INTRODUCTION
Thank you for choosing an HK Instruments MM series liquid col-
umn manometer. The MM series is intended for use in commercial
environments for air and non-corrosive gases. The MM series is de-
signed with overpressure reservoir to protect the manometer liquid
from leaking into the duct during overpressure.
The MM series includes a field adjustable zero point calibration and
pressure limit stickers. The MM series is available with optional level
bubble.
APPLICATIONS
MM series devices are commonly used in HVAC/R systems for:
• fan, blower and filter monitoring
• pressure and flow monitoring
SPECIFICATIONS
• pressure monitoring in cleanrooms
SPECIFICATIONS
Performance
Accuracy:
MM±50
±1 Pa
MM100
±1 Pa
MM±100500
-100...0 Pa ±5 Pa
0...500 Pa ±25 Pa
MM200600
0...200 Pa ±5 Pa
200...600 Pa ±25 Pa
Overpressure:
Max pressure 200 kPa
Copyright HK Instruments 2017
DIFFERENTIAL PRESSURE GAUGES
& MANOMETERS - MM Series
• READ THESE INSTRUCTIONS CAREFULLY BEFORE
• Failure to observe safety information and comply with
• Retain these instructions for future reference.
• This product, when installed, will be part of an engineered
Technical Specifications
Media compatibility:
Dry air or non-aggressive gases
Measuring units:
Pa
Measuring ranges:
-50...0...50 Pa
-20...0...100 Pa
-100...0...100 Pa
0...200...600 Pa
Environment:
Operating temperature:
-40...+60 ºC
Gauge fluid:
Red: s.g. 0.786 kg/dm (15 °C)
(Isopar M)
MM±50 RED
MM100 RED
MM±100500 RED
MM200600 RED
www.hkinstruments.fi
WARNING
ATTEMPTING TO INSTALL, OPERATE OR SERVICE THIS
DEVICE.
instructions can result in PERSONAL INJURY, DEATH AND/OR
PROPERTY DAMAGE.
system whose specifications and performance characteristics
are not designed or controlled by HK Instruments. Review
applications and national and local codes to assure that the
installation will be functional and safe. Use only experienced and
knowledgeable technicians to install this device.
Physical
Case:
ABS
Cover:
PMMA
Knobs:
Polycarbonate (PC)
O-ring:
Nitrile rubber (NBR)
Weight:
420 g
Safety
Product equipped with integral reservoir to prevent
gauge fluid leakage during overpressure situation.
Conformance
Meets the requirements for CE marking:
RoHS Directive: 2011/96/EU
COMPANY WITH
MANAGEMENT SYSTEM
CERTIFIED BY DNV GL
= ISO 9001 = ISO 14001 =
INSTALLATION
INSTRUCTIONS
RoHS 2
2011/65/EU
Installation version 3.0 2017
