TOLSEN TOOLS FX FORCE XPRESS 79662 Instruction Manual

Scroll saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
79662
SCROLL SAW
INSTRUCTION MANUAL
SAVE THIS MANUAL !
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
S2 30min 90W 230-240V~50Hz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FX FORCE XPRESS 79662 and is the answer not in the manual?

Questions and answers

Related Manuals for TOLSEN TOOLS FX FORCE XPRESS 79662

Summary of Contents for TOLSEN TOOLS FX FORCE XPRESS 79662

  • Page 1 79662 SCROLL SAW INSTRUCTION MANUAL S2 30min 90W 230-240V~50Hz SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.

  • Page 2: Important Safety Information

    SAFETY IMPORTANT SAFETY INFORMATION WARNING: FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS INJURY. 1. READ AND UNDERSTAND the instruction manual before operating this machine. 2. DO NOT OPERATE THIS MACHINE until it is completely assembled and installed according to the instructions. 3.
  • Page 3 SAFETY SCROLL SAW DISCLAIMER Read the entire text of the operating instructions prior to the assembly and operation of the scroll saw. These operating instructions are intended to make it easier for you to get familiar with your saw and utilize its intended use.
  • Page 4 SAFETY GENERAL SAFETY RULES FOR SCROLL SAWS WARNING When using electric tools basic safety precautions should always followed to reduce the risk of fire, electric shock and personal injury. Read all these instructions before attempting to operate this product. Save these instructions for future reference.Keep work area clear.

  • Page 5: Electrical Connection

    SAFETY ELECTRICAL EXTENSION CORDS Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that accept the product's plug.When using a power product at a considerable distance from the power source, use an extension cord heavy enough to carry the current that the product will draw. An undersized extension cord will cause a drop in line voltage, resulting in a loss of power and causing the motor to overheat.
  • Page 6 SAFETY ADDITIONAL SAFETY RUIES FOR SCROLL SAWS •This scroll saw is intended for use in dry conditions, and for indoor use only. •Do not cut pieces of material too small to hold by hand outside the blade guard. •Avoid awkward hand positions where a sudden slip could cause a hand to move into the blade. •Always use the blade guard to avoid possible injury due to blade breakage.

  • Page 7: Specifications

    SPECIFICATIONS TECHNICAL DATA Rated Voltage 230-240V Frequency 50Hz Power 90W(S2 30min) No-load spee 550-1600/min Table size 254x414mm Saw blade length 133mm Max cutting depth 50mm Throat depth 405mm Table tilting range 45-90° Weight Ne 10kgs FUNCTIONS 1. Clamping screw: for fixing and adjusting upper blade support 2.

  • Page 8: Installation

    SETUP INSTALLATION Setting the saw bench Setting the angle scale •Release the lock knob and bring the saw bench To a right angle in relation to the saw blade. •Use a 90°angle to measure the right angle between the blade and the bench. The saw blade should be 90°to the angle.
  • Page 9 SETUP REMOVING AND INSTALLING PIN TYPE BLADES 1. Rotate the blade tension knob anti-clockwise to release blade tension. 2. Remove table insert and remove blade from the inner upper and lower blade holders by pulling forward on blade and then li ing the blade through the access hole in the table. Slight downward pressure against the upper holder may be helpful when removing blade from upper holder.
  • Page 10 SETUP BASIC OPERATIONA scroll saw is fundamentally a "curve cutting tool" but which can also carry out straight and angled edge cuts.Familiarize yourself with the following important points prior to commissioning the saw. •The saw does not automatically cut wood. You must feed the wood against the saw blade manually. •The cutting process occurs while the blade moving.
  • Page 11 MAINTENENCE MAINTENENCE MAINTENANCEA WARNING : In the interests of operational safety, always switch off the saw and remove the cord from power supply before carrying out maintain work. General Re-application of the wax coating on the work table makes feeding the work piece to the blade easier. MOTOR The power cord should be replaced immediately if pulled out, cui or damaged in any other way.

  • Page 12: Troubleshooting Tablea

    TROUBLESHOOTING TROUBLESHOOTING TROUBLESHOOTING TABLEA WARNING : In the interests of operational safety, always switch off the saw and remove the mains plug before carrying out maintenance work. The work bench is not screwed down...

  • Page 13: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79662 scroll saw Complies with the essential health and safety requirements of the following Directices: EC Council Directive 2006/42/EC Machinery Standards and technical specifications referred to:...
  • Page 14 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. TolsenWorld MADE IN CHINA SCAN TO VISIT PRODUCT LINK...
