- Page 1 ELITE Switched IP-Controllable Surge Protected PDU USER MANUAL SX-AEP-159 SX-AEP-209 SX-AEP-1011i SX-AEP-1611i Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
- Page 2 User Manual ELITE Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
-
Page 3: Table Of Contents
3. Rack Installation ......................6 Rack Mounting Options........................7 Unit Installation into the Rack ......................7 4. Web Server ........................8 Login ..............................8 Power Management .........................8 Reports ............................9 Power Monitoring ...........................10 Chart ..............................10 Setup..............................11 Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) - Page 4 Backup/Restore .......................25 4.7.3 Factory Reset ........................25 4.7.4 Soft Reboot ........................25 4.8 User Profile ............................26 System info ............................26 5. Command Line Interface (CLI) ..................27 SSH..............................27 RS 232 PORT ..........................27 Commands.............................28 Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
- Page 5 7. Application Programming Interfaces (APIs) ............... 32 HTTP/HTTPS REST ........................32 Interfaces ............................32 8. Part Numbers ......................... 32 Part Number Scheme ........................32 9. Troubleshooting ......................33 10. Specifications ........................ 34 Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
-
Page 6: Introduction
• Line Voltage • Neutral-Ground Voltage • Each Outlet Current • Each Outlet Power • Line Frequency • Each outlet Power Factor • Crest Factor • Each Outlet Energy Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 7: Physical Interfaces
7 Outlets / 5-15R SX-AEP-1011i 11 Outlets / IEC C13 240V AC 10 A 50/60 Hz SX-AEP-1611i 11 Outlets / IEC C13 240V AC 16 A 50/60 Hz Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 8: Installation And Components
The default login credentials are: Username: admin Default password: Adm1nXXXXXX Where XXXXXX are the last six characters of the MAC address. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 9: Usb-Micro Ab
2.9. Access to the Common, Normally Open, and Normally Closed positions is provided for each relay. The wire size can range from 18 AWG to 22 AWG. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 10: Wiring Details
If the button is held for less than 10 seconds, the unit will perform a software reset that will not reset any data, or power cycle the connected equipment. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 11: Front Key Switch
• Ensure the Unit is mounted securely and evenly. • To avoid possible electrical shock and equipment damage, Use only the supplied hardware. Failure to follow these instructions will result in death or serious injury Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 12: Rack Mounting Options
Secure Ear Mount Brackets to the Unit using eight Flat head screws Unit Installation into the Rack Horizontal Mounting: Mount Unit on 19” rack holes provided in the channel and secure the Unit using four Pan head screws. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 13: Web Server
ELITE+ and individual outlets, as well as basic control of each outlet and auxiliary relay outputs. The top right section of the page provides system status. Contact Closure input status is displayed. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 14: Reports
Total current measurement period. The measured input frequency during the measurement Frequency Frequency period. Power Factor of all Outlets Power Factor The measured power factor during the measurement period. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 15: Power Monitoring
Additionally, a pie chart offers a visual representation of the relative frequency of trigger activations, providing a clear comparison of trigger activity. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 16: Setup
Syslog Settings Configure Syslog server settings USERS Configure and modify user accounts. TRIGGERS Create and modify Triggers Threshold with Samples Configure triggers based on measurements Auto Ping Configure triggers based on pinging IP addresses Schedule Configure triggers based on time Contact Closure (CC) Configure triggers based on contact closure status SEQUENCES Create and modify custom Sequences Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 17: Device Setup
Address or Hostname in an auto ping trigger. Specifies the amount of time the Axess ELITE+ device will wait for a ping Auto Ping Timeout response before calling the attempt a failure. Specifies if the user has permission to control device from cloud if it is Device Control enabled and vice versa if disabled. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 18: Outlet Configuration
Using this setting, the outlet will still turn off during Shutdown state. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 19: Outlet Group Configuration
Options for this setting are NTP or manual. NTP will use the NTP Server option to automatically sync the device time every day. Specifies the desired time zone adjustment for the Axess ELITE+ Time Zone device. Specifies the hostname or IP address of the NTP server to use for time NTP Server synchronization. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 20: Network Setup
NOTE: If disabling the web server, the web interface end REST API will be disabled, only limited functionality over SNMP will remain it enabled. HTTP Port Port number to use for the web server. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 21: Network Advanced Setup
The port number that the SNMP Manager is listening for traps on. Specifies which specific traps are to be sent. Triggers send traps for Traps Sent Triggering and Clearing. Manual Control sends traps for outlet state changes, and Authentication sends traps for failed authentication attempts. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 22: 802.1X Settings
Specify the authentication method used during the 802.1x negotiation. Authentication Type Different authentication options and settings will be displayed based on the selected Authentication Type. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 23: Ldap Client Settings
A button to send an authentication request using the given settings for the user and password above. NOTE: Settings should be saved using Test User the "Save Settings" button at the bottom of the page before testing a configuration change. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 24: Syslog Settings
The IP address or name of the Syslog server Port Listening port used by syslog server Protocol Supported protocol by syslog server Syslog Tag Required syslog tag can be given Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 25: Cloud Setting
Device Control: Grants the user control over device outlets. • Network Settings: Permits the user to modify network settings. • Software Update: Enables the user to update software. • UserAdmin: Provides administrative privileges over user accounts. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 26: Triggers Setup
NTP server is updating correctly to use the schedule trigger. The actions to be executed upon closing or opening of the contact closure Contact Closure input may be defined as various User Triggers on the Triggers Setup web page. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 27: Action Types
REST API command. Clear the device's shutdown state. Clearing the device's shutdown state will Clear Shutdown State cause the outlets to follow the logic defined by the On Shutdown Clear setting. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 28: Threshold With Samples
The Schedule trigger uses the internal time of the Axess ELITE+ to easily configure single and recurring events based on time. Only Alarm Actions are used for this trigger. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 29: Contact Closure
Using sequences avoids manually performing each action, or turning each outlet on or off, individually. Utilities Axess ELITE+ contains several utilities to ease the configuration and deployment that may be performed on a per unit basis through several web pages. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 30: File Upload
A soft reboot will not change the outlet state or disconnect power from connected equipment. This request will add a message in the event log “Rebooting Adapter Due to User Request”. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 31: User Profile
On this page, users can also edit their username, password, and view their privileges and authentication mode. This screen helps users to manage their own profiles and maintain their account security. System info The System Info screen provides hardware and software information about the device and the number of users connected to the device. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 32: Command Line Interface (Cli)
3. Go to Setup and select Serial Port. 4. Set the speed to 115200. 5. Click on New Settings to connect. 6. Provide the login credentials: • Login: admin • Password: admin Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 33: Commands
Retrieves the nominal voltage setting of the device. • get nominalfrequency: Retrieves the nominal frequency setting of the device. • get temperatureunit: Retrieves the temperature unit setting of the device. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) - Page 34 1 on: Turns on Aux relay 1. • set auxelay 1 reboot: Reboots Aux relay 1. • set nominalvoltage: Sets the nominal voltage for the device. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
- Page 35 Sets the temperature unit for the device. • set devicename: Sets the name of the device. • get outletname: Retrieves the name of all the outlets. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
-
Page 36: Security
Access Protocol) to authorize users, and determine their level of privileges, using Microsoft® Active Directory. While it is possible to use LDAP to authorize users without SSL encryption, we suggest only configuring the connection to the authentication server using SSL encryption to plain text network traffic. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 37: Interfaces
16A Rated Current 16A Rated Current Number of Receptacles 9 Receptacles (NEMA ONLY) 11 Receptacles (IEC ONLY) NEMA / IEC Model IEC Model (240V) blank NEMA Model (120V) Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 38: Troubleshooting
8. Contacting customer support - If the above troubleshooting methods do not resolve the issue, the user may be advised to contact customer support for further assistance. Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A) -
Page 39: Specifications
EN IEC 61000-3-2:2019 + A1:2021 EN 61000-3-3:2013 + A2:2021 Surge Protection Advanced Series Mode IP protection class IPX0 AC Power System Type Pollution Rating Pollution degree (PD) PD 2 Technical Support: 800-645-9721 | surgex.com ©2025 AMETEK SurgeX | B01-00014 (REV A)
