- Page 1 Installation Guide Flora Smart Ceiling Fan AT2663...
-
Page 2: For Your Safety
FOR YOUR SAFETY Read and save all instructions before using. WARNING 1. To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets, balancing the blades, or cleaning the fan. Do not insert foreign objects in between rotating fan blades. 2. -
Page 3: What's In The Box
WHAT’S IN THE BOX Ceiling Fan Fan Blade (x3) 12” Downrod Acrylic Shade External Power Supply Light Fixture This fixture comes pre-assembled. Please, check step 2 on page 20 for instructions. 43in. Extension Wire Bag D with Connector (suitable Wire Nut (x3) for downrod more than 18in.) Light Ring... -
Page 4: Tools Needed For Installation
CEILING FAN MOUNTING OPTIONS Unpack and inspect the fan carefully to confirm that all parts are included. Flush Mounting Standard Mounting Pre-assembled. The Atomi Smart Ceiling Fan comes already prepped for this installation option. Ceiling Outlet Box Ceiling Outlet Box 12”... -
Page 5: Other Mounting Options
Other Mounting Options If there isn’t an existing UL (cUL for Canadian Installation) listed mounting box, then read the following instructions. • Disconnect the power by removing fuses or turning off circuit breakers. • Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials. •... -
Page 6: Installing The Standard Bracket
ATTENTION Only use the provided Atomi Smart ceiling bracket that comes with your fan. Remove any existing brackets from your ceiling prior to installation. Secure the bracket to a ceiling box that is acceptable for fan support of 31.8kg (70lb). - Page 7 INSTALLING THE SAFETY SUPPORT (PART ONE) Place a washer onto the wood screw, then feed the screw through one of the loops of the safety cable. Install the washer and wood screw into the side of the brace that holds the outlet box. Leave 3mm (⅛”) of space between the support brace and washer.
- Page 8 This step is for Standard and Angled Mounting only. For the Flush Mounting (pre-assembled) please go to Step 4 (page 12). If you have a longer downrod from Atomi Smart, please follow the same instructions. PREVENT FAN FALLING INJURY OR DEATH: •...
- Page 9 Locate and remove the clip and pin. Loosen the screws and remove the downrod, canopy, and funnel.
- Page 10 Remove the clip and pin from the new downrod. Insert the canopy and funnel into the downrod, passing all wires through the downrod. Note: If using a longer downrod, connect the 43in. red and blue extension cable before installing the new downrod.
- Page 11 Hold the canopy and funnel up to insert the pin and clip back in place. 11 11 Tighten the screws. Slide down the funnel.
-
Page 12: Hanging The Fan
HANGING THE FAN Lift and carefully hang the fan on the mounting bracket. Ground Wire Be sure that the wires are not pinched between the bracket ATTENTION and fan. Note: Make sure the downrod is locked and secured to the groove inside the mounting bracket. - Page 13 INSTALLING THE SAFETY SUPPORT (PART TWO) Install the second part of the safety cable. Place the motor cable through one hole in Then place the motor cable through one the dual cable clamp. loop of the safety cable. 13 13...
- Page 14 Loop the safety cable through the other hole of Use a screwdriver to tighten each screw at the dual cable clamp and feed the cable all the the end of the dual cable clamp. way through. Optional: Trim the safety cable to fit the downrod length.
-
Page 15: Wiring The Fan
FOR THIS STEP YOU WILL NEED FOR THIS STEP YOU WILL NEED WIRING THE FAN Carefully follow these steps to get your fan wired safely and quickly. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. THE CEILING FAN MUST BE GROUNDED. - Page 16 Push the bare metal ends of the wires together and slide a wire nut over them. Twist the wire nut clockwise until tight. Give it a gentle pull to ensure none of the wires come apart. Connect the BLACK Connect the WHITE (W) wire Connect the GREEN (ungrounded Z) wire from the from the RECEIVER to the...
- Page 17 Connect the remote power supply box to the fan. The blue and red wires connect by a cam-lock connector block found on the blue and red wires. 17 17...
-
Page 18: Installing The Canopy
FOR THIS STEP YOU WILL NEED INSTALLING THE CANOPY Lift the canopy into place so that the screw holes are Tighten the screws. aligned with the housing holes. Insert the screws and loosely secure them. Fit the canopy in place as shown and turn it counter-clockwise. -
Page 19: Installing The Blades
FOR THIS STEP YOU WILL NEED INSTALLING THE BLADES Place each fan blade on the face of the motor plate one at a time. Secure each blade with screws found in Bag A1. 19 19 ATTENTION: Screws must be Note: tightened securely before fan •... -
Page 20: Assembling The Light Fixture
FOR THIS STEP YOU WILL NEED ASSEMBLING THE LIGHT FIXTURE Using a screwdriver detach the three parts that come together: the light ring, the LED board, and the LED board cover. Note: Save these screws to be used in step 4. Remove the four screws from the fan. - Page 21 Re-install the light housing screw that was removed Align the light ring keyhole slots over the two screws and twist. and tighten the other screws in the keyhole slots. 21 21 Pass the white connector through the center hole of the Attach the LED board cover using the three screws LED Board.
- Page 22 Turn on the circuit breakers to the outlet box associated with the wall switch location, then turn on the wall switch and check if the Atomi Smart WiFi Ceiling Fan has 100% of white light brightness. You can check the brightness using the Atomi Smart app or with the included remote controller.
- Page 23 Scan the QR code below Register or go to https:/ /atomismart.com/app/ Get the app Register Download the Atomi Smart app from Follow the on-screen instructions and the App Store or Google Play. register an account. Make sure to allow access to Location (Android), Bluetooth and Local Network (iOS).
- Page 24 WiFi Password Continue Connect your 2.4GHz WiFi network* Enter or select your local WiFi name, enter your password, then press “Continue”. *Make sure you’re connected to a 2.4GHz WiFi network (Atomi Smart can’t connect to 5GHz networks).
-
Page 25: Using The Remote Control
FOR THIS STEP YOU WILL NEED USING THE REMOTE CONTROL Control buttons WiFi pairing: long press (more than 5 seconds) to connect fan to network. Short press to recover WiFi connection Fan ON/OFF Long press (10 seconds) Fan reversal: Press to change to turn WiFi OFF the direction of the airflow Fan Speed (from 1 to 6) - Page 26 ATTACHING TO AN EXISTING LIGHT SWITCH Note: This is only compatible with toggle switches. Remove the screws from your Place the remote control mount Slide the remote control light switch cover over the cover and attach it with the holder in place, then insert the (Do not remove the cover).
- Page 27 FOR THIS STEP YOU WILL NEED USING THE BALANCE KIT Follow these steps to properly even out the blade weight distribution. Pause your fan to attach the clip to the end of any Ensure your fan is correctly installed and all fasteners are secure.
-
Page 28: Troubleshooting
The Ceiling Fan is too noisy. Use your smartphone to confirm that you have at least two WiFi bars in the vicinity of your Atomi Smart device. Confirm that the blades are properly installed. If not, move your Atomi Smart device closer to your The Ceiling Fan is wobbling. - Page 29 How to use batteries for the remote control? How to pair the remote control? • Always purchase the correct size and grade of the Once connected to the app, turn off the wall switch battery most suitable for the intended use. and wait 20-30 seconds.
- Page 30 1. Coupon is only valid on the Atomi Smart website 8. Promo code is not exchangeable for cash. www.atomismart.com. 9. Atomi Smart will not be liable and/or be required to 2. A valid code must be entered at the checkout page offer replacement codes, discounts, credits, cash or in order to redeem the promotion.
-
Page 31: Fcc Notice
For questions or concerns, email us at support@atomiusa.com Manufactured and marketed by ATOMI INC. 10 WEST 33RD ST., NEW YORK, NY 10001 atomi smart is a registered trademark of Atomi Inc. ® Designed by Atomi in New York. Made in China...
