Room&Board MODA Crib Assembly Instructions

Step 1: Lay the Base Panel on the floor. Place one of the End Panels
on the left side of the Base Panel so that the silver metal inserts are facing
inward. Use three Decorative Bolts and Lock Washers to secure
the End Panel to the Base from underneath the Base Panel, but DO NOT
tighten the Bolts completely yet. Repeat this procedure on the right.
Step 2: Attach one of the Sides to the End Panels with four
Decorative Bolts and Lock Washers using the enclosed Allen
Wrench. Place the Bolts through the end slat of the Side and into the
End Panel, but DO NOT tighten completely.
BOLT + WASHER
Steps 1 & 2 Attach End Panels and 1 Side
BOLT + WASHER
CRIB ASSEMBLY INSTRUCTIONS
For MODA Crib
DO NOT USE POWER TOOLS!
Step 3: Screw a Bolt and Lock Washer in each of the top holes of the 4
middle columns of inserts on the End Panels. Leave the bolts sticking out
at least an inch. This configuration puts the Mattress in the highest position,
which is the height recommended for newborns. To select a lower position, place
the bolts in lower holes. Place the Mattress Support Platform over the
Bolts. The notches in the Platform fit snugly over the Bolts.
Step 4: Attach the other Side to the End Panels as in step 2. Now tighten
all 18 Bolts on crib completely.
