Summary of Contents for Sovol SV06 ACE

  • Page 1 SOVOL User Manual V1.0...
  • Page 3: Dear Customers

    .This manual is designed for SV06 owners to start their SV06 ACE printing journey.We still recommend all the SV06 ACE owners to read the manual carefully even if you are familiar with the 3D Printing technology, as there are lots of important information about the SV06 ACE for you to learn and help you get better printing exprience .In this manual there...
  • Page 4: Table Of Contents

    Catalogue 1 Note 2 Equipment Parameters 3 Package List 4 Assembly Mian frame installation Nozzle and camera installation Screen and power supply installation Feeder rack installation Connect the cables 5 Function List 6 Touchscreen 7 Start-up 8 Fill Filament 9 Print the file 10 OrcaSlicer 11 Obico 12 Motherboard...
  • Page 5: Note

    (used), abide by professional ethics, pay attention to safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Sovol will not be responsible for any violators' legal liability under any circustance.
  • Page 6: Equipment Parameters

    Equipment Parameters Model SV06 ACE Software language English Print method Network interface USB cord and WIFI Type Number of nozzles Print size 220*220*250mm Recommend Printing speed 200-300mm/s Printing accuracy ±0.1mm Nozzle diameter 0.4mm (Replaceable) Nozzle temperature ≤300℃ Hot bed temperature ≤100℃...
  • Page 7: Package List

    Package List Gantry Extruder kit Base kit Disaplay Rack Power box Tool Box Zip Tie M5X10*2 M4X20*2 M5X50*4 M3X8*3 Nozzle Power cord Scraper knife USB Flash Drive Phillips Barrel screwdriver Silicone brush Nozzle Cleaner Needle Diagonal pliers Toolkit...
  • Page 8: Assembly

    Mian frame installation Assembly First, remove the gantry frame gantry assembly and base kit from the M5X50*4 packaging box, as well as the M5*50 screw from the accessory pack. Gantry Base kit step 1 M5X50*2 Position the gantry assembly directly in front of the chest, and insert the gantry Tighten the screws on both sides into the groove in the base assembly.
  • Page 9: Nozzle And Camera Installation

    Nozzle and camera installation Assembly Install the camera module. Remove the camera module Align the camera Buckle in from left to right and and align the notch with the module with the X- push to the top to complete step on the X-axis securing axis bracket.
  • Page 10: Screen And Power Supply Installation

    Screen and power supply installation Assembly Remove the touchscreen from the package and locate the machine's right Disaplay side. Attach it to the bracket and slide it down to lock it into groove. The cable is connected to Then press the touchscreen Locate the right profile the touch screen interface down along the groove to...
  • Page 11: Feeder Rack Installation

    Feeder rack installation Assembly Install the rack barrel. Attach the rack plate to the top of the machine using M5X10*2 two M5X10 screws. Barrel Rack (This part of the rack) Facing the front of the machine. step 4 M5X10*2 *The picture shows the back of the machine,When the back of the machine is facing you, the rack faces to the left.
  • Page 12: Connect The Cables

    Assembly Connect the cables All wiring connections of this machine need to be turned off Filament sensor before plugging and unplugging. connector Front of the machine X-axis motor connecter *Please select the correct input voltage to match your local power supply. (230V or 115V).
  • Page 13: Function List

    Function List...
  • Page 14: Touchscreen

    Touchscreen Network connection Nozzle temperature Mian Hot bed temperature Fan and LED If an error occurs during the return to zero, release the filament 2 turns before starting the Back to zero return to zero. Motor unlok...
  • Page 15: Start-Up

    Start-up After the entire installation process is completed, plug in the power cord and toggle the power switch on the left side of the machine. The printer's display will light up, indicating that it has entered the booting guidance phase. Follow the steps below for operation. Language Selection Tap“start”...
  • Page 16: Fill Filament

    Fill Filament After completing the boot guide, please load the filaments before starting printing. Cut the filament tip at a 45° bevel angle and insert it into the feeder, pushing it up to the gear. Click on Filament on the main interface → Select PLA → Load Filament. The extruder will automatically rotate to feed the material in.
  • Page 17: Print The File

    Print the file Plug in the USB and wait for the display to load the print content, and then follow the steps below to print. Click Print Select the file you want to print.
  • Page 18: Orcaslicer

    OrcaSlicer OrcaSlicer_2.1.1_x64_.exe Double-click and install the file "OrcaSlicer" on the USB flash drive. Select add SV06 ACE and the parameters are already set in the system. Select and add the model you want to print.
  • Page 19: Obico

    Obico Obico Download a. For Android users: visit the Google Play store,search. for“Obico” and select install app. b. For iOS users: Visit the Apple APP Store, search for “Obico”, and then select Install APP. c. Via Web interface: If you want to access via Web interface.
  • Page 20 Obico ⑤.Click the main menu ⑥.Click the ‘Link New Printer’ ⑦.Click the ‘Generic Kilper- Self-Installed’ ⑨.Switch to Manual Serup ⑧.Click the ‘Generic Kilper- ⑩.Click the ‘Obico menu on Self-Installed’ the touch sereen’...
  • Page 21 Obico Machine QR code One-time password After scanning the QR code on the screen, you will see what's on the right, indicating that your machine is now connected to obico. Proceed to operate according to your needs and embark on your 3D printing journey.
  • Page 22: Motherboard

    Motherboard...
  • Page 24 SHENZHEN Lian Dian Chuang Technology CO., LTD. Official Website: sovol3d.com E-mail: info@sovol3d.com...
