Cordless Pole Hedge Trimmer INSTRUCTION MANUAL
Taille Haie Sur Perche
FR
Sans-Fil
Akku-Heckenschneider
DE
Tagliasiepi telescopico a
IT
batteria
Accustokheggenschaar
NL
Cortasetos de Extensión
ES
Inalámbrico
Aparador de Cerca Viva a
PT
Bateria
Φορητό κονταροψάλιδο
EL
μπορντούρας
TR
Akülü Yüksek Çit Budama
UN001G
MANUEL D'INSTRUCTIONS
BETRIEBSANLEITUNG
ISTRUZIONI PER L'USO
GEBRUIKSAANWIJZING
MANUAL DE
INSTRUCCIONES
MANUAL DE INSTRUÇÕES
ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ
KULLANMA KILAVUZU
10
22
36
51
66
80
94
108
123

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UN001GZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Makita UN001GZ

Summary of Contents for Makita UN001GZ

  • Page 1 Cordless Pole Hedge Trimmer INSTRUCTION MANUAL Taille Haie Sur Perche MANUEL D’INSTRUCTIONS Sans-Fil Akku-Heckenschneider BETRIEBSANLEITUNG Tagliasiepi telescopico a ISTRUZIONI PER L’USO batteria Accustokheggenschaar GEBRUIKSAANWIJZING Cortasetos de Extensión MANUAL DE Inalámbrico INSTRUCCIONES Aparador de Cerca Viva a MANUAL DE INSTRUÇÕES Bateria Φορητό...
  • Page 2 Fig.1 Fig.2 Fig.4 Fig.3 Fig.5...
  • Page 3 Fig.9 Fig.6 Fig.10 Fig.7 Fig.11 Fig.8...
  • Page 4 Fig.12 Fig.15 Fig.16 Fig.13 Fig.17 Fig.14...
  • Page 5 Fig.18 Fig.22 Fig.19 Fig.23 Fig.24 Fig.20 Fig.25 Fig.21...
  • Page 6 Fig.26 Fig.30 Fig.31 Fig.27 Fig.32 Fig.28 Fig.33 Fig.29...
  • Page 7 Fig.34 Fig.38 Fig.42 Fig.39 Fig.35 Fig.40 Fig.36 Fig.41 Fig.37...
  • Page 8 Fig.42 Fig.46 Fig.43 Fig.47 Fig.44 Fig.48 Fig.45 Fig.49...
  • Page 9 Fig.50...

  • Page 10: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model: UN001G Blade length 600 mm Strokes per minute 2,000 / 3,000 / 4,000 min Cutting blade angle 115° (up 45°, down 70°) Overall length 2,268 mm Rated voltage D.C. 36 V - 40 V max Net weight 4.0 kg 4.7 - 5.9 kg...

  • Page 11: Declarations Of Conformity

    Intended use Sound power level according to Australia NSW Noise Control Regulation. The tool is intended for trimming hedges. Noise The typical A-weighted noise level determined according to EN62841-4-2: Model Sound pressure level Guaranteed Measured sound power sound level power level (dB(A)) Uncertainty (dB(A)) L (dB(A)) Uncertainty K (dB(A)) K (dB(A)) UN001G NOTE: The declared noise emission value(s) has been measured in accordance with a standard test method and...

  • Page 12: Additional Safety Warnings

    hidden in hedges or bushes and can be acciden- DANGER - Keep hands away from blade. tally cut by the blade. Contact with blade will result in serious personal injury. Wear ear protection. Adequate protective equip- Only use with handle and guard properly ment will reduce the risk of hearing loss. assembled to the tool.
  • Page 13 24. Do not use the tool on soft/unstable/slippery Only use the tool for its intended purpose. Do not use the tool for any other purpose. ground or steep inclines. Avoid working on ladders or at heights. Doing otherwise may Switch off the tool and remove the battery cause a risk of falling, resulting in personal injury.
  • Page 14 12. Use the batteries only with the products product. MISUSE or failure to follow the safety specified by Makita. Installing the batteries to rules stated in this instruction manual may cause non-compliant products may result in a fire, exces- serious personal injury.

  • Page 15: Parts Description

    CAUTION: Only use genuine Makita batteries. less tool power. Use of non-genuine Makita batteries, or batteries that Never recharge a fully charged battery car- have been altered, may result in the battery bursting tridge. Overcharging shortens the battery causing fires, personal injury and damage. It will service life.

  • Page 16: Overload Protection

    NOTE: Depending on the conditions of use and the Charge the battery(ies) or replace it/them with ambient temperature, the indication may differ slightly recharged battery(ies). from the actual capacity. Let the machine and battery(ies) cool down. NOTE: The first (far left) indicator lamp will blink when If no improvement can be found by restoring protection the battery protection system works. system, then contact your local Makita Service Center. Tool / battery protection system Power switch action The tool is equipped with tool/battery protection system. This system automatically cuts off power to the motor to WARNING: For your safety, this tool is extend tool and battery life. The tool will automatically equipped with lock-off switch which prevents the stop during operation if the tool or battery is placed tool from unintended starting.

  • Page 17: Electronic Function

    This tool is equipped with an electric brake. If the branches or debris by hand may cause an injury, tool consistently fails to stop the shear blades since the shear blades may move in reaction to quickly after the switch lever is released, have the removing them. tool serviced at Makita Authorized Service Center. • Accidental re-start preventive function This tool has a reverse button to change the direction When you turn on the tool while pulling the switch of shear blades movement. It is only for removing lever, the tool does not start and the caution lamp branches and debris entangled in the tool.
  • Page 18 If the parts other than the shear blades such as the connecting rods are worn out, ask the alignment line. ► Fig.17: 1. Holes 2. Alignment line Makita Authorized Service Centers for parts replacement or repairs. Align the protruding parts on both sides of the shear blades.

  • Page 19: Operation

    NOTICE: Do not cut down dead trees or similar harness included in the tool package, but use the hard objects. Doing so may damage the tool. hanging band recommended by Makita. NOTICE: Do not trim the grass or weeds while If you put on the shoulder harness included in the using the shear blades. The shear blades may tool package and the shoulder harness of the back- become tangled in the grass or weeds.

  • Page 20: Maintenance

    Place the tool upside down, and then remove the burrs from the shear blade with the dressing stone. To maintain product SAFETY and RELIABILITY, ► Fig.47: 1. Dressing stone repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Set the angle of the file to 50°, and grind the lower Centers, always using Makita replacement parts. blade with the file in exactly the three edge directions. Cleaning the tool Return the tool to normal position, and then remove the burrs from the shear blade with the dressing stone.

  • Page 21: Troubleshooting

    Remove the battery and ask your local authorized service center for repair. Remove the battery immediately! OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center.
