the topogram subtask card of your software. The patient table height indicator has no significance here as well. (1) Gantry position (2) Table height (no significance) Sliding Gantry Print No. HC-C2-X05.610.73.01.02... -
Page 22: Gantry Operator Panels
Description Gantry operator panels 3.3.2 Due to the separation of the gantry and the patient table, the table movement keys on the gantry control panel work differently. The keys for vertical table movement are nonfunctional. The keys for horizontal table movement are used to move the gantry along the patient table. -
Page 23: Rail System
The rail system is covered by a cover strip and lateral covers (the lateral covers may not be visible if covered by flooring). Never cross the rail system cover with a trolley if the diameter of its wheels is smaller than 50 mm. Sliding Gantry Print No. HC-C2-X05.610.73.01.02... -
Page 24: Ct Mode Restrictions
Description CT mode restrictions Because of the moving range of the Sliding Gantry and the moving speed limitations due to the stopping distance of the gantry, the CT mode is subject to the following restrictions: ◾ Intercom communication may be restricted as the distance between patient table and gantry increases. -
Page 25: Measurement
Autorange scan is restricted to either horizontal movements or gantry tilt movements. ◾ Only rapid image reconstruction is possible with CARE Vision. ◾ Isocenter adaption is not possible as the table cannot be automatically moved vertically by the CT system. Sliding Gantry Print No. HC-C2-X05.610.73.01.02... - Page 26 Description SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
-
Page 27: Operation
(1) Sliding Gantry front (2) Sliding Gantry movement away from the patient table (3) Sliding Gantry movement towards the patient table ✓ Stop the patient table before you position the patient. -
Page 28: Operating The Sliding Gantry
4.2.1 Moving the Sliding Gantry The following section describes all operations using the front position of the Sliding Gantry. The handling refers to the gantry operation and uses the front gantry operator panels. SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02... -
Page 29: Performing The Tests
In case of malfunction of the gantry movement keys, the rotary switch at the cable column can be used. Moving the Sliding Gantry towards the patient table Check the status lamps at the auxiliary column. Press the patient table movement key to move the gantry towards the patient table. -
Page 30: Performing The Quality Test
Operation Performing the quality test 4.3.1 To ensure a consistently high image quality, you must perform quality measurements regularly. A phantom set is used to perform quality measurements. You position these phantoms on the patient table prior to these tests. The quality test must be performed with the patient table facing the gantry front. -
Page 31: Performing The System Constancy Test
Siemens Med Service Software window. ◆ Follow detailed instructions, see SOMATOM Instructions for Use. Cleaning and disinfecting Clean and disinfect the Sliding Gantry and the rail system in accordance with the cleaning instructions for corresponding accessories. ◆... - Page 32 Operation SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
-
Page 33: Technical Specifications
(4) Minimum patient table height above floor The technical specifications of the patient table in instructions for use of your CT system do not apply to the table used with the Sliding Gantry option. Sliding Gantry Print No. HC-C2-X05.610.73.01.02... -
Page 34: Patient Table And Table Top Requirements
Technical specifications Patient table and table top requirements 5.1.1 Minimum distance of the gantry The distance value depends on front and the patient table the patient table height and the gantry tilt. Refer to the table Collision-safe patient table heights . CT value for the covering of the <... - Page 35 Maximum patient table width (mm) for gantry tilt height (mm) gantry tilt 0° gantry tilt gantry tilt -15° gantry tilt gantry tilt -30° relative to iso- +15° +30° center (0°) -100 -120 -140 -160 -180 n.a. -200 n.a. -220 n.a. Sliding Gantry Print No. HC-C2-X05.610.73.01.02...
-
Page 36: Sliding Gantry Specifications
-280 n.a. n.a. n.a. n.a. Sliding Gantry specifications These values are representative for the SOMATOM Scope (power option). Horizontal gantry travel max. 320 cm Examination range depends on your installation Automatic travel speed up to 100 mm/s Remote controlled feed in min. -
Page 37: Location Of Labels
The numbers and parameters on the labels are examples only. Always refer to the original labels, which are located on the CT system and system components. Sliding Gantry Sliding Gantry Print No. HC-C2-X05.610.73.01.02... - Page 38 Location of labels —or— —or— —or— SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
-
Page 39: Control Cabinet
Location of labels (1) Sliding Gantry label The label is located at the rear of the gantry on the lower right side. Control cabinet —or— Sliding Gantry Print No. HC-C2-X05.610.73.01.02... - Page 40 Location of labels (1) System manufacturer’s identification label SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
- Page 41 19 display 21 gantry tilt 22 horizontal zeroing 22 moving away from the patient table 29 moving the Sliding Gantry 28 moving towards the patient table 29 operating 28 operator panels 22 overview 19 patient table collision-safe heights 34...
- Page 42 This page has been intentionally left blank. SOMATOM Scope | Instructions for Use Print No. HC-C2-X05.610.73.01.02...
- Page 44 The original language of this document is English. Siemens Healthcare Legal Manufacturer Headquarters Siemens Healthcare GmbH Siemens Healthcare GmbH Henkestr. 127 Henkestr. 127 91052 Erlangen 91052 Erlangen Germany Germany Phone: +49 9131 84-0 siemens.com/healthcare Print No. HC-C2-X05.610.73.01.02 | © Siemens Healthcare GmbH, 2016 www.siemens.com/healthcare...
