Summary of Contents for Sovol SV08
- Page 1 SOVOL User Manual V1.0...
-
Page 3: Dear Customers
Thank you for choosing Sovol printers! Sovol is committed to providing excellent machines to 3D printing enthusiasts all over the world. This manual is designed for SV08 owners to start their SV08 printing journey. We still recommend all the SV08 owners to read the manual carefully even if you... -
Page 4: Table Of Contents
1 Note 2 Equipment Parameters 3 Package List 4 Assembly Base & Toolhead Top frame AB-axis Filament Holder Extruder Module Screen Connect Wires Screen Menu Menu Wifi Connection Pre-print preparation Calibrate Z offset Printing 6 Obico connection 7 Main Board... -
Page 5: Note
Users shall abide by relevant laws and regulations of the countries andregions where the printer is placed (used) and professional ethicsperform safety obligations, and do not use our product or device for anyillegal purpose. In no case shall Sovol bear any legal responsibilities foranyone breaching laws. -
Page 6: Equipment Parameters
Equipment Parameters Model SV08 Software language English Print method Network interface USB cord and WIFI Type Number of nozzles Print size 350*350*345mm Recommend Printing speed 300 mm/s (MAX 700mm/s) Printing accuracy ±0.1mm Nozzle diameter 0.4mm (Replaceable) Nozzle temperature ≤300℃ Hot bed temperature ≤100℃... -
Page 7: Package List
Package List Base & Toolhead AB axis Top frame Screen 物品清单 Filament Holder PTFE TUBE Filament Black Seal strip Tool Box step2 M5X40*4 step1 M4X30*16 step4 M4X8*4 step3 M5X15*4 step5 M3X6*8 step7 M3X12*3 step6 M4X10*2 step8 M4X12*1 Scraper knife USB Flash Drive Toolkit Power cord Ribbon... -
Page 8: Assembly
Assembly Base & Toolhead A sembly Table Base frame 1. As shown in figure , take out the base components, Z1,Z2,Z3andZ4 components， from the packaging box, and place all compoents on a table surface that is not easy to scratch. 2. - Page 9 Assembly Base & Toolhead Asse Install to the left Install to the upside 3. Align Z4 with the front panel of the base and install it to the left. 4. Check whether the mounting holes and screw holes are aligned. If not, manually adjust the Z4 assembly and base assemlbly to check whether they are aligned.
-
Page 10: Top Frame
Use the M2.5 Allen screw- driver in the accessory box to tighten the screws in step step 5 M3×6*2 Notice: The "Sovol" logo faces forward, corresponding to the screen installation position When installing the top frame, all four corners need to be installed downward... -
Page 11: Ab-Axis
Assembly AB-axis Take out the AB axis, as shown in the picture. Place the AB axis on the Z -axis mounting base according to the position in the picture. step 1.M4×30*2 1. Installing the rear end of the AB shaft take the step 1 screw out of the spare parts package, place it into the screw holes, and lock it tightly. -
Page 12: Filament Holder
Assembly Filament Holder Assembly Turn counterclockwise to open the end cap, then insert the barrel into the circle of the barrel holder, then align the barrel cover with the barrel buckle and rotate it clockwise to tighten it. step 6.M4×10*2 After the bracket is assembled, use two step 6 screws to lock it. -
Page 13: Extruder Module
Assembly Extruder Module Please take off the cover before assemble the nozzle. Fan 4 Notice: The nozzle cover is magnetically connected and is not fixed with screws. Use 3 step 7 screws to lock and tighten on the nozzle mounting sheet metal. - Page 14 Assembly Screen 1. Prepare the touch screen and find the two display cables on the base. The cables are marked EXP1 and EXP2 below the corresponding display installation ports. Insert the display cables according to the corresponding marked ports. 2. After the screen cable is connected, use the buckle to assemble the screen.
-
Page 15: Connect Cable
Assembly Connect cable Filament runout sensor connector Camera connector Light connector X-axis motor connector Light connector Filament runout sensor Lower connector Install PTFE tubes at both ends When intalling teflon tubes for the first time,follow these steps. 1.Place the longest end of the teflon tube, as shown in the picture on the left,and align it with the squeeze outlet. - Page 16 Assembly Connect cable Insert the PETF into the two ports Pneumatic couplings Assemble two side of PTFE TUBE Please follow the following steps when unplugging the Teflon tube from extruder 1. Please pull out the Teflon tube buckle of the quick-plug interface first. 2.
- Page 17 Assembly Connect cable Assembly After connecting the material breakage detection line, you need to use a cable tie to fix the wire harness on the cable tie as the picture shown. Place the "X motor wire harness" Black flat seal in the wire trough at the bottom of the profile, then lower the black flat seal to cover the wire...
-
Page 18: Screen
Screen Menu We will continue to update the software version, and the operation interface will be different. Auto Home Show IP Preheat 1.Prepare Preheat Z offset Cooldown Speed ExO:0(27) Flow Calibrate Zoffset Quad Gantry Lvl 2.Levelling Tune Bed Mesh Nozzle Temperature Files name 3.Print USB-Files name... -
Page 19: Screen
Screen Menu 1. Nozzle 5. Fan rotation temperature speed percentage 2. Heating bed 6. Printing speed temperature 3. Printing 7. Printing progress progress bar time 4. Printer status 1. Nozzle temperature: Displays the current temperature/preset value temperature of the nozzle. 2. -
Page 20: Wifi Connection
Screen Wifi Connection Use the USB flash drive included in the machine's accessory package and insert it into your computer to access its contents. Search for the file named “wifi.cfg" within the drive. Open the “wifi.cfg" file using Notepad; this action resembles the example displayed on the right. -
Page 21: Pre-Print Preparation
Screen Pre-print preparation Attentions: 1. WIFI must use 2.4G band signal. 2. Pay attention to the strength of the WIFI signal, the router connected without obstacles in a. The straight line distance from the machine should not exceed 10m. 3. Make sure the wifi name and password are correct. 4. -
Page 22: Calibrate Z Offset
Screen Calibrate Z offset Turn on the power and enter the home page. Press the button to confirm. Enter the first-level menu, select‘Levelling’ Select "Calibrate Z offset", the machine will automatically heat the hot bed to 65°C, reset, Z-axis calibration, nozzle heating, and Z-axis height calibration. - Page 23 Screen Calibrate Z offset 1. The leveling printing test is to print 5 round pieces in the order marked above. Please observe the printing effect during printing process. 2. Once completing the printing of No.1 round piece, please observe the printing effect of No.1 round piece and adjust Z Offset right away.
- Page 24 Screen Calibrate Z offset b.GOOD a.TOO LOW c.TOO HIGH How to adjust Z Offset: Press the knob during the leveling printing test rotate the knob choose Tune press the knob choose Offset Z press the knob rotate the knob to adjust the Z Offset. ’...
-
Page 25: Printing
Screen Printing Using a USB flash drive to print or print from a web site interface. Printing process after confirming the print model: 1. Preheating print bed to a temperature of 65℃. 2.Resetting the extruder to its home on the X, Y, and Z axes. 3.Perform Quad-gantry-leveling(QGL) (the nozzle moves to the four corners of the hot bed probe point, according to the parameters, probe 1-5 turns to complete this step) -
Page 26: Obico Connection
Obico connection Obico Download a. For Android users: visit the Google Play store,search for “Obico” and select install app. b. For iOS users: Visit the Apple APP Store, search for “Obico” , and then select Install APP. c. Via Web interface: If you want to access via Web interface https://obico.io 1. - Page 27 Obico connection ⑤.Click on ‘LinkPrinter’ ⑥.Select ‘My 3D Printer ⑦.Click on ‘I have installed Came With Klippe Pre- Obico for Klipper’ Installed’ The printer should be connected to the networkunder the following scenarios: Scenario 1: If the machine can be detected, simply click 'Link'...
- Page 28 Obico connection The printer information is Display successful connection, displayed on the phone. enter the name. Scenario 2: If the machine cannot be detected, manual connection is required. Please click “Switich to Manual Setup”...
- Page 29 Obico connection a.Select the obico function, and a 5-digit verification code will appear. b.Enter the verification code displayed on the knob screen. oxsbx...
- Page 30 Obico connection c.Display successful connection, d.The printer information is enter the name. displayed on the phone. 3.Rebind Obico and perform the following operations on the machine.
-
Page 31: Mainboard
Mainboard Knob screen Knob screen Z-axis limited Power exp2 Heatbed exp1 input wire Y-axis limited X-axis limited Heatbed thermal Z2 motor Filament detection Z4 motor Z1 motor Y-axis Z3 motor motor Acceleration sensor connector X-axis (reserve) motor Nozzle power Nozzle signal SDcard Nozzle signal (reserve) - Page 32 Shenzhen Liandianchuang Technology Co. , Ltd...
