Assa Abloy Norton 8000 Series Installation Instructions Manual

ASSA ABLOY
Left Hand Door - LH
Right Hand Reverse - RHR
• "DA" suffix (Delayed Action) is an optional feature.
• NOTE: For special applications a separate door and frame preparation template is packed with these instructions.
Use this instruction sheet for installation sequence and closer adjustments only.
• Doors should be hung on ball bearing or anti-friction hinges.
• A separate door stop is recommended.
• Door and frame must be properly reinforced.
• Always adjust spring power before adjusting control valves.
• Adjust closing time speed between 3 and 7 seconds from 90° to 0°. Greater closing times may be required for
elderly or handicapped.
• These door closers should NOT be installed on the exposed side (weather side) of exterior doors.
Copyright © 2004, 2014 Yale Security Inc., an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
Installation Instructions
An Incorrectly installed or improperly
adjusted door closer can cause property
!
damage or personal injury. These
installation instructions should be followed
to avoid the possibility of misapplication or
misadjustment.
1
8000 Series
Non Handed Door Closer
Non Hold Open Models
Parallel Arm Installation
Adjustable (Sizes 1 thru 6)
P8101
P8301
P8501
Right Hand Door - RH
Left Hand Reverse - LHR
80-9380-2219-020 (09-14)
