AUREL RX-4MR50-SMD Instruction Manual

---------------------------------------------------------------------------------------------------------------------------------------------------
Band pass filtered Super Het Receiver 433.92MHz
Low cost OOK receiver working at 433,92MHz with band pass filter, compliant with RED (Radio Equipment
Directive 2014/53/EU) and in particular with harmonics standards:
EN 301 489-3 : V2.1.1 (final draft)
•
EN 300 220-2 : V3.1.1
•
ESD antenna protection in compliance with EN610000-4-2.
PIN-OUT
CONNECTIONS
Pin 1-5-7-8-9 GND
Pin 2 +Vcc
Pin 3 Data-Out
Pin 4 NC
Pin 6 Antenna

Technical features RX-4MR50

Supply voltage
Supply current
Reception frequency
RF sensitivity
IF Bandwidth -3dB
RF power on 50Ω pin ant.
Square wave output
Output high voltage
Output low voltage
Switch on time
Operating temperature range
NOTE 1: RF generator with 100% modulation.
Technical features are subject to change without notice. AUR°EL S.p.A does not feel responsible for any damage caused by the device's misuse.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------
AUREL S.p.A. Via Foro dei Tigli, 4 - 47015 Modigliana (FC) – ITALY
Tel.: +39.0546.941124 Fax: +39.0546.941660
http://www.aurelwireless.com - email: rfcomm@aurel.it
GND Connections. To be externally connected to a single
ground plate.
Connection to the positive pole of supply.
Data output from the receiver. Load higher than 1KΩ.
Not connected
Antenna input, impedance 50Ω.
Min Tipic
3 5
4,1 4,3
433,92
-112
420
0,020 1
Vcc-0,6
GND
-20
RX-4MR50-SMD
Instruction Manual
Max Unit
5,5 Vdc
4,6 mA
MHz
-114 dBm
KHz
-60 dBm
5 KHz
Vcc-0,1 V
GND+0,4 V
4 ms
+85 °C
01/08/2018 - Rev.A
Remarks
See note 1
Pag 1 di 6
