- Page 1 79532 CIRCULAR SAW INSTRUCTION MANUAL 230-240V~50Hz 1300W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ”power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 3 SAFETY turning the power tool on. A wrench or a key before making any adjustments, changing le attached to a rotating part of the power tool accessories, or storing power tools. Such may result in personal injury. preventive safety measures reduce the risk of 15.
-
Page 4: Circular Saw Safety Warnings
SAFETY Circular Saw Safety Warnings 1. DANGER: Keep hands away from cutting area • Kickback is a sudden reaction to a pinched, and the blade. Keep your second hand on bound or misaligned saw blade, causing an auxiliary handle, or motor housing. If both uncontrolled saw to li up and out of the hands are holding the saw, they cannot be cut workpiece toward the operator;... - Page 5 20. Maintain labels and nameplates on the tool. 12. Lower guard should be retracted manually only These carry important safety information. If for special cuts such as "plunge cuts" and unreadable or missing, contact Tolsen Tools for a "compound cuts". Raise lower guard by replacement.
- Page 6 SAFETY 21. Avoid unintentional starting. Prepare to begin loss of control. work before turning on the tool. 26. Verify that there are no utility lines or hardware 22. Do not lay the tool down until it has come to a in or near the workpiece.
-
Page 7: Specifications
SPECIFICATIONS SPECIFICATIONS Electrical Rating 230-240VAC / 50Hz Input Power 1300W No Load Speed : 5000/min Max. Blade Diameter 185mm Arbor Ø16mm 65mm @ 90 Depth of Cut 44mm @ 45 Note: Symbology Double Insulated WARNING mark concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shields Read the manual before set-up and/or use. -
Page 8: Before Use
SET UP SET UP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool off... - Page 9 SET UP Fig. 2 1. Lever of lower guard 10. Outer flange 2. Dust extraction outlet 11. Blade clamp bolt 3. Saw blade 12. Lower guard 4. Auxiliary handle 13. Spindle lock button 5. Angle gauge 14. ON/OFF switch 6. Lock knob for angle adjustment 15.
-
Page 10: Changing The Blade
SET UP Changing the blade WARNING: To prevent serious injury from accidental operation: Release the Switch, turn off the laser and unplug the tool from its electrical outlet before adjusting tool or installing accessories. Bolt Inner flange Outer flange Saw blade Fig. -
Page 11: Depth Adjustment
SET UP Depth adjustment WARNING: To prevent serious injury from accidental operation: Release the Switch, turn off the laser and unplug the tool from its electrical outlet before adjusting tool or installing accessories. 1. Loosen the lock lever for depth adjustment (18). -
Page 12: Switch On And Off
SET UP Switch on and off WARNING: Before engage the ON/OFF switch, check that the saw blade is properly fitted and run smoothly, the blade clamp bolt is well tightened. 1. Connect the plug to the power supply. 2. To switch on the circular saw, press the lock-off... - Page 13 SET UP GENERAL OPERATING INSTRUCTIONS WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Release the Trigger, turn off the laser and unplug the tool from its electrical outlet before adjusting tool or installing accessories. TO PREVENT SERIOUS INJURY FROM FLYING FRAGMENTS: Do not use blades made from high-speed steel, abrasive blades, or metal- or masonry-cutting blades.
-
Page 14: Maintenance And Servicing
MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn off the switch, laser and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use. -
Page 15: Troubleshooting
TROUBLESHOOTING Troubleshooting Problem Possible Causes Likely Solu�ons Tool will not 1. Cord not connected. 1. Check that cord is plugged in. start. 2. No power at outlet. 2. Check power at outlet. If outlet 3. Tool’s thermal reset breaker tripped is unpowered, turn off... -
Page 16: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79532 Circular saw(M1Y-YH19-185) 230-240V~ 50Hz 1300W n0: 5000/min Serial number: N/A Complies with the essential health and safety requirements of the following Directices:... - Page 17 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
