TecTake 405110 Installation Manual

Accessory list
Attention: The drawings below are only for reference which might be slightly different from the actual object, please in kind prevail. Any tools missing
or installation problems, please contact the customer service firstly.
A C
x1 B
x4
X4
2.5x2.5
4x4 5x5 M4x6 M6x16
Part list
Qty Qty
No. Part No. Part No.
1
2
Pedestal
Column
1 1
Supporting beam Transmission rod
1 2
Crank Baffle
Item No.: 405110/405111
N231031111 -V1
Technical data
Column Number 2
Maximum Load
70KG
Maximum speed 6mm/Round
Lowest Position 710mm
Highest Position 1210mm
1000- 1600mm
Desktop Size
600- 800mm
Applicable Temperature
0~40°C
D E
F G
X14 x1
X8 x4
ST4.2x19
M6x30 M8x50 Nut Wrench
Installation instruction
Qty
Part
5
7
1
4
Column
2
Supporting plate
8
6
3
1
STEP1
Install Pedestal(1)
E
x8
A
5x5
Install Supporting
STEP2
beam(4)
F
x2
1
A
A
Loosen
4x4 5x5
H
x1
Loosen the 4 screws on the beam (4) with a 4 x 4 wrench (A ),
and then pull the beam apart
Crank Holder
STEP3
Install Transmission rod(5)
A
2.5x2.5
2
2
Install (5) & (2)(3), following picture1, then picture 2, use
2.5*2.5 wrench(A) to tighten.
A
E
1
3
Install (1) & (2)(3) together, use 5*5 wrench(A) to tighten the screws(E)
2
A
F
4
Stretch
3
Fix the beam to the column (2) (3) as shown
in the figure, and tighten the screw (F) with
a 5 x 5 wrench (A)
1
5
3
Loosen
Insert
2
2
4
2
Rotate
Insert
Tighten
A
Do not rotate the drive rod
more than a third of a turn.
