MODEL #
FM74003-Q
Questions?
GIVE US
MON-FRI 8:30AM - 5:30PM (PT)
1 /
CALL: 1-888-980-5122
Screwdriver
(Not Included)
(Included)
Allen Wrench
2 - People
EASY
DIFFICULT
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
Advertisement
Related Manuals for Furniture of America FM74003-Q
Summary of Contents for Furniture of America FM74003-Q
- Page 1 MODEL # FM74003-Q Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PT) Screwdriver (Not Included) (Included) Allen Wrench 2 - People EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 6 QUEEN BED PARTS Headboard Left Wing Right Wing Footboard Roll Slats Side Rail 1set 2pcs Vol - Vol + Support Rail Support Leg Remote Control 2pcs 4pcs...
- Page 7 HARDWARE Full-thread bolt Long Bolt Half Moon Washer Ø 5/16"X88mm Ø5/16"x50mm Ø 5/16"X88mm 6pcs 8pcs 8pcs Spring Washer Full-thread bolt Flat Washer Ø5/16-RBW 16mmx13mmx13mm Ø5/16-RBW 8pcs 6pcs 6pcs Open wrench Flat Washer Allen Key (12mm) Ø1/4 8pcs Screw M4x30mm Screw M4x50mm 9pcs 8pcs...
- Page 8 ASSEMBLY INSTRUCTIONS Part 1 x1pc Part 2 x1pc Part 3 x1pc OPENING THE ZIPPER HERE FOR ASSEMBLY. Hardware A x6 pcs Hardware E x6 pcs Hardware F x6 pcs Hardware I x1 pc Part 4 x1pc Part 7 x2pcs Hardware K x6 pcs Hardware G x6 pcs...
- Page 9 ASSEMBLY INSTRUCTIONS Part 2 x1pc Part 3 x1pc Part 4 x1pc Part 6 x2pcs Part 7 x2pcs Hardware B x8 pcs Hardware C x8 pcs Hardware D x8 pcs Hardware H x1 pc Hardware K x2 pcs Hardware G x2 pcs Part 8 x1pc Part 9 x4pcs...
- Page 10 ASSEMBLY INSTRUCTIONS Part 5 x1set Part 8 x1pc Hardware J x3 pcs 5 x1 set Part 5 x1set Part 6 x2pcs Hardware J x6 pcs 5 x1 set...
- Page 11 ASSEMBLY INSTRUCTIONS This product is intended for RESIDENTIAL USE ONLY and not for commercial use.
-
Page 12: Bluetooth Switch
USER The keypad is on the upper right of the electric . (See Figure 1) Figure 1 Bluetooth switch Electric key board 1 / 1... - Page 13 When the Power is turned on, the display shows the ambient temperature and the flame is turned on. Short press the flame button to Color change There are C1-C7 color changes, turn on the flame color change or mode; non-function non-function Long press the timer to turn it on Press timer to select time 1H, 1H, 2H, 3H, 4H, 5H, 6H,...
- Page 14 Technical Specification Product name Electric Supply 120V AC 60Hz Rated power 15W/M long 1 / 1...
- Page 15 Clean the metal trim using a water-dampened soft, clean cloth. DO NOT use brass polish or household cleaners as these products will damage the metal trim. Any electrical repairs of this unit should be carried out by a licensed electrician in accordance with national and local codes.
