K2
KRYPTO Bluetooth Reader
Radio equipment for access control applications.
CDVI's economical KRYPTO K2 card reader makes
high security easy!
KRYPTO K2 Mifare
®
combined with CDVI EV2 credentials work right
out of the box. No fastedious and complicated
programming required!
Factory-programmed,
CDVI protocol and encryption keys ensure
end-to-end encryption between the card, reader
and A22K door controller.
• Easy to use & FULLY secure CDVI protocol
using authentication with diversified keys.
• Reads 13.56 MHz Mifare Classic and
DESFire EV2 credentials
• OSDP-2 compatible
• Bluetooth
• Up to 2 in. (5cm) read range
• Power requirements: 12V DC
• Current consumption : 200mA
RFID Frequency band : 13,553-13,567MHz / Bluetooth Frequency band: 2,402 - 2,480 GHz
Maximum transmitted power <60dBμA/m
DESFire
EV2
readers
®
®
industry-unique
secure
43
w w w . c d v i . c a
QUICK START
INSTALLATION GUIDE
RED Certification
CE Certification
-40°C to +70°C
IP65
IK9
WEEE
We CDVI declare that the K2 radio equipment complies with
directive 2014/53/UE. The full text of the EU declaration is
available at www.cdvi.com
43
43
39
7,2
21
5
43
39
7,2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CDVI KRYPTO K2
Summary of Contents for CDVI KRYPTO K2
- Page 1 CDVI protocol and encryption keys ensure end-to-end encryption between the card, reader and A22K door controller. We CDVI declare that the K2 radio equipment complies with directive 2014/53/UE. The full text of the EU declaration is available at www.cdvi.com • Easy to use & FULLY secure CDVI protocol using authentication with diversified keys.
- Page 2 D0 / A+ (RS485 BUS) Ce document est la propritété exclusive de CDVI, il ne peut être communiqué à des tiers sans son autorisation. This document is the exclusive property of CDVI and it may not be disclosed to others without permission.
- Page 3 RAPIDE Lecteur Bluetooth KRYPTO Certification RED Équipement radioélectrique pour applications de contrôle Certification CE d’accès. -40°C à +70°C Le lecteur de carte économique KRYPTO K2, la haute sécurité en toute simplicité. IP65 Le lecteur KRYPTO K2 Mifare DESFire ® ®...
- Page 4 D1 / B- (RS485 BUS) Ce document est la propritété exclusive de CDVI, il ne peut être communiqué à des tiers sans son autorisation. This document is the exclusive property of CDVI and it may not be disclosed to others without permission.
