- Page 1 UV DISINFECTION RACK SYSTEM Operation & Installation Instructions UV SYS TEM LB4-Z, LB5-Z, LB6-Z, LBH4-Z, LBH5-Z, LBH6-Z Series ILLUMINATING TECHNOLOGIES FOR LIFE...
- Page 2 Congratulations on purchasing this LUMINOR UV System.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Considerations .......................... 4 Before You Begin ........................... 5 Water Quality Parameters........................5 Assembly ............................... 6 Configuration Overview ........................7 System Sizing ............................8 Location ..............................8 Orientation ............................. 9 Installation ............................10 System Preparation ..........................13 Cleaning the Quartz Sleeve ........................13 Cleaning the UV Sensor ........................14 Filter Changes .............................14 Pressure Gauges ..........................15... -
Page 4: Safety Considerations
SAFETY CONSIDERATIONS It is important that care is taken when operating and/or maintaining your system. Please read the instructions • The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 5: Before You Begin
Turbidity: < 1 NTU Tannins (organics): <0.1 ppm (0.1 mg/L) UVT (transmittance): >85% (Please contact Luminor if water has a UVT that is less than 80% for pre-treatment recommendations) You can have your water tested at a private analytical laboratory or by your local dealer. It... -
Page 6: Assembly
ASSEMBLY Unpack the system and ensure all the components are included with the system. Your system is shipped with the following components: UV SYSTEM CONTROLLER RC-B4.01 4.1 systems RC-B56.01 5.1/6.1 systems RCHO-4.12 H4 systems MOUNTING PLATE MOUNTING SCREWS RCHO-56.12 H5/6 systems 310122 Single Filter 390083 GLAND NUT... -
Page 7: Configuration Overview
CONFIGURATION OVERVIEW Filter Configuration (if equipped): 1 Sediment Filter 2 Carbon Filter 3 Scale Reduction Filter (ScaleArmor™) 4 Mesh Strainer UV SYST LB4-Z1 LBH5-Z22 UV SYSTEM UV SYSTEM LBH5-Z122 LBH5-Z222... -
Page 8: System Sizing
SYSTEM SIZING All Luminor UV systems are rated for a specific flow rate in water that meets the quality parameters on page 5. PLEASE NOTE: increasing the flow above this rating or disinfecting water that does not meet the quality parameters will decrease the dose and therefore compromise the efficacy of the system. -
Page 9: Orientation
ORIENTATION This system has the ambidextrous capability of being able to have the main water inlet enter from either the left hand side or right hand side of the unit. While the whole system can be setup in either orientation, the filter head and UV reactor can not and must be rotated. The filter head inlet is indicated by the “Inlet”... -
Page 10: Installation
INSTALLATION Step 1: Once both the orientation and location have been selected, securely fasten the rack to a suitable backing. As the rack system is extremely heavy when filled with water, it is imperative that the rack be mounted with suitable fasteners for the particular installation. Mounting to a drywall backing is not suitable, unless the rack is fastened directly to the wall studs. - Page 11 PLEASE NOTE: This chart indicates the correct cartridge position for the default “left-hand” orientation with the water inlet located on the left side of the rack system. If the orientation was switched, the cartridge placement must also be switched. Once the cartridges are in place, use the supplied filter wrench to “snug”...
- Page 12 WATER-HAMMER WARNING: Quartz sleeves can break inside the reactor if water-hammer occurs. Water hammer is caused by sudden closing of valves elsewhere in the piping system. It is strongly recommended to ensure that the piping and valve system is designed to prevent water-hammer.
-
Page 13: System Preparation
SYSTEM PREPARATION With a new installation, or any time the UV system is shut down for service, without power, or is inoperative for any other reason, the lines in the home or facility could be contaminated. Use the following steps to prepare the lines throughout the entire home or facility. Step 1: Check for and remove any “dead ends”... -
Page 14: Cleaning The Uv Sensor
CLEANING THE UV SENSOR Depending on the water quality, the UV sensor may require periodic cleaning. At a minimum, the UV sensor should be cleaned on an annual basis. The following steps outline a basic cleaning procedure. Step 1: If a by-pass assembly is installed, shut the inlet valve off to prevent water flow through the system. -
Page 15: Pressure Gauges
PRESSURE GAUGES Your BLACKCOMB UV Rack system is equipped with pressure gauge ports to monitor the pressure drop across each specific filter. Depending on the application it may be important to monitor pressure drop across one, two or all three filters. A pressure gauge should be installed before and after each filter being monitored. -
Page 16: Operation
LED will be illuminated red and an audible buzzer will be sounding. To remedy this condition, the UV lamp must be replaced with a new genuine Luminor UV lamp. LBH4 Series... -
Page 17: Power-Up Sequence
BLACKCOMB & BLACKCOMB POWER-UP SEQUENCE On start-up, the controller will run through a diagnostic start-up and the sequence will be displayed as follows on the colour LCD: system starting diagnostics lamp Next, the controller checks for and initializes any optional modules that may be attached to the system. -
Page 18: Blackcomb 6.1 Operational Screens
On systems without the UV monitor, the default screen shows the Luminor Home Screen. At any point during operation the user is able to scroll through the Luminor Home Screen, Lamp Life Remaining, QR Code, Contact Info and Maintenance Parts screens by pressing the button located on the front of the controller. -
Page 19: Lamp Countdown Sequence
LAMP COUNTDOWN SEQUENCE The system counts down the number of days until a lamp change is required. Blackcomb Blackcomb Blackcomb At thirty days remaining, the LED or display screen will change to a yellow caution indicator. At seven days remaining, the system will additionally repeat an audible chirp. Past the zero day threshold, the LED or display screen changes to solid red with a continuous buzzer. -
Page 20: System Service Suggested
SYSTEM SERVICE SUGGESTED Blackcomb 5.1 & 6.1 controllers will display the System Service Suggested Screen every 6 months to remind consumers to maintain both their UV and other prefiltration. This will serve as a prompt only and will not put the system into alarm. -
Page 21: System Troubleshooting
SYSTEM TROUBLESHOOTING Hard Alarms: The following give a constant audible alarm. If present, the solenoid valve is closed, and the 4-20, remote alarm and wifi modules transmit the alarm. System Display Problem Resolution Reset lamp protection circuit -unplug unit for 10 seconds. The system has detected a Replace the lamp with the problem with the lamp. - Page 22 Soft Alarms: The following remaining errors give a 15 second audible chirp only System Display Problem Resolution Ensure all modules are connected properly to the system and to each other. Modules can be tested The module indicated is no individually by plugging in one at longer communicating to a time and cycling power to the with the system.
-
Page 23: Temperature Management Devices
In extreme situations elevated water temperature or the fluctuation in temperature can lower the output of the UV lamp. In these cases, or if the elevated water temperature is a nuisance, Luminor recommends one of the following forms of temperature management devices. - Page 24 SOLENOID CONNECTION MODULE: Connects a NORMALLY CLOSED line voltage solenoid valve to the controller. Maximum contact rating is 240VAC (50-60Hz) / 30VDC / 2A. On a non-monitored system, the solenoid will only close on a lamp failure error. On a monitored system, the solenoid is closed when the UV level drops below 50%.
-
Page 25: Blackcomb Rack-Mount Uv System Specifications
BLACKCOMB RACK-MOUNT UV SYSTEM SPECIFICATIONS LBH# LBH# LBH# LBH# LBH# MODEL -Z1-X -Z2-X -Z12-X -Z2-X -Z12-X -Z22-X -Z122-X -Z222-X Flow Rate 8 GPM 15 GPM (30mJ/cm2 @ 30.3 lpm 56.8 lpm 95% UVT) 1.82 m /hr. 3.4 m /hr. Alternate flow rate 5.6 GPM 12 GPM (40 mJ/cm... -
Page 26: Limited Warranty Statement
Products which are sold but not manufactured by Luminor are subject to the warranty provided by the manufacturer of said products and not by Luminor’s warranty. Luminor will... -
Page 27: Warranty Registration
Unless otherwise provided, the Dealer or Distributor will contact Luminor for instructions on returning the product. Any defective product to be returned to Luminor must be sent freight prepaid; documentation supporting the warranty claim and/or a Return Goods Authorization must be included if so instructed. - Page 28 Luminor Environmental Inc. 80 Southgate Drive, Unit 4 Guelph, Ontario, CANADA N1G 4P5 519-837-3800 TF: 855-837-3801 F: 519-837-3808 info@luminoruv.com luminoruv.com PN: 910114 RevI / 05-25 Certified to NSF/ANSI/CAN 372 Certifié NSF / ANSI / CAN 372...
