- Page 1 Operation & Installation Instructions LBH4-PS LBH4-PL LUMINOR - Standard Systems System Rated Flow System Rated Flow LBH4-PS 42 gpm LBH4-PS 82 gpm illuminating technologies for life...
- Page 2 Congratulations on purchasing this ultraviolet disinfection system. By purchasing a LUMINOR UV Disinfection system you are receiving not only a high quality product but also peace of mind. Installing a UV system gives you reassurance that the water in your home will have an extra level of protection.
-
Page 3: Table Of Contents
Lamp Countdown Sequence .................. 11 Lamp Replacement ....................12 System Troubleshooting..................12 System Specifications ....................... 13 Limited Warranty Statement .................... 14 Warranty Registration ...................... 15 Note: These instructions are also available in soft copy via email from Luminor Customer Service. P a g e... -
Page 4: Safety Considerations
Safety Considerations It is important that care is taken when operating and/or maintaining your system. Please read the instructions • The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 5: Before You Begin
Before You Begin The following will be needed for installing the UV system: Tools • Pipe cutter, hacksaw or other specialized tools required to cut into your existing plumbing (e.g. if you have PEX piping) • Soldering tools (torch, flux, emery cloth and solder) •... -
Page 6: Assembly
RCHO-4.12P O-RING 300038 Pressure Test Plug 390110 Optional Mounting Hardware UV LAMP 390078 (2 screws) 390071 (2 clamps) RL-600HO (LBH4-PS Series) RL-950HO (LBH4-PL Series) *not included POWER CABLE SLEEVE SPRING 260004 310039 North American QUARTZ SLEEVE RQ-600 OUTLET... -
Page 7: Location
Recommended Placement LUMINOR SALT CELL OR PUMP FILTER HEATER CHLORINATOR Figure 1. Diagram of flow FLOW RATES For detailed flow rates see page 13. LOCATION Place UV system in an area to ensure there is enough space at the lamp connector end to safely remove the UV lamp and/or quartz sleeve (Figure 2). -
Page 8: Installation
INSTALLATION The chamber can be installed either horizontally or vertically. Vertical installation is the preferred method with the inlet at the bottom (lamp connection at the top). If installing horizontally additional mounting hardware is required. The use of a by-pass assembly is recommended as it will allow you to isolate the UV chamber. This will allow for easier access in case maintenance is required. -
Page 9: Cleaning The Quartz Sleeve
Step 6: Carefully remove the lamp from its packaging. Always hold UV lamps by their ceramic ends. Gently lower lamp into quartz sleeve. Figure 5. UV Lamp Connection Step 7: Plug the LUMI-Loc™ lamp connector into the lamp. Note the keying for proper alignment (see Figure 5). Insert the lamp connector into the gland nut and turn the connector approximately ¼... -
Page 10: Winterization
Step 6: Being careful to touch only the ceramic ends, remove the lamp out of the chamber. Step 7: Unscrew the gland nut from the chamber exposing the end of the quartz sleeve. Step 8: Carefully remove the quartz sleeve and o-ring by gently twisting and pulling the quartz sleeve. -
Page 11: Operation
OPERATION Pool UV systems come with a feature laden controller that incorporates both the lamp driver (ballast) and control features in a fully sealed case to prevent water intrusion. Controllers feature a built in lamp monitor, with both audible and visual indication of lamp life, and auto sensing dual voltage for plug in or hard wired use. -
Page 12: Lamp Replacement
At any point during this sequence, the audible chirp or alarm can be deferred for seven days by holding the controller button down for a period of five seconds. The number of deferrals used will be displayed as below. Once the deferral expires, the alarm will sound once again. The deferral can be repeated up to three times. -
Page 13: System Specifications
SYSTEM SPECIFICATIONS Model PV2-42C PV2-82C 42 GPM 82 GPM Flow Rate 159 lpm 310.4 lpm 16mJ/cm2 @ 95% UVT 9.5 m 18.6 m Port Size 1.5” MNPT 2” MNPT Electrical 90-265V/50-60Hz. (IEC power cord included) Plug Type NEMA 5/15 Lamp Watts Replacement Lamp RL-600HO RL-950HO... -
Page 14: Limited Warranty Statement
LUMINOR are subject to the warranty provided by the manufacturer of said products and not by LUMINOR’s warranty. LUMINOR will not be liable for damage or wear to products caused by abnormal operating conditions, accident, abuse, misuse, unauthorized al- teration or repair, or if the product was not installed in accordance with LUMINOR’s printed... -
Page 15: Warranty Registration
FOR WARRANTY SERVICE To obtain service under this warranty, you must first contact LUMINOR Customer Service at 1-855-837-3801 (519-837-3800 outside of the US or Canada) to obtain a Warranty Return Authorization. You will then need to return the product through the LUMINOR Dealer or Distributor where the product was originally purchased, together with proof of purchase and installation date, failure date, and supporting installation data. - Page 16 illuminating technologies for life 80 Southgate Drive, Unit 4 Guelph, Ontario, CANADA N1G 4P5 P: 519-837-3800 TF: 855-837-3801 F: 519-837-3808 info@luminoruv.com www.luminoruv.com PN: 910443 Version Date: 11-2021...
