CT-2002
HYDRAULIC
OPERATION MANUAL
Battery Charger
-
PA24178A01
PA24694A01_00
03/2003
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panduit CT-2002
Summary of Contents for Panduit CT-2002
-
Page 1: Table Of Contents
CT-2002 HYDRAULIC COMPRESSION SYSTEM OPERATION MANUAL SYSTEM SPECIFICATIONS ........................1 CT-2002 SYSTEM ............................2 OPTIONAL ACCESSORIES ........................2 PRECAUTIONS AND GENERAL GUIDELINES ..................2 Hydraulic Compression Tool......................... 2 Estimated Crimping Cycles........................2 DIE SELECTION............................3 INSTALLATION Die Installation............................4 Battery Installation..........................4 TOOL OPERATION............................ -
Page 2: System Specifications
(for product) or five years (for tools) from the date of delivery. Tool warranty is void if PANDUIT tools are modified, altered or misused in any way. Use of PANDUIT tooling with any product other than the specified PANDUIT products for which the tool was designed, constitutes misuse. -
Page 3: Ct-2002 System
1 – CT-CHR25 Battery Charger 1 – CA21414B01 Shoulder Strap 1 – PC2001 Plastic Carrying Case OPTIONAL ACCESSORIES CD-2001 Compression Consult PANDUIT catalog for part numbers and specific die application Dies information. PRECAUTIONS AND GENERAL GUIDELINES HYDRAULIC COMPRESSION TOOL WARNING: DO NOT USE THIS TOOL ON LIVE ELECTRICAL CIRCUITS. -
Page 4: Die Selection
FIG. 1 DIE IDENTIFICATION FOR USE WITH MATCHED CONNECTOR NOTE: DIES ARE DESIGNED TO PRODUCE THE HIGHEST QUALITY CONNECTIONS WHEN USED WITH PANDUIT COMPRESSION CONNECTORS. USE OF ANY OTHER BRAND OF CONNECTORS IS NOT RECOMMENDED WITH CD-2001 DIES. PANDUIT DIE INDEX... -
Page 5: Installation Die Installation
To facilitate support of the tool during operation the shoulder strap can be attached to the compression tool by snapping hook on tool hanging ring. Strap length can be adjusted for individual comfort. Copyright © 2003 Panduit Corp. Page: 4... -
Page 6: Periodic Maintenance
Avoid humidity wherever possible for smooth operation and for the prevention of corrosion. ELECTRICAL GROUP 17301 Ridgeland Ave., Tinley Park, IL 60477-0981 Phone (708) 532-1800 • FAX (708) 532-1811 Copyright © 2003 Panduit Corp. Page: 5 PA24694A01_00 All Rights Reserved... - Page 7 NEVER DISASSEMBLE OR MODIFY THE BATTERY. 4. NEVER DISPOSE OF BATTERY IN FIRE, OR DISPOSE IN GARBAGE. Batteries can be returned to Panduit Tool Division for disposal. Contact Panduit Tool Service at (888) 506-5400, ext. 3255. AVOID DROPPING THE BATTERY CARTRIDGE.
- Page 8 The pattern of LED's that are "on" will indicate how many times the battery has been recharged (see Chart 3). ELECTRICAL GROUP 17301 Ridgeland Ave., Tinley Park, IL 60477-0981 Phone (708) 532-1800 • FAX (708) 532-1811 Copyright © Panduit Corp. Page: 2 PA24198A01_02 All Rights Reserved 3/2003...
- Page 9 • Charging battery models other than Panduit CT-BC25 or CT-NLBC25 may result in personal injury due to exploding battery. Contact Panduit Tool Division at (888) 506-5400, ext. 3255; and ask for a Tool Service Technician, for repair information. The LED indicator on the battery charger changes colors to indicate the status of the recharge cycle. Refer to the label on the charger for specific status color codes.
- Page 10 CAUTION: Be sure to fully recharge the battery when the tool is delivered or after 3 months of storage. ELECTRICAL GROUP 17301 Ridgeland Ave., Tinley Park, IL 60477-0981 Phone (708) 532-1800 • FAX (708) 532-1811 Copyright © 2003 Panduit Corp. Page: 2 PA24178A01_01 All Rights Reserved...
