VERSION # 24-03-27
1 / 21
MODEL #
FM-BK611
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America FM-BK611
Summary of Contents for Furniture of America FM-BK611
- Page 1 MODEL # FM-BK611 Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 2 / 21...
- Page 3 3 / 21...
- Page 4 4 / 21...
- Page 5 BUNKBED FM-BK611 #1 1pc #2 1pc #3 1pc #4 1pc Lower End Upper End Lower End Upper End Guardrail Guardrail Guardrail Guardrail #5 1pc #6 1pc #7 4pcs #8 4pcs Lower End Upper End Upper/Lower Back/Front Guardrail Guardrail Side Rail...
- Page 6 #17 2pcs #18 1pc #19 1pc #20 1pc Cha Foot Plate Front Board Front Board Cha Foot Plate #21 1pc #24 1pc #22 3pcs #23 3pcs Right Board Left Board Bottom Board Front Board #25 1pc #26 1pc #27 1pc #28 1pc Bottom Board Back Board...
- Page 7 #D 34pcs #A 6pcs #B 20pcs #C 4pcs Bolt Metal Dowel Bolt Half moon Ø1/4" x 1-1/8" Ø3/8" x 3-1/2" Ø1/4" x 3-1/4" Ø1/4" #H 8pcs #E 8pcs #F 2pcs #G 6 SET Bolt Wood Dowel Screw Allen Wrench Ø1/4" x 1" Ø10x40mm Ø1/4"...
- Page 8 Exploded View #19,#22 #23,#24 #20,#22 #23,#25 #21,#22 #23,#26,#29 #30,#31 #32,#33,#34 8 / 21...
- Page 9 CM-BK611 is packed in 3 cases Disignation Part Hardware Carton Lower End Guardrail #1 Upper End Guardrail #2 Lower End Guardrail Upper End Guardrail Lower End Guardrail CM-BK611-1 Upper End Guardrail Upper/Lower Side Rail #A x 6pcs #B x 20pcs Back/Front Guardrail #C x 4pcs #D x 34pcs...
- Page 10 CM-BK611 is packed in 3 cases Disignation Part Hardware Carton Back Board Back Guardrail Cha Foot Plate Cha Foot Plate Cha Foot Plate Cha Foot Plate Cha Foot Plate CM-BK611-3 Cha Foot Plate Front Board Front Board Front Board Bottom Board Bottom Board Bottom Board Back Board...
- Page 11 CM-BK611 is packed in 3 cases Disignation Part Hardware Carton Back Plane Scroll Bar CM-BK611-3 Scroll Bar 11 / 21...
- Page 12 ASSEMBLY INSTRUCTIONS Part #1 x1pc Part #3 x1pc Part #7 x2pcs Hardware #B x8pcs Part #2 x1pc Part #4 x1pc Part #7 x2pcs Part #8 x4pcs Hardware #B x8pcs Hardware #E x8pcs 12 / 21...
- Page 13 ASSEMBLY INSTRUCTIONS Part #12 x2pcs Hardware #G x6pcs Hardware #A x4pcs 13 / 21...
- Page 14 ASSEMBLY INSTRUCTIONS Part #13 x1pc Part #15 x2pcs Part #16 x1pc Part #17 x2pcs Hardware #D x8pcs Part #5 x1pc Hardware #D x6pcs #F #D 14 / 21...
- Page 15 ASSEMBLY INSTRUCTIONS Part #9 x2pcs Part #14 x1pc Part #18 x1pc Hardware #B x2pcs Hardware #C x2pcs Hardware #D x2pcs Hardware #H x8pcs Part #6 x1pc Hardware #A x2pcs Hardware #B x2pcs Hardware #C x2pcs Hardware #D x4pcs Hardware #H x4pcs 15 / 21...
- Page 16 ASSEMBLY INSTRUCTIONS Hardware #D x10pcs Hardware #L x5pcs Hardware #J x10pcs Hardware #M x5pcs Part #19 x1pc Part #20 x1pc Part #21 x1pc Part #22 x2pcs Part #23 x2pcs Part #30 x1pc #23,#32 #19,#20 Part #31 x2pcs #21,#30 Part #32 x2pcs #22,#31 16 / 21...
- Page 17 ASSEMBLY INSTRUCTIONS Part #24 x1pc Part #25 x1pc Part #26 x1pc Part #33 x1pc #24,#25 #26,#33 Part #27 x1pc Part #28 x1pc Part #29 x1pc #27,#28 Part #34 x1pc #29,#34 Hardware #I x8pcs 17 / 21...
- Page 18 ASSEMBLY INSTRUCTIONS Hardware #J x3pcs Hardware #K x1pc Part #36 x1pc Part #37 x1pc Part #38 x1pc Part #39 x1pc #37 #38 Hardware #J x24pcs 18 / 21...
- Page 19 ASSEMBLY INSTRUCTIONS Part #35 x1pc Hardware #I x2pcs #19,#22 #23,#24,#27 #20,#22 #23,#25,#28 #21,#22 #23,#26,#29 #30,#31 #32,#33,#34 19 / 21...
- Page 20 ASSEMBLY INSTRUCTIONS Part #10 x1set Part #11 x1set Hardware #I x56pcs Part #40 x4pcs Hardware #D x4pcs This product is intended for RESIDENTIAL USE ONLY and not for commercial use. 20 / 21...
- Page 21 Objects such as, but not limited to, hanger, hooks, belts, bag, rope strings, etc. should not be hanged or used on or around the bunk bed. Replacement Parts: Replacement parts may be obtained from your Furniture of America dealer. Distributed by: Furniture of America 680 S.
