AUREL RX-4MHCS-SE User Manual

650201553G
High sensitivity and selectivity 433.92 MHz superheterodyne receiver RF in AM with integrated HCS
decoding. HCS decoding uses Microchip's KEELOQ code variation technology. HCS and KEELOQ are
trademarks of Microchip.
Monostable, bistable mode and the presence of open collector outputs, make it ideal as a control element
in applications such as burglar alarms, gate openers, and generally, in functions where channel coding is
required. The transmitter code is stored by self-learning (see specifications). The module is compatible with
AUREL transmitters: HCS-TX-1/2/3 (OVO), TX1/2/3-HCS-433 (HCS), TX-2/4/6 M-HCS
Main Features
RF Sensitivity -110dBm
16 Storable Transmitters
28 bit Serial Identification Code
32 bit Hopping Code
32
2 Combinations
Self Learning
Bistable/Monostable programming
Erase Memory
Technical features are subject to change without notice. AUREL S.p.A. does not assume responsibilities for any damages caused by the device's misuse.
AUREL S.p.A. Via Foro dei Tigli, 4 - 47015 Modigliana (FC) – ITALY
Tel.: +39.0546.941124 Fax: +39.0546.941660
http://www.aurelwireless.com - email: rfcomm@aurel.it
RX-4MHCS-SE
User Manual
,
TX-12 CH, TX4-RP-HCS.
Rev.A - 04/06/2021
