TABLE OF CONTENTS RECEIVING YOUR EQUIPMENT................... WARNINGS AND SAFETY....................ELECTRICAL INFORMATION..................GROUNDING INSTRUCTIONS..................MAINTENANCE......................... CORD SAFETY AND STORAGE..................CLEANUP AND STORAGE..................... MAINTENANCE, CLEANUP, STORAGE..............PAD INSTALLATION......................DRIVE BELT ADJUSTMENTS..................MACHINE OPERATION....................MANEUVERING THE MACHINE................SERVICING......................... FINAL ASSEMBLY PROCEDURE.................. 8-13 HANDLE HEIGHT ADJUSTMENT................14-15...
• Do not allow children or untrained adults to operate CLEANFREAK.COM’s liability ceases when the carrier this machine. picks up the shipment. However, our customer service • Do not leave the machine when plugged in. Unplug...
• All servicing of CLEANFREAK.COM’s equipment should be performed by a CLEANFREAK.COM WARNING: authorized service center. Connecting the equipment to an improperly grounded • Keep hair, loose clothing, fingers and all parts of body outlet can result in an increased risk of electric shock.
CORD SAFETY CLEAN UP & STORAGE • Do not leave appliance when plugged in. Unplug 1. Unplug and wrap it under the cord hook and around from outlet when not in use and before servicing the left side handle grip. Clean the cord and inspect it •...
No user serviceable components are employed in this equipment. Do not attempt repairs yourself. CLEANFREAK.COM will assist you in locating an indepedent service contractor. 3. On the belt tensioners, locate the two jam nuts. There is a front and a rear jam nut on each tensioner.
MACHINE ON/OFF OPERATION: TO MANEUVER THE MACHINE: This equipment is equipped with a safety “LOCK OUT” lever. Refer to Diagram 1 for steps 5, 6, and 7. CAUTION: THIS MACHINE CANNOT BE OPERATED WITH 1. Install the pad driver and pad or attachment. THE HANDLE IN THE UPRIGHT POSITION.
HS Floor Machine SV Unit Final Assembly Procedure Models: TPL-BK-20-1500HS-TC TPL-BK-20-2000HS-TC Tools Required: - 5/16” Allen Wrench (included) - A pair of adjustable wrenches or • (2x) 3/4” Wrench • (1x) 9/16” Wrench • (1x) 7/8” Wrench • (1x) 13/16” Wrench Assembly Instructions: 1.
Page 9
2. Next, remove handle locking lever from handle braces with 9/16” wrench. 3. Attach handle assembly to the rear of the motor base and secure with included nut and bolt.
Page 10
4. Secure Handle Assembly to the Motor Base with nut and bolt. 5. Re-install Handle Locking Lever to Handle Brace and Handle clamp assembly. Do not fully tighten Handle Locking Lever assembly yet.
Page 11
6. Do not fully tighten Handle Locking Lever assembly yet. Adjustment for proper tension and locking will be necessary after the unit is fully assembled. Refer to Instructions for Locking Lever Adjustment in the next section. 7. Re-install rear right-wheel assembly (C14724, C11559-1, G11943, C00240(2x), C14725). Do not over- tighten wheel assembly.
Page 12
8. Assembly is complete. Proceed to adjust Handle Locking Lever Assembly. Handle Locking Lever Adjustment: 1. Put the handle in the unlock position (up position) and start adjusting the nut C11558 on the threaded portion of the spade bolt (C11536) until the gap between the clamp is around 0.8mm (around the width of a credit card).
Page 13
2. Check that the cord-hook clamp is sliding up and down freely on the handle stem while in the unlock position. 3. Lock the handle (down position) to check if it is tight enough. The cord-hook clamp should not slide while in the locked position when properly tightened.
Handle Height Adjustment: 1. Handle height during operation can be adjusted to accommodate a slightly higher position. Begin by Locking the handle into the desired height. 2. To set the Brace-stops for the operator’s preferred height, loosen the two jam nuts, one above the frame and one below the frame.
Page 15
3. Be careful not to over-extend the brace-stop bolts. Check to make sure the handle braces make full contact with the brace-stop bolts when handle is in lowest position. 4. Once the desired height setting is achieved, tighten the two jam nuts on the brace-stop bolts on each side.
