Room&Board TAYLOR Assembly Instructions

Download this manual

TAYLOR

NOTE

Recommended Tools and Materials

• Screwdriver or power drill

• Allen wrench (included)

• Studfinde

Note: We recommend assembling this product with two people.

800.486.6554 | roomandboard.com

Keep these instructions for future use. Units can

be disassembled and reconfigured as desired

ASSEMBLY INSTRUCTIONS

Keep these instructions for future use

9/12/22

Need help?

Do you have a question about the TAYLOR and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS Keep these instructions for future use TAYLOR Keep these instructions for future use. Units can NOTE be disassembled and reconfigured as desired Recommended Tools and Materials • Screwdriver or power drill • Allen wrench (included) • Studfinde Note: We recommend assembling this product with two people.
Page 2 Attach the base to the Taylor case piece that will be in the first (lowest) position. o do this, place the case piece on its side or back and fasten the included Allen bolts through the base and into the underside of the case piece. The wood base requires the addition of the included steel counterweight.
Page 3 If your piece has drawers or a wine insert, remove those components prior to adding additional pieces. To add additional pieces, simply stack one on top of another to form a unit. Use the included Allen bolts to fasten the pieces together from inside the lower piece by inserting the bolts up through the top panel of the lower piece and into the corresponding threaded inserts in the bottom of the piece above.
Page 4 After the bracket is installed, place the finished wood top on top of the unit. Use the included Allen bolts to fasten the lid through the upper most piece in the same way the cases below were assembled. Your full unit should NEVER exceed 86” in total height (including base and lid components).
