Summary of Contents for TOLSEN TOOLS FORCE XPRESS 79540
- Page 1 79540 RECIPROCATING SAW 230-240V~50/60Hz 710W Original instruction SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Reciprocating Saw Safety Warnings
9. The warnings, precautions, and instructions These carry important safety information. If discussed in this instruction manual cannot unreadable or missing, contact Tolsen Tools for a cover all possible conditions and situations that replacement. may occur. It must be understood by the 4. -
Page 3: Specifications
SPECIFICATIONS SPECIFICATIONS 230-240V/50/60Hz/710W 0-2800/min 20mm Note: Symbology Double Insulated WARNING mark concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shields Read the manual before set-up and/or use. -
Page 4: Before Use
SETUP SETUP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Release the Trigger, make sure the Trigger lock is not engaged and unplug the tool from its electrical outlet before adjusting the tool or installing accessories. -
Page 5: General Cutting
GENERAL OPERATING INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS The Saw features a variable speed Trigger. For increased strokes per minute, squeeze the Switch trigger harder. For decreased strokes per minute, apply less pressure to the Switch trigger. When cutting so er materials, use a faster speed. When cutting harder materials, use a slower speed. General Cutting 1. -
Page 6: Metal Cutting
GENERAL OPERATING INSTRUCTIONS 1. Clearly mark the line of cut. piece, blade or cause injury. 2. From a convenient starting point within the 4. Line of cut shoe rotate tool on Pivot shoe, Wait cutting area, place the tip of the Blade over that for the Saw to reach full speed, then slowly point with the Saw parallel to the line of cut. -
Page 7: Maintenance And Servicing
MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn off the switch and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use. -
Page 8: Troubleshooting
TROUBLESHOOTING Troubleshooting Problem Possible Causes Likely Solu�ons Tool will not 1. Cord not connected. 1. Check that cord is plugged in. start. 2. No power at outlet. 2. Check power at outlet. If outlet is 3. Tool’s thermal reset breaker unpowered, turn off... -
Page 9: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79540 Reciprocating Saw(J1F-GW3-20) 230-240V~,50/60Hz,710W,Class Ⅱ Serial number: N/A Complies with the essential health and safety requirements of the following Directices: EC Machinery Directive 2006/42/EC The EMC Directive 2014/30/EU Standards and technical specifications referred to:... - Page 10 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
