HK Instruments DPG Series Manual

INTRODUCTION
Thank you for choosing an HK Instruments DPG/PS series filter
alert. In many situations filter monitoring requires an alarm signal
and a local display. Our filter alerts are the right solution for these
situations. The DPG/PS filter alerts combine differential pressure
switches with gauges into one practical product offering.
APPLICATIONS
The filter alerts are a solution for systems requiring visual indication of
pressure on site and a switching point signal. The filter alerts are ideal
for general-purpose work in air-conditioning and ventilation, especially
SPECIFICATIONS
in monitoring of air filters for contamination.
SPECIFICATIONS
Performance
Accuracy of gauge (FS 20 °C):
±2 %
Switching difference:
DPG200/PS200: 20 Pa
DPG300/PS300: 20 Pa
DPG500/PS500: 20 Pa
DPG600/PS600: 30 Pa
DPG1,5K/PS1500: 80 Pa
Accuracy of switching point (Low limit typ.):
DPG200/PS200: 20 Pa ±5 Pa
DPG300/PS300: 30 Pa ±5 Pa
DPG500/PS500: 30 Pa ±5 Pa
DPG600/PS600: 40 Pa ±5 Pa
DPG1,5K/PS1500: 100 Pa ±10 Pa
Accuracy of switching point (HIgh limit typ.):
DPG200/PS200: 200 Pa ±20 Pa
DPG300/PS300: 300 Pa ±30 Pa
DPG500/PS500: 500 Pa ±30 Pa
DPG600/PS600: 600 Pa ±30 Pa
DPG1,5K/PS1500: 1500 Pa ±50 Pa
Electrical rating, resistive load:
3 A / 250 VAC (DPG200/PS200: 0.1 A / 250 VAC)
Electrical rating, resistive load:
2 A / 250 VAC (DPG200/PS200: -)
Maximum pressure:
50 kPa
Service life:
> 1 000 000 switching operations
Copyright HK Instruments 2017
FILTER ALERTS
DPG/PS Series
• READ THESE INSTRUCTIONS CAREFULLY BEFORE
• Failure to observe safety information and comply with
• To avoid electrical shock or damage to equipment, disconnect
• To avoid potential fire and/or explosion do not use in potentially
• Retain these instructions for future reference.
• This product, when installed, will be part of an engineered
Technical Specifications
Media compatibility:
Dry air or non-aggressive gases
Measuring units:
Pa
Environment:
Operating temperature: -5...+60 °C
Storage temperature: -40...+85 °C
Physical
Case (DPG & PS):
ABS
Cover (DPG & PS):
PC
Membrane (DPG & PS):
Silicone
Machinery (DPG):
Aluminum and steel spring
Duct connectors (PS):
ABS
Tubing (PS):
PVC, soft
www.hkinstruments.fi
WARNING
ATTEMPTING TO INSTALL, OPERATE OR SERVICE THIS DEVICE.
instructions can result in PERSONAL INJURY, DEATH AND/OR
PROPERTY DAMAGE.
power before installing or servicing and use only wiring with
insulation rated for full device operating voltage.
flammable or explosive atmospheres.
system whose specifications and performance characteristics
are not designed or controlled by HK Instruments. Review
applications and national and local codes to assure that the
installation will be functional and safe. Use only experienced and
knowledgeable technicians to install this device.
Protection standard:
IP54
Electrical connections:
3-screw terminal
Cable entry:
M16
Pressure fittings:
Male ø 5 mm
Weight:
510 g
Conformance
Meets the requirements for CE marking:
RoHS Directive 2011/65/EU
LVD Directive 2014/35/EU
WEEE Directive 2012/19/EU
COMPANY WITH
MANAGEMENT SYSTEM
CERTIFIED BY DNV GL
= ISO 9001 = ISO 14001 =
INSTALLATION
INSTRUCTIONS
RoHS 2
2011/65/EU
Installation version 4.0 2017
