SINUMERIK
SINUMERIK ONE
New installation and upgrade
Installation Manual
Valid for:
CNC software for SINUMERIK ONE
Linux basic software V6.00
12/2019
A5E49062488B AA
V6.13
Preface
Fundamental safety
instructions
System overview
New installation
Upgrade
Device replacement
Service tasks
Abbreviations
1
2
3
4
5
6
A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SINUMERIK ONE NCU 1750 and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens SINUMERIK ONE NCU 1750

Summary of Contents for Siemens SINUMERIK ONE NCU 1750

  • Page 1 Preface Fundamental safety instructions System overview SINUMERIK New installation SINUMERIK ONE New installation and upgrade Upgrade Device replacement Installation Manual Service tasks Abbreviations Valid for: CNC software for SINUMERIK ONE V6.13 Linux basic software V6.00 12/2019 A5E49062488B AA...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Siemens' content, and adapt it for your own machine documentation. Training At the following address (http://www.siemens.com/sitrain), you can find information about SITRAIN (Siemens training on products, systems and solutions for automation and drives). FAQs You can find answers to Frequently Asked Questions in the Service&Support pages at Product Support (https://support.industry.siemens.com/cs/de/en/ps/faq).
  • Page 4 Note regarding the General Data Protection Regulation Siemens observes standard data protection principles, in particular the principle of privacy by design. For this product, this means: this product does not process / store any personal data, only technical functional data (e.g. time stamps).

  • Page 5: Table Of Contents

    Table of contents Preface .................................3 Fundamental safety instructions........................7 General safety instructions.......................7 Equipment damage due to electric fields or electrostatic discharge ........11 Warranty and liability for application examples ..............12 Industrial security ........................13 Residual risks of power drive systems ...................15 System overview ............................17 Delivery condition of the system ....................17 Status and diagnostics displays .....................18 New installation ............................19...
  • Page 6 Table of contents Configuration file "basesys.ini" ....................41 Open source software ......................42 Abbreviations..............................43 Abbreviations .........................43 Index................................45 New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...

  • Page 7: Fundamental Safety Instructions

    Fundamental safety instructions General safety instructions WARNING Electric shock and danger to life due to other energy sources Touching live components can result in death or severe injury. ● Only work on electrical devices when you are qualified for this job. ●...
  • Page 8 Fundamental safety instructions 1.1 General safety instructions WARNING Electric shock due to equipment damage Improper handling may cause damage to equipment. For damaged devices, hazardous voltages can be present at the enclosure or at exposed components; if touched, this can result in death or severe injury.
  • Page 9 ● If you come closer than around 2 m to such components, switch off any radios or mobile phones. ● Use the "SIEMENS Industry Online Support app" only on equipment that has already been switched off. WARNING...
  • Page 10 Fundamental safety instructions 1.1 General safety instructions Note Important safety notices for Safety Integrated functions If you want to use Safety Integrated functions, you must observe the safety notices in the Safety Integrated manuals. WARNING Malfunctions of the machine as a result of incorrect or changed parameter settings As a result of incorrect or changed parameterization, machines can malfunction, which in turn can lead to injuries or death.

  • Page 11: Equipment Damage Due To Electric Fields Or Electrostatic Discharge

    Fundamental safety instructions 1.2 Equipment damage due to electric fields or electrostatic discharge Equipment damage due to electric fields or electrostatic discharge Electrostatic sensitive devices (ESD) are individual components, integrated circuits, modules or devices that may be damaged by either electric fields or electrostatic discharge. NOTICE Equipment damage due to electric fields or electrostatic discharge Electric fields or electrostatic discharge can cause malfunctions through damaged individual...

  • Page 12: Warranty And Liability For Application Examples

    Fundamental safety instructions 1.3 Warranty and liability for application examples Warranty and liability for application examples Application examples are not binding and do not claim to be complete regarding configuration, equipment or any eventuality which may arise. Application examples do not represent specific customer solutions, but are only intended to provide support for typical tasks.

  • Page 13: Industrial Security

    In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Products and solutions from Siemens constitute one element of such a concept.
  • Page 14 Fundamental safety instructions 1.4 Industrial security WARNING Unsafe operating states resulting from software manipulation Software manipulations, e.g. viruses, Trojans, or worms, can cause unsafe operating states in your system that may lead to death, serious injury, and property damage. ● Keep the software up to date. ●...

  • Page 15: Residual Risks Of Power Drive Systems

    Fundamental safety instructions 1.5 Residual risks of power drive systems Residual risks of power drive systems When assessing the machine- or system-related risk in accordance with the respective local regulations (e.g., EC Machinery Directive), the machine manufacturer or system installer must take into account the following residual risks emanating from the control and drive components of a drive system: 1.
  • Page 16 Fundamental safety instructions 1.5 Residual risks of power drive systems New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...

  • Page 17: System Overview

    File basesys.ini (template) SD Card /user/common/tcu TCU configuration files Note Files in the directory under /user always have priority over files with the same name in the directory /oem → /addon → /siemens. New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...

  • Page 18: Status And Diagnostics Displays

    STOP MRES (= memory reset) Further information The meaning of the LED and 7-segment status displays can be found in the respective hardware description (https://support.industry.siemens.com/cs/document/109768483): ● NCU 1760 Equipment Manual ● NCU 1750 Equipment Manual ● PPU 1740 Equipment Manual...

  • Page 19: New Installation

    New installation Procedure for new installation Installing CNC software Requirement: ● The SINUMERIK ONE NCU or PPU is connected. ● The SINUMERIK ONE and the SD Card with CNC software are in delivery condition. ● The original licensed SINUMERIK ONE SD Card is plugged in. Procedure: ●...

  • Page 20: This Is How You Create A Sinumerik Service System

    New installation 3.2 This is how you create a SINUMERIK service system This is how you create a SINUMERIK service system Application The "SINUMERIK service system (eboot)" starts up the NCU from the USB storage medium. The SINUMERIK service system supports you in the following tasks: ●...
  • Page 21 New installation 3.2 This is how you create a SINUMERIK service system 2 partitions are created on the SINUMERIK service system: ● A Linux partition that is not available under Windows. NOTICE Cancel the prompt for formatting! In Windows 10, a prompt for formatting the data storage medium appears when plugging in the USB storage medium.

  • Page 22: How To Check The Sd Card

    New installation 3.3 How to check the SD Card How to check the SD Card Proceed as follows The following action is necessary to enable you to use the maximum extent of storage on the Linux Partition: 1. Start up the control system with SINUMERIK service system. 2.

  • Page 23: How To Back Up The Data Of The Cnc Software

    1. Startup of the control system with SINUMERIK service system. 2. In the main menu, select the menu item "Backup NCU and Data". 3. Select the menu item "Backup SSD system (/siemens, /addon) partition to USB stick" to back up the data on the SINUMERIK service system.

  • Page 24: How To Back Up Data On The Sd Card

    New installation 3.5 How to back up data on the SD Card How to back up data on the SD Card Proceed as follows To create a complete data backup of the SD Card (OEM and user data and license key): 1.

  • Page 25: This Is How You Load Factory Settings

    New installation 3.6 This is how you load factory settings This is how you load factory settings Proceed as follows Archives created previously on the SD Card remain unaffected by this. To load factory settings: 1. Startup of the control system with SINUMERIK service system. 2.

  • Page 26: How To Deactivate The Internal Sinumerik Operate

    New installation 3.7 How to deactivate the internal SINUMERIK Operate How to deactivate the internal SINUMERIK Operate Proceed as follows The "internal" SINUMERIK Operate is part of the CNC software. When a SINUMERIK Operate is used on an IPC instead of a TCU, the internal SINUMERIK Operate must be deactivated: 1.

  • Page 27: Upgrade

    Upgrade How to check the installed software version Proceed as follows To display the installed software version: 1. Startup of the control system with SINUMERIK service system. 2. In the main menu, select the menu item "Diagnosis". 3. Select the menu item "Installed software versions": New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...
  • Page 28 Upgrade 4.1 How to check the installed software version Example New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...

  • Page 29: How Install A Software Update

    Upgrade 4.2 How install a software update How install a software update Proceed as follows To install a software update: 1. Copy the new CNC software package (*.tgz) to the FAT partition of the SINUMERIK service system. 2. Startup of the control system with SINUMERIK service system. 3.

  • Page 30: How To Delete All Of The Data And Install An Update With A Restore Point

    Upgrade 4.3 How to delete all of the data and install an update with a restore point How to delete all of the data and install an update with a restore point Proceed as follows To delete all of the OEM and user data on the SD Card: 1.

  • Page 31: Device Replacement

    ● There is a restore point (system restore point) on the SD Card or a CNC software package (current.tgz) in the directory /card/install/siemens. ● Before the defect, a DSF archive was created as a backup using SINUMERIK Operate:...

  • Page 32: How To Create A System Restore Point

    How to create a system restore point Proceed as follows To restore the system when replacing the NCU or PPU, a software installation file of the type *.tgz is required. ● Original CNC software package: /card/install/siemens/current.tgz ● Restore point: /card/install/siemens/snapshot-siemens_<xxx>.tgz NOTICE Creating a restore point When you create a restore point, an existing "current.tgz"...
  • Page 33 Device replacement 5.2 How to create a system restore point Result New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...

  • Page 34: How To Restore Data From The Sinumerik Service System

    Device replacement 5.3 How to restore data from the SINUMERIK service system How to restore data from the SINUMERIK service system Proceed as follows To restore the complete system: 1. Startup of the control system with SINUMERIK service system. 2. In the main menu, select the menu item "Restore NCU Software and Data". 3.

  • Page 35: Service Tasks

    Service tasks Service commands Service shell Note Calling a service command The service commands are only available in the "Service Shell" on the SINUMERIK service system. The service command "sc" is a tool used for performing service tasks in the Service Shell. An onboard keyboard is available for making entries: To get a list of all of the actions with a brief description, enter "sc help".
  • Page 36 Service tasks 6.1 Service commands Default users The following users are already set up: User Access level Target group user Password: CUSTOMER Operator service Password: EVENING Service personnel manufact Password: SUNRISE Machine manufacturer NOTICE Change password To increase system security, you should change the passwords in the Linux system for users "manufact", "service"...

  • Page 37: Help

    Service tasks 6.1 Service commands ● Alternatives are separated with "|". Example: sc start all|system|SUBSYSTEM This means that any of the following commands applies: sc start all sc start system sc start SUBSYSTEM In the latter case, SUBSYSTEM in upper case can be replaced by an actual subsystem name.

  • Page 38: Disable

    Service tasks 6.1 Service commands 6.1.2 Disable Description Syntax: sc disable hmi|nck|SUBSYSTEM ... sc disable DHCPSvr -INTERFACE sc disable DHCPSync [-X120] sc disable IPAlias [-X120] sc disable usb [-MINUTES] all | HOSTS Alternative names: Authorization level: service The "sc disable" command switches the specified subsystems off. These subsystems are then not loaded again at the next cold restart.

  • Page 39: Distribute

    Service tasks 6.1 Service commands single "enable" command. "hmi", "nck" or any other subsystem names can be used for the subsystems. Note The "sc enable" command acts on the parameters in the basesys.ini file located in the user/ system/etc/basesys.ini directory. Parameters in the file "basesys.ini": "InternalIP_Alias", "InternalNetMask_Alias", "SyncModeDHCPD_SysNet".

  • Page 40: Vncpwd

    Service tasks 6.1 Service commands It is recommended that the version file in /user/common/tcu be changed manually as this is only read-in once by the DHCP server at the start. An incrementing of the version would then only take effect at a cold restart. Note This command can be performed on any machine in the system network, not only on the active server.

  • Page 41: Configuration File "Basesys.ini

    6.2 Configuration file "basesys.ini" Configuration file "basesys.ini" Storage path For a Linux system, a file template is available under the following path: siemens/system/etc/template-basesys.ini Copy this template with the name basesys.ini into one of the following directories: oem/system/etc/basesys.ini user/system/etc/basesys.ini Settings are made in the basesys.ini file that specify the behavior of the system in the network.

  • Page 42: Open Source Software

    Service tasks 6.3 Open source software Open source software Service programs The following service programs support you during commissioning and service tasks: ● WinSCP is a graphical, open-source SFTP and FTP client for Windows, which also supports the old SCP protocol. It offers protected data and file transfer between different computers, effectively providing the user with a protected "tunnel".

  • Page 43: Abbreviations

    Abbreviations Abbreviations Cluster File System CIFS Common Internet File System Direct Control Keys: Direct control keys Discovery and Basic Configuration Protocol DHCP Dynamic Host Configuration Protocol: Dynamic assignment of an IP address and other configuration pa‐ rameters on a computer in a network Domain Name System: Conversion of domain names into IP addresses Emergency Boot System EUNA...
  • Page 44 Abbreviations A.1 Abbreviations Universal Serial Bus Uninterruptible power supply Universal Time, Coordinated: Coordinated Universal Time (previously: Greenwich Mean Time) Virtual Network Computing New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...

  • Page 45: Index

    Index Create, 20 Creating a restore point, 32 Deactivating Operate, 26 Deleting all data + Update, 30 basesys.ini, 41 Diagnostics, 27 Installed software version, 27 Load factory settings, 25 operating, 21 Command Reset to factory settings, 25 Disable, 38 Restore, 34 Distribute, 39 Restoring the system, 34 Enable, 38...
  • Page 46 Index New installation and upgrade Installation Manual, 12/2019, A5E49062488B AA...
