- Page 1 79664 BAND SAW INSTRUCTION MANUAL 350W 230V~50Hz SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION WARNING: read all safety warnings and instructions.Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.Save all warnings and instructions for future reference.The term ”power tool” in the warnings refers to your mains-operated (corded) power tool. Work area safety a) Keep work area clean and well lit. - Page 3 SAFETY Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
-
Page 4: Product Description And Specifications
SPECIFICATIONS PRODUCT DESCRIPTION AND SPECIFICATIONS 1.HANDLE 2.TENSIONING KNOB 3.UPPER BLADE PULLEY 4.UPPER DOOR 5.SWITCH 6.LOWER DOOR 7.RIP FENCE 8.RIP FENCE LOCKING LEVER 9.LOWER BLADE PULLEY 10.UPPER DOOR LOCK 11.ADJUSTING HANDLE KNOB 12.COVER PLATE 13.UPPER SAW BLADE GUIDE 14. TABLE 15.LOWER DOOR LOCK 16.CHIP DISCHARGE PORT 17. -
Page 5: Technical Data
SPECIFICATIONS TECHNICAL DATA Rated Voltage 230V Frequency 50Hz Power 350W(S2) No-load speed 900m/min Blade Size 1430mmx10mmx6T Table Size 300x300mm Table tilting range 45~90° Max. cutting thickness 90mm Throat depth 195mm... -
Page 6: Setup And Adjustments
SETUP OPERATING INSTRUCTIONS Setup and adjustments Before commencing any operations, refer to the Setup and Adjustment Manual to make sure that the Band Saw has been Assembled and Setup correctly. WARNING! TO PREVENT ACCIDENTAL STARTING, ENSURE THE BAND SAW IS DISCONNECTED FROM THE POWER SUPPLY BEFORE MAKING ANY ADJUSTMENTS Rip Fence 1 Release the rip fence lever by pulling it... - Page 7 SETUP 3. Secure in position by tightening the blade guard locking knob. Note: Check the setting before each cut and re-adjust if necessary. Tilting the Saw Table 1. Move the upper blade guide to its maximum height. 2. Loosen both the tilt lever and locking knob. 3.
- Page 8 SETUP Using the band saw CAUTION! TO REDUCE THE RISK OF ELECTRIC SHOCK, WE RECOMMEND THE USE OF A RESIDUAL CURRENT DEVICE . CAUTION! AFTER EACH NEW ADJUSTMENT IT IS RECOMMEND A TRIAL CUT IS MADE IN ORDER TO CHECK THE NEW SETTINGS. On/Off...
- Page 9 SETUP Free Hand Cuts One of the most outstanding features of a band saw is the ease with which it allows you to make curved cuts. 1. Lower the blade guide to the work piece. 2. Switch on the saw. 3.
-
Page 10: Changing The Blade
MAINTENENCE MAINTENENCE WARNING! TO PREVENT ACCIDENTAL STARTING, ENSURE THE BAND SAW IS DISCONNECTED FROM THE POWER SUPPLY BEFORE PERFORMING ANY OF THE FOLLOWING OPERATIONS. NOTE: OUR COMPANY WILL NOT BE RESPONSIBLE FOR ANY DAMAGE OR INJURIES CAUSED BY THE REPAIR OF THE TOOL BY AN UNAUTHORISED PERSON OR BY MISHANDLING OF THE TOOL. Cleaning •... -
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Possible Causes • Power cord is not connected Bandsaw not starting • One of the housing doors are not shut completely Premature and excessive • Feed pressure too light tooth wear • Feed pressure too high • Guide hitting teeth alignment Finished surface too rough •... -
Page 12: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79664 band saw Complies with the essential health and safety requirements of the following Directices: EC Council Directive 2006/42/EC Machinery Standards and technical specifications referred to:... - Page 13 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. TolsenWorld SCAN TO VISIT MADE IN CHINA PRODUCT LINK...
