Summary of Contents for HAWEKA MB
- Page 1 Operating instructions Inclinometer MB Item No. 913 009 084 Optional with inclinometer bracket (electronic steering wheel balance) (Translated from original operating instructions) GEB 001 302 Kokenhorststraße 4 • D-30938 Burgwedel • Tel. +49 5139/8996-0 • info@haweka.com • www.haweka.com...
-
Page 2: Table Of Contents
Replacing the battery ..................12 Conversion table degrees / angular minutes ............13 EU Declaration of Conformity................14 Subject to technical modifications. Version 1.0 / 2025 Figures: HAWEKA GmbH / 30938 Burgwedel Reproduction in any form is not permitted. HAWEKA GmbH... -
Page 3: User Information
Check the inclinometer MB before use! (s. point 5 p. 10) 2. Product description Furthermore, the inclinometer MB is referred to as inclinometer in this description. Intended use The inclinometer is used to record angle values! This device enables determination of the angle of the wishbone or the drive shaft to the horizontal in a motor vehicle. -
Page 4: Description Of Device
Inclinometer MB Description of device LED display (s. page 6 ) ON/OFF Spokes Steering wheel Tara live measure- ment Bluetooth Selection Light Hold Battery condition Direction of inclination Degree display angle Steering wheel measuring point Measuring points on the vehicle ON/OFF button: Keep the ON/OFF button pressed for approx. - Page 5 Inclinometer MB Steering wheel live measurement The steering wheel live measurement can only be started in the overview display (long press of the selection button) with the ON/OFF button. Steering wheel live measurement quit Optional: With an existing Bluetooth connection, the measure- ment value is transferred automatically every 5 sec.
-
Page 6: Using The Different Adapters
Inclinometer MB LED display The LED function is only activated once the inclinometer is rotated by 180°. What is shown in the dis- play is also rotated. This is needed to determine the angle of the wishbones or the drive shafts below the vehicle. - Page 7 Inclinometer MB The cavity adapter: The cavity adapter is specifically designed for measurement on the wishbone. Depending on the vehi- cle type, there are recesses or indentations on the wishbone where this adapter is positioned. The adapter is held on the inclinometer by a magnet and is laterally movable.
- Page 8 Inclinometer MB Crown adapter with magnetic plate: This combination is used for the Mercedes Citan box wagon. For measurement on the front axle, first of all the magnetic plate is positioned on the wishbone, and the inclinometer is then placed onto the four contact points of the magnetic plate with the crown adapter.
-
Page 9: Calibration Of The Inclinometer
Inclinometer MB 4. Calibration of the inclinometer If a deviation of the angle values >0.2° was detected after verification (s. point 5), the device must be recalibrated. Press the buttons -0- and hold them for approx. 3 seconds until the calibration setting is shown in the display. -
Page 10: Checking The Inclinometer
Inclinometer MB 5. Checking the inclinometer The measuring accuracy must be checked once calibration is complete and at regular in- tervals, but in any case if the device fell down or if a temperature difference between the last check and the place of use is larger than 5 °C. -
Page 11: The Steering Wheel Balance
Inclinometer MB 6. The steering wheel balance (optional accessory) Inclinometer bracket Item No. 913 009 085 The inclinometer, in connection with the bracket, forms the electronic steering wheel balance. Observe the correct order -> 1 -> 2 for mounting and dismounting the inclinometer. -
Page 12: Maintenance And Care
Inclinometer MB 7. Maintenance and care The inclinometer is maintenance-free. If required, clean the device with a soft, lint-free cloth. Do not use any solvents for cleaning the inclinometer! Replacing the battery The service life closely depends on the display illumination. -
Page 13: Conversion Table Degrees / Angular Minutes
Inclinometer MB 8. Conversion table degrees / angular minutes Grad = Winkelminuten Grad = Winkelminuten Grad = Winkelminuten Degrees = angular minutes Degrees = angular minutes Degrees = angular minutes 0º20’24” 0º40’12” 0,01° 0º0’36” 0,34° 0,67° 0,02° 0,35° 0,68° 0º1’12”... -
Page 14: Eu Declaration Of Conformity
Inclinometer MB 9. EU Declaration of Conformity HAWEKA GmbH The manufacturer: Kokenhorststrasse 4 D-30938 Burgwedel hereby declares that the below-mentioned product Inclinometer MB complies with the following directives RED Directive 2014/53/EU or standards and regulations of the EMC Directive 2014/30/EU European Union respectively. - Page 16 HAWEKA GmbH Kokenhorststr. 4 30938 Burgwedel / Germany 05139-8996-0 www.haweka.com Info@haweka.com...
