Taipeng TPGAZ94031 Installation Manual

10'x12' rattan gazebo
Hide thumbs

Advertisement

Quick Links

Download this manual
Model #TPGAZ94031
INSTALLATION GUIDE
10'X12' Rattan Gazebo

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPGAZ94031 and is the answer not in the manual?

Questions and answers

Related Manuals for Taipeng TPGAZ94031

Summary of Contents for Taipeng TPGAZ94031

  • Page 1 Model #TPGAZ94031 INSTALLATION GUIDE 10’X12’ Rattan Gazebo...

  • Page 2: Operation

    Operation Fig.1 Fig.1 1.Connect the supporting post (A)With post bottom plate (B)Bolt(AA).
  • Page 3 Operation (continued) Fig.2 C1/D1 C2/D2 Fig.2 C2/D2 C1/D1 E1/E2 E1/E2 C2/D2 C1/D1 2.Connect the crossbar (C1/D1) with the crossbar (C2/D2) with bolts (DD), then, set the U-shaped bracket (G), cornice (E1/E2) in turn on the beams (C1/C2/ D1/D2) using bolts (AA).
  • Page 4 Operation (continued) Fig.3 Fig.3 3.Connect the long right crossbar (C2) and the short left crossbar (D1) to the rack (A) with bolts (BB), then connect the bracket (F) to the supporting post (A) using the Bolts (AA).
  • Page 5 Operation (continued) Fig.4 Fig.4 4.Insert the short bar (H1) into the long top bar (H2).
  • Page 6 Operation (continued) Fig.6 Fig.5 Fig.6 Fig.5 5-1. Connect the short bar (H1) with the bracket using the Bolts (CC). 5-2. Insert the upper long Bar (H2) into the Central Roof Connector (J).
  • Page 7 Operation (continued) Fig.8 Fig.7 Fig.7 Fig.8 I1/I2 C1/D1 C2/D2 6-1. Connect the middle bar (I1/I2) with the U-shaped bracket (G1/G2) with bolts (CC). 6-2. Insert the middle bar (I1/I2) into the Central Roof Connector (J).
  • Page 8 Operation (continued) Fig.9 Fig.9 I1/I2 C2/D2 C1/D1 7.Place the cover (L) on the beam using bolts (AA).
  • Page 9 Operation (continued) Fig.10 Fig.11 Fig.12 Fig.10 Fig.11 Fig.12 I1/I2 8. Place the small canopy (M) on the long top connector pole (H2), the large canopy (N) on the short bar (H1) and the Middle bar (I1/I2).
  • Page 10 Operation (continued) Fig.13 Fig.14 Fig.13 Fig.14 E1/E2 9-1. Fix the racks on the surface with the help of pegs (EE) using a loop. 9-2. Hang the mosquito net (O) and Curtain (P) on the eaves (E1/E2) by the Loops (GG), curtain outside, the mosquito net from the inside.
