  • Page 1 MSP-7 Introduction Safety notes Milltronics Description Installing/mounting Motion Sensors MSP-7 Connecting Service and maintenance Operating Instructions Diagnostics and troubleshooting Technical specifications Dimension drawings Technical reference Applications Product documentation and support 7MH7146 (MSP-7) 11/2023 A5E34105798-AC...

  • Page 4: Legal Information

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Table Of Contents

    Table of contents Introduction ............................7 Operating instructions scope ....................7 Purpose of this documentation .................... 7 Designated use ........................7 Checking the consignment ....................8 Security information ......................8 Transportation and storage ....................9 Industrial Use Note ......................9 Notes on warranty ......................
  • Page 6 Table of contents Technical specifications ........................29 Power ..........................29 Output ..........................29 Construction ........................29 Approvals .......................... 29 Operating conditions ......................30 Dimension drawings ..........................31 MSP-7 device dimensions ....................31 Technical reference ..........................33 Principle of operation ......................33 Applications ............................

  • Page 7: Introduction

    Introduction Operating instructions scope These operating instructions cover the installation, operation, and maintenance of the MSP-7 (Motion Sensing Probe). Purpose of this documentation These instructions contain all information required to commission and use the device. Read the instructions carefully prior to installation and commissioning. In order to use the device correctly, first review its principle of operation.

  • Page 8: Checking The Consignment

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to...

  • Page 9: Transportation And Storage

    NOTICE Unauthorized product information or software Use only authorized Siemens websites when accessing any product information or software, including firmware updates, device integration files (EDD, for example), as well as other product documentation. Using unauthorized product information or software could result in a security incident, such as breach of confidentiality, or loss of integrity and availability of the system.

  • Page 10: Notes On Warranty

    The sales contract contains all obligations on the part of Siemens as well as the complete and solely applicable warranty conditions. Any statements regarding device versions described in the manual do not create new warranties or modify the existing warranty.

  • Page 11: Safety Notes

    Safety notes Preconditions for use This device left the factory in good working condition. In order to maintain this status and to ensure safe operation of the device, observe these instructions and all the specifications relevant to safety. Observe the information and symbols on the device. Do not remove any information or symbols from the device.
  • Page 12 Safety notes 2.1 Preconditions for use Symbol Explanation Equipment suitable for direct current Equipment suitable for alternating current Dispose of in an environmentally safe manner, and according to local regulations. The product described in this document is in conformity with the relevant harmonization legislation, and its amendments, of the European Union.

  • Page 13: Improper Device Modifications

    If you need additional information not covered by these instructions, contact your local Siemens office or company representative. Note Operation under special ambient conditions...
  • Page 14 Safety notes 2.2 Requirements for special applications MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 15: Description

    Description MSP-7 (Motion Sensing Probe) detects rotating, reciprocating, or conveying equipment. When connected to a Programmable Logic Controller (PLC), it can warn of malfunction, sending signals to stop or slow down equipment, preventing costly failure or downtime. The single setpoint system suits most industrial applications. An NPN open collector 3-wire output allows for connection to most PLC models and a large dynamic range.
  • Page 16 Description MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 17: Installing/Mounting

    Installing/mounting Note Installation shall only be performed by qualified personnel and in accordance with local governing regulations. Location requirements Avoid strong magnetic fields (50/60 Hz) from nearby equipment, as these can affect performance. The probe design detects a changing magnetic field, typically caused by a ferromagnetic target that disturbs the magnetic field.

  • Page 18: Proper Mounting

    Installing/mounting 4.2 Proper mounting Proper mounting Mount MSP-7 in a non-hazardous area that is clean, dry, and vibration-free, using the mounting flange. The environment must be within the probe's range of ambient temperature and non-corrosive to the probe's body. To prevent damage, ensure that the gap between the probe and target is large enough.

  • Page 19: Wiring

    Installing/mounting 4.3 Disassembly 4.2.2 Wiring Interconnect the probe components via flexible conduit, where possible. This allows for easier removal or calibration of the probe and mounting flange assembly. Disassembly WARNING Incorrect disassembly The following risks may result from incorrect disassembly: - Injury through electric shock - Risk through emerging media when connected to the process - Risk of explosion in hazardous area...
  • Page 20 Installing/mounting 4.3 Disassembly MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 21: Connecting

    Connecting Basic safety notes NOTICE Ambient temperature too high Damage to cable sheath. • At an ambient temperature ≥ 60 °C (140 °F), use heat-resistant cables suitable for an ambient temperature at least 20 °C (36 °F) higher. Note Electromagnetic compatibility (EMC) You can use this device in industrial environments, households and small businesses.

  • Page 22: Interconnection

    Connecting 5.2 Interconnection Interconnection Standard cable length • ½" NPT inlet [1.5 m (5 ft) cable] MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 23: Service And Maintenance

    • Reliability of power supply, lightning protection, and grounds WARNING Impermissible repair of the device • Repair must be carried out by Siemens authorized personnel only. Cleaning If it is necessary to clean the enclosure, do the following: 1. Disconnect the power at the main breaker.

  • Page 24: Ordering Of Spare Parts

    5. Select a spare part and add it to your watch list. The watch list opens. 6. Click "Add to cart of Industry Mall". The Siemens Industry Mall opens and you can order your spare part. MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 25: Return Procedure

    To return a product to Siemens, see Returns to Siemens (www.siemens.com/returns-to- siemens). Contact your Siemens representative to clarify if a product is repairable, and how to return it. They can also help with quick repair processing, a repair cost estimate, or a repair report/cause of failure report.
  • Page 26 Service and maintenance 6.5 Disposal MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 27: Diagnostics And Troubleshooting

    Diagnostics and troubleshooting Troubleshooting If you are having issues with MSP-7, try the following solutions: Note A multimeter is required to perform these diagnostics. CAUTION Hazardous voltage at open device Risk of electric shock when the enclosure is opened or enclosure parts are removed. •...
  • Page 28 Diagnostics and troubleshooting 7.1 Troubleshooting MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 29: Technical Specifications

    • NPN open collector, 2 kΩ pull up to input voltage, 330 Ω impedance, 40 mA max. Construction Enclosure material • Aluminum Enclosure rating • NEMA/Type 4X, 6, IP67 Approvals • Ordinary Locations/General Purpose (Non-Ex), CE, UKCA, RCM, EAC, KC See also Certificates (http://www.siemens.com/processinstrumentation/certificates) MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 30: Operating Conditions

    Technical specifications 8.5 Operating conditions Operating conditions Principle of measurement Magnetic Typical application Monitoring motion in tail pulley, screw flights, bucket elevators Ambient temperature range -40 … +60 °C (-40 … 140 °F) Storage temperature range -40 … +60 °C (-40 … 140 °F) Location Indoor/outdoor Altitude...

  • Page 31: Dimension Drawings

    Dimension drawings MSP-7 device dimensions Dimensions in mm (inch) ① 2" NPSL ② Mounting flange ③ Locknut ④ Probe body ⑤ Gasket ⑥ Cap c/w ½" NPT conduit entrance ⑦ 6 (0.25) ∅ hole for ¼ - 20 nut and bolt or drill and tap, four holes on 114 (4.5) BCD ⑧...
  • Page 32 Dimension drawings 9.1 MSP-7 device dimensions MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 33: Technical Reference

    Technical reference Principle of operation MSP-7 works on the principle of Faraday’s Laws of Electromagnetic Induction. When a ferromagnetic object enters the probe’s permanent magnetic field, it distorts the flux causing it to cut the coil windings and generate a voltage. This voltage is proportional to the following parameters: •...
  • Page 34 Technical reference A.1 Principle of operation Note 25.4 mm = 1 inch and 0.305 m = 1 ft The graph is plotted from tests using four ferrous blocks. These are set equidistantly on a 406 mm (16 inch) diameter circle, on a non-ferrous disc. The physical shape of the ferrous target becomes important at low velocities or large gaps.

  • Page 35: Applications

    Applications Bucket elevators Dimensions in mm (inch) MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 36: Bucket Elevator

    Applications B.2 Bucket elevator Figure A Dimensions in mm (inch) Bucket elevator MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 37: Shafts

    Applications B.3 Shafts Shafts Dimensions in mm (inch) ① Probe ② Probe ③ Key and keyway ④ Shaft 102 (4) ∅ min. ⑤ Added paddle ⑥ Shaft These methods are viable if the speed is such that the blades or key provide the number of pulses required at a minimum velocity of 1.5 m/minute (5 ft/minute).

  • Page 38: Rotating Shaft Of Rotary Feeder

    Applications B.4 Rotating shaft of rotary feeder Rotating shaft of rotary feeder Drive sprocket on rotary feeder MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 39: Belt Conveyors

    Applications B.6 Belt conveyors Belt conveyors Dimensions in mm (inch) ① 50 x 50 x 25 (2 x 2 x 1) ferrous blocks or spoked wheel ② Probe Potential for damage in each application governs the minimum gap allowable. Maximum gap for operation is 102 mm (4 inch), optimum 25 to 50 mm (1 to 2 inch).

  • Page 40: Screw Conveyor Flights

    Applications B.8 Screw conveyor flights Screw conveyor flights End bearing on screw conveyor MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 41: Non-Ferrous Window

    Applications B.10 Non-ferrous window B.10 Non-ferrous window Dimensions in mm (inch) ① 64 (3.5) ∅ clearance hole ② 6 (0.25) ∅ clearance, four holes ③ Conveyor enclosure ④ Probe and mounting flange ⑤ Bracket ⑥ Weld ⑦ Base plate ⑧ Window MSP-7 can be used for screw conveyors with a trough over 3.1 mm (0.125 inch) thick or for high temperature applications.
  • Page 42 Applications B.10 Non-ferrous window MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...

  • Page 43: Product Documentation And Support

    Entering a serial number 1. Open the PIA Life Cycle Portal (https://www.pia-portal.automation.siemens.com). 2. Select the desired language. 3. Enter the serial number of your device. The product documentation relevant for your device is displayed and can be downloaded.

  • Page 44: Technical Support

    In addition to our technical support, Siemens offers comprehensive online services at service & support (http://www.siemens.com/automation/serviceandsupport). Contact If you have further questions about the device, contact your local Siemens representative at Personal Contact (http://www.automation.siemens.com/partner). To find the contact for your product, go to "all products and branches" and select "Products &...

  • Page 45: Index

    Index Applications Installing/mounting belt conveyors, 39 proper mounting, 18 bucket elevator, 36 wiring, 19 drive sprocket on rotary feeder, 38 end bearing on screw conveyor, 40 non-ferrous window, 41 rotating shaft of rotary feeder, 38 Maintenance, 23 screw conveyor flights, 40 Manuals, 43 screw conveyors, 39 Modifications...
  • Page 46 Index Technical data approvals, 29 Technical support, 44 partner, 44 personal contact, 44 Warning symbols, 12 Warranty, 10 Wiring, 19 MSP-7 Operating Instructions, 11/2023, A5E34105798-AC...
