R A I N I E R
Operation & Installation
R A I N I E R
Instructions
R A I N I E R
R A I N I E R
Series
ILLUMINATING
TECHNOLOGIES
FOR LIFE
4.0
5.0
6.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAINIER and is the answer not in the manual?

Questions and answers

Summary of Contents for Luminor RAINIER

  • Page 1 R A I N I E R Series Operation & Installation R A I N I E R Instructions R A I N I E R R A I N I E R ILLUMINATING TECHNOLOGIES FOR LIFE...
  • Page 2: Table Of Contents

    Table of Contents Product Matrix ......................1 Safety Considerations ....................2 Before You Begin ......................3 Water Quality Parameters................... 3 Assembly ........................4 System Sizing ......................5 Installation Location ....................5 Considerations Before Installation ................6 Installation ........................7 System Preparation ....................9 Cleaning the quartz sleeve ..................
  • Page 3: Product Matrix

    Product Matrix “Normal” LOW UVT 30 mJ/cm 30 mJ/cm 150 mJ/cm SYSTEM @ 95% UVT @ 50% UVT @ 95% UVT 1-lamp LR5-35X LR5-35X LR5-35X-TOC “35” series LR6-35X LR6-35X-50 LR6-35X-TOC 1-lamp LR5-55X LR5-55X LR5-55X-TOC “55” series LR6-55X LR6-55X-50 LR6-55X-TOC 1-lamp LR5-85X LR5-85X LR5-85X-TOC...
  • Page 4: Safety Considerations

    • The system should be directly installed into a ground fault circuit interrupter (GFCI). Please note that for 230 volt RAINIER products, special High-current GFCI’s (GFI’s) are required. These special GFCI’s can easily be obtained through an electrical supply house, or are readily available from a local spa/hot tub supply store as they are commonly used in these applications.
  • Page 5: Before You Begin

    Tannins (organics): <0.1 ppm (0.1 mg/L) UVT (transmittance): >85% (Please contact LUMINOR if water has a UVT that is less than 80% for pre-treatment recommendations) You can have your water tested at a private analytical laboratory or by your local dealer.
  • Page 6: Assembly

    260006 Australian/New Zealand, 310206 (2 for 1-lamp, 4 for 2-lamp) AS/NS 3112 O-RING 260004 North American NEMA 5-15, (110V.) 310043 GLAND NUT Note: see specification table 310042 Closed End for specialty applications Figure 1. RAINIER System Components P a g e...
  • Page 7: System Sizing

    System Sizing All LUMINOR UV systems are rated for a specific flow rate in water that meets the quality parameters. PLEASE NOTE: increasing the flow above this rating or treating water that does not meet the quality parameters will decrease the dose and therefore compromise the efficacy of the system.
  • Page 8: Considerations Before Installation

    RAINIER system is not exceeded and the UV dose is not compromised. The flow restrictor should be installed on the outlet port of the reactor.
  • Page 9: Installation

    Although there are many methods of installation, this manual will provide a recommended procedure using copper plumbing and standard soldering methods. LUMINOR recommends the use of unions, a bypass assembly and shut-off valves as this will allow you to isolate and remove the UV reactor if necessary (this is a recommended method only as it allows for the maximum convenience but it requires extra components and more time for installation).
  • Page 10 Step 5: The reactor is now ready for water flow. When all plumbing connections have been completed you should check for any possible leaks. Slowly turn on the water supply and check for leaks. Make sure that any bypass valves are functioning properly and that the water is flowing through the reactor.
  • Page 11: System Preparation

    Care & Maintenance System Preparation With a new installation, or any time the UV system is shut down for service, without power, or is inoperative for any other reason, the lines in the home or facility could be contaminated. Use the following steps to prepare the lines throughout the entire facility.
  • Page 12: Cleaning The Uv Sensor

    Step 8: While holding on to both ends of the sleeve carefully remove the o-ring from the end opposite from the lamp connection and then pull the quartz sleeve out of the reactor (ensure that no water enters the inside of the quartz sleeve); remove second o-ring Step 9: Using a soft, lint-free cloth or towel, wipe the sleeve down using a commercial scale cleaner (i.e.
  • Page 13: Operation - Control Panel

    Operation The RAINIER system comes with a feature laden control system that incorporates both the lamp driver (ballast) and control features in one modular panel. The LED display indicates remaining lamp life and total running hours, and has audible and visual warings for lamp failure. With the...
  • Page 14: Operation - Power-Up

    If any water does pass through the UV system during this period, please follow the preparation procedure as outlined in this manual before the water is consumed. The RAINIER LR5 system does not measure the level of disinfection; it simply measures the “ON-OFF” status of the lamp. Please have your water checked for microbiological contaminants on a regular basis.
  • Page 15: Operation - Major & Minor Alarm Set Points

    Installation for instructions on installing the new lamp. After changing the lamp on the RAINIER systems, the control panel must be reset in order for the system to begin its countdown function on the newly installed lamp. To reset, simply press and hold down the button located directly beneath the top LED screen for fifteen seconds.
  • Page 16: System Troubleshooting

    System Troubleshooting The RAINIER control panel continuously monitors your UV system and if there is a problem with the system the panel will provide both a visual and audible signal indicating the specific fault that it is detecting. The fault conditions are listed in a...
  • Page 17: Expansion Options

    Expansion Options Although features such as remote-on, system ready and fault dry contacts, and 4-20 mA output are built into the control panel, they require an optional cable as below. Remote Monitoring Cable (for both 4-20mA and remote monitoring options) Part # 210010 Includes connector and 10m (33’) of cable to provide both a 4-20 mA signal, dry contacts for system ready, fault signals and 24V DC remote-on input to a remote...
  • Page 18: Specifications

    1 6 | P a g e...
  • Page 19 1 7 | P a g e...
  • Page 20: Warranty Registration

    (proper documentation required for verification). LUMINOR warrants that it will repair, replace or refund, at LUMINOR’s sole option, any ultraviolet system or component that is defective in materials or workmanship for the period as outlined above, subject to the “Limitations of Warranty”...
  • Page 21: Limited Warranty Statement

    BEYOND THOSE WARRANTIES DESCRIBED OR REFERRED TO ABOVE. THIS LIMITED WARRANTY IS THE SOLE AND EXCLUSIVE WARRANTY MADE BY LUMINOR WITH RESPECT TO THE PRODUCT, AND IS GIVEN IN LIEU OF ANY OTHER WARRANTY. TO THE EXTENT ALLOWED BY APPLICABLE LAW, ANY AND ALL EXPRESS...
  • Page 22 2 0 | P a g e...
  • Page 23 2 1 | P a g e...
  • Page 24 LUMINOR Environmental Inc. 80 Southgate Drive, Unit 4, Guelph, Ontario, CANADA N1G 4P5 Phone: (519) 837-3800 | Toll Free: (855) 837-3801 | Fax: (519) 837-3808 info@luminoruv.com www.luminoruv.com LUMINOR Environmental LuminorUV LuminorUV EPA Establishment PN: 910008 #088776-CAN-001 Version Date: 03-2023...
