DE-4000
Next-Generation Safety Shutdown
& Control System
Firmware Update
Quick Start Guide
Required Documents
• ST-Link Programming Procedure.pdf *
• MicroSD SOM Update.pdf *
• IP Address Instructions.pdf
• Pinging Instructions.pdf
Required Software*
ST-Link Utility Software v4.6.0
Overview
WARNING! Failure to properly follow these instructions may cause damage to the DE-4000 system.
This quick start guide refers to several documents that will provide step-by-step procedures for programming and downloading
the support files for the DE-4000. See
NOTE: A basic understanding of DE-4000 operation and configuration is required. Reference the
DE-4000 Operation and Configuration
Firmware Update
STEP 1: Download the Required Files
1. Click click the links to download the required PDF documents:
a. ST-Link Programming Procedure.pdf
b. IP Address Instructions.pdf
2. Download ST-Link Utility Software v4.6.0
3. Download the firmware zip file
a. update.atf
b. Controller module firmware: CONTROL_X.X.X.s19
IMPORTANT:
4. Export the DE-4000 system configuration JSON file. Updating the SOM will erase any previous DE-4000
system configuration.
*Required for LEGACY FIRMWARE UPDATE
Required Hardware*
ST-Link Tool – 693225-KT, which includes:
• Programmer (Used with PC)
• Programmer Adapter Board
• Programming Cable (Board to
Adapter)
*Required
for LEGACY FIRMWARE UPDATE only.
Required Documents above.
Manual.
*
*
from GitHub. The zip file contains three files:SOM firmware:
only.
c. MicroSD SOM Update.pdf
d. Pinging Instructions.pdf
c. Terminal module firmware: TERMINAL_X.X.X.s19
*
FORM DE-4000 QSG 05-25
