- Page 1 PA-HD2 User Manual Scan for more information V 1 . 2...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Precautions ................3 Specifications .................. 4 Dimensions ..................5 Performance Graphs ............... 6 Connectors ..................8 Internal Components ..............10 Internal Descriptions ..............11 Have any queries? Our expert engineers are here to help! sales@progressiveautomations.com progressiveautomations.com 1-800-676-6123 P a g e | 2... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS When installing and using your Progressive Automations linear actuator, basic safety precautions should always be followed. Please read all safety precautions thoroughly and be familiar with all functions of the product before use. Apply all other relevant precautions when operating electrical and moving mechanical devices. -
Page 4: Specifications
SPECIFICATIONS RATED LOAD CONFIGURATIONS Rated Load (lbs) 12 VDC Current (A) 24 VDC Current (A) 12 VDC Speed 24 VDC Speed (inch/sec) (inch/sec) Dynamic Static No Load Full Load No Load Full Load No Load Full Load No Load Full Load 15.0 2.63 2.20... -
Page 5: Dimensions
DIMENSIONS Note: All dimensions are listed in inches. DIAGRAM HOLE TO HOLE LENGTH 2” 6” 8” 10” 12” 16” 18” 24” 30” 40” Stroke Length 4" A (Fully Retracted) 9.87 11.87 13.87 15.87 17.87 21.84 25.84 27.84 35.81 41.81 51.81 B (Fully Extended) 13.87 15.87... -
Page 6: Performance Graphs
PERFORMANCE GRAPHS SPEED VS LOAD Current vs. Load: PA-HD2-12VDC High-Load Industrial Actuator 450 lbs 12V 1349 lbs 12V 674 lbs 12V 899 lbs 12V 270 lbs 12V 2023 lbs 12V 1000 1500 2000 Load (lbs) Current vs. Load: PA-HD2-24VDC High-Load Industrial Actuator... - Page 7 CURRENT VS LOAD Speed vs. Load: PA-HD2 High-Load Industrial Actuator 3.00 2.50 2.00 270 lbs 450 lbs 1.50 674 lbs 899 lbs 1.00 1349 lbs 2023 lbs 0.50 0.00 1000 1500 2000 2500 Load (lbs) P a g e | 7...
-
Page 8: Connectors
CONNECTORS Note: Actuators without feedback come with the Motor 2-Pin Connector only. MOTOR - 2-PIN CONNECTOR Pin Location Function Wire Color Wire Gauge Motor + (Extend) 15 AWG Motor - (Retract) Black 15 AWG HALL EFFECT - 4 PIN CONNECTOR Pin Location Function Wire Color... - Page 9 POTENTIOMETER - TINNED LEADS Pin Location Function Wire Color Wire Gauge N/A, Tinned Potentiometer Wiper 22 AWG Leads Potentiometer (5 VDC, 10kΩ) N/A, Tinned Yellow 22 AWG Leads Potentiometer (GND, 0 kΩ) N/A, Tinned White 22 AWG Leads Force Rating Starting Resistance Potentiometer Resolution Maximum Stroke Length...
-
Page 10: Internal Components
INTERNAL COMPONENTS P a g e | 1 0... -
Page 11: Internal Descriptions
INTERNAL DESCRIPTIONS Item Description Item Description Shaft Enclosure Electric Motor Brush Shaft Enclosure Top Gasket Electric Motor Rotor Shaft Top Guide Electric Motor Case and Stator Shaft Inside Gasket Motor Case Top O-Ring Shaft Top Cap Electric Motor Top Bearing Shaft Outside Gasket Electric Motor Spring Washer Shaft Top Cap Screw...
