SPECIFICATIONS
Part Number: 115957
Set Up Size:91"L x 37"W x 64"H
Packed Size:48"L x 37"W x 25"H
W e i g h t: 45 lbs.
Fishable Area: 11 sq.ft.
Instructions: 106618
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
** REGISTER YOUR PURCHASE ONLINE AT CLAMOUTDOORS.COM **
IMPORTANT-PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable.
Clam Outdoors has a one- y e a r manufacturer's defect warranty from the date of original purchase. Warranty
does not cover cracked or worn bases (if runner kits have not been installed as recommended), cracked windows,
tent tears or cuts, or broken or bent hoops due to high wind weather conditions or unattended use. Defective parts will
be replaced or repaired (at the manufacturer's option) if found to be defective within one year from the date of original
purchase. Warranty will be void if product has been subject to neglect, misuse, improper installation, misapplication,
alteration, accident including but not limited to improper maintenance, or use of unauthorized parts or attachments.
Please read the entire owner's manual to ensure proper installation, use, storage and care of your Clam Shelter.
To submit a warranty claim request, please use one of the following methods:
https://clamoutdoors.com/pages/warranty-form
Email:
customerservice@clamcorp.com
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description of
the problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your request,
and a Clam representative will contact you regarding your claim status. All returns must be shipped to us postage pre-
prepaid.
It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty,
negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any
injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit,
or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or
replacement of Clam products. Clam reserves the right to make alterations or modifications in its products at any
time, which in its opinion, may improve the performance and efficiency of the product. Clam shall not be obligated to
make such alterations or modifications to products already in service.
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
Phone: 763-231-4120
FISH TRAP BUILD VIDEO
CLAMOUTDOORS.COM
WARRANTY INFORMATION
LIMITATION OF LIABILITY
MODEL 9710

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KENAI PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Clam KENAI PRO

  • Page 1 It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any...
  • Page 2: Parts List

    PARTS LIST QTY. DESCRIPTION PART NO. 104108 BASE, KENAI PRO 104145 HOOP POLE, KENAI PRO 104147 TENT, KENAI PRO 104146 SEAT RAIL TUBE 102814 U-CHANNEL 106618 INSTRUCTIONS, KENAI PRO 101095 TOW ROPE, 3/8 DIA X 9 FT 104159 HAMMOCK, ACCESSORY...
  • Page 3 HARDWARE FASTENERS REFERENCE...
  • Page 4: Required Tools

    REQUIRED TOOLS #2 AND #3 PHILLIPS HAND SCREW 3/8 AND 7/16 COMBINATION WRENCH OR SOCKETS #2 PHILLIPS SCREW BIT POWER DRILL...
  • Page 5: Step 1 - Mounting Brackets

    STEP 1 – MOUNTING BRACKETS STEP 1 A. Install both Mounting Brackets #103833 to sled using hardware shown below. STEP 2 – CAP TUBE SPACERS A. Insert Cap Tube Spacers #101083 into the ends of the Hoop Poles #104145 (see photos below).
  • Page 6: Step 3 - Swivel Bracket

    STEP 3 STEP 3 – SWIVEL BRACKET A. Secure Hoop Poles to Swivel Bracket #103834 using the hardware shown. B. Repeat process for opposite Swivel Bracket. Hoop Poles assembled in Step 2 Leave these holes open...
  • Page 7 STEP 4 – HOOP INSTALLATION A. Attach the Hoop Pole Assembly from Step 3 to the FRONT hole location on both Mounting STEP 3 Brackets using hardware shown below. Attach the assembly from Step 3 to Shown with accessory the Mounting Bracket #103833 from Corner Console #104130 Step 1 installed (not included)
  • Page 8: Step 5 - Seat Assembly

    STEP 5 – SEAT ASSEMBLY STEP 5 A. Insert Seat Tube Plugs #101429 into ends of the Seat Rail Tubes #104146. B. Slide the Seat Sliders #104162 onto the Seat Rail Tubes. C. Install the Deluxe Seat #104165 onto sliders using the OUTER holes on seat with the hardware shown. NOTE: Seat Covers are not included with Kenai-model shelters Add a #101081...
  • Page 9 STEP 7 – ROPE & SPREADER POLE STEP 7 A. Attach the Rope #101095 to the sled by routing it through the predrilled holes on the angled end of the sled. B. Put the Rear Spreader Pole #101074 into the shelter. STEP 8 –...
  • Page 10 STEP 9 Soaking the U-Channel Molding #102814 in hot water will make it much more pliable and easier to wrap around shelter Detail “A” THE PORCH HOOP POLE SHOULD TOUCH THE FLOOR WHEN THE TENT IS SET CORRECTLY WITH SOME SLACK IN THE FRONT PART OF THE TENT Detail “B”...
  • Page 11: Tips For Use

    NOTE: Pulling behind an ATV or snowmobile may result in premature wear of the base. ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit (PN 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 12 SAFETY INSTRUCTIONS Please fully understand and follow all safety instructions as outlined. Failure to do so could result in severe injury or death. ▪ DO NOT USE OPEN FLAME HEATERS IN YOUR ICE SHELTER. INJURY OR DEATH MAY RESULT FROM FIRE IF TENT FABRIC IS EXPOSED TO OPEN FLAME. THE TENT IS NOT FIREPROOF, BUT THE FABRIC IS TREATED WITH A FIRE RETARDANT THAT MEETS CPAI-84 SPECIFICATIONS.
  • Page 13 FREQUENTLY ASK QUESTIONS Fish Trap FAQ’s Q: Should I install a runner kit/hyfax to the base of my shelter? A: The warranty on our shelters does not cover cracked or worn bases if a runner kit has not been installed. Additionally, bases will wear much quicker without a runner kit installed.
  • Page 14 of the tent is water resistant it is not waterproof, so some water from rain or melting snow may come through your tent. A waterproofing spray such as Kiwi Camp Dry can be applied to the tent fabric to make the shelter more water repellent.
