  • Page 1 PRESTIGIO NOBILE 141 TECHNICAL SERVICE MANUAL...

  • Page 2: Table Of Contents

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Contents 1. Hardware Engineering Specification ………………………………………………………………… 1.1 Introduction …………………………………………………………………………………………………………. 1.2 Other Functions ……………………………………………………………………………………………………. 1.3 Peripheral Components ……………………………………………………………………………………………. 1.4 Power Management ………………………………………………………………………………………………… 1.5 Appendix 1 : Intel 82801DBM ICH4-M GPIO Definitions ……………………………………………………… 1.6 Appendix 2 : Product Specification …….......……………………………………………………………...
  • Page 3 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Contents 5.3 Intel 82801DBM I/O Controller Hub Mobile (ICH4-M) ………………………………………………………… 6. System Block Diagram ……………………………………………………………………………….. 7. Maintenance Diagnostics ……………………………………………………………………………… 7.1 Introduction ………………………………………………………………………………………………………… 7.2 Error Codes ………………………………………………………………………………………………………… 7.3 Debug Tool ………………………………………………………………………………………………………….. 8. Trouble Shooting ………………………………………………………………………………………...
  • Page 4 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Contents 8.13 IEEE1394 Failure ………….……………………………………………………………………………………… 9. Spare Parts List ……………………………………………………………………………………….. 10. System Exploded Views ……………………………………………………………………………… 11. Circuit Diagram ……………………………………………………………………………………… 12. Reference Material …………………………………………………………………………………...

  • Page 5: Hardware Engineering Specification

    This document describes the brief introduction for Prestigio Nobile 141 portable notebook computer system. 1.1.2 System Overview The Prestigio Nobile 141 model is designed for Intel Banias processor with 400MHz FSB with Micro-FCPGA package. It can support Banias 1.3GHz ~ 1.7GHz.
  • Page 6 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL The Montara-GM GMCH Host Memory Controller integrates a high performance host interface for Intel Banias processor, a high performance 2D/3D Graphic Engine, a high performance memory controller, Digital Video port (DVOB & DVOC) interface, and Intel Hub interface Technology connecting with Intel 82801DBM ICH4-M.
  • Page 7 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL The NS PC87393 LPC Super I/O device is targeted for a wide range of portable applications. PC99 and ACPI compliant, it also incorporates: a Floppy Disk Controller (FDC), two enhanced Serial Ports (UARTs), one with Fast Infrared (FIR, IrDA 1.1 compliant), General-Purpose Input/Output (GPIO) support for a total of 32 ports, Interrupt...

  • Page 8: System Parts

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Support is provided for Macrovision and RGB bypass mode which enable driving a VGA CRT with the input data. The H8/F3437 is a high performance microcontroller with a fast H8/300 CPU core and a set of on-chip supporting functions optimized for embedded control.

  • Page 9: Cpu Module

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL LAN single chip : VT6105LOM PCMCIA controller : ENE CB710 AC’97 Codec : STAC9750 Thermal sensor : ADM1021A System Flash Memory (BIOS) 1.1.2.1 CPU Module Intel Banias Processors with 478 pins Micro-FCPGA package. The first Intel mobile processor with the Intel NetBurst micro-architecture which features include hyper-pipelined technology, a rapid execution engine, a 400MHz system, an execution trace cache, advanced dynamic execution, advanced transfer cache, enhanced floating point and multi-media unit, and Streaming SIMD Extensions 2 (SSE2).
  • Page 10 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.2 Synthesizer System frequency synthesizer: ICS950810 Programmable output frequency, divider ratios, output rise/fall time, output skew. Programmable spread percentage for EMI control. Watchdog timer technology to reset system if system malfunctions. Programmable watchdog safe frequency.
  • Page 11 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL A high bandwidth and mature Intel®’ I/O Hub architecture is incorporated to connect Montara-GM GMCH and Intel 82801DBM ICH4-M together. Intel® I/O Hub architecture is developed into three layers, the Multi-threaded I/O Link Layer delivering 1.2GB bandwidth to connect embedded DMA Master devices and external PCI masters...

  • Page 12: Memory System

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - Support for DPWR# signal to Banias processor for PSB power management Memory System - Directly supports one DDR channel, 64-bts wide (72-b with ECC). - Supports 200-MHz and 266-MHz DDR devices with max of 2 Double-Sided SO-DIMMs(4 rows populated) with unbuffered PC1600/PC2100 DDR(with ECC).
  • Page 13 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - Video Overlay - Single high quality scalable overlay and second Sprite to support second overlay - Multiple overlay functionality provided via Arithmetic Stretch Blt - Direct YUV from Overlay to TV-out - Independent Gamma Correction...
  • Page 14 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - Dedicated LFP (local flat panel) interface -- Single or dual channel LVDS panel support up to SXGA+ panel resolution with frequency range from 25MHz to 112MHz per channel -- SSC support of 0.5%, 1.0%, and 2.5% center and down spread with external SSC clock...
  • Page 15 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - 8-bit, 16-bit, and 32-bit color - ROP support - DIB translation and Linear/Title addressing - 3D Graphics Engine - 3D Setup and Render Engine - Viewpoint Transform and Perspective Divide - Triangle Lists, Strips and Fans support...
  • Page 16 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - Bilinear, Trilinear, Anisotropic MIP-Mapped Filtering - Cubic Environment Reflection Mapping - Embossed Bump-mapping - DXTn Texture Decompression - 3D Graphics Rasterrization enhancements - One Pixel per Clock - Flat and Gouraud Shading - Color Alpha Blending for Transparency...

  • Page 17: Hub Interface For Ich4

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL HUB Interface for ICH4 - 266 MB/s point to point hub interface to ICH4-M - 66-M Hz base clock - Supports the following traffic types to the ICH4-M - Hub interface-to DRAM - CPU-to-Hub interface...
  • Page 18 16-bit counters channels 5-7, hardwired keyboard controller and PS2 mouse interface(not use in Nobile 141 model), Real Time clock with 512Bytes CMOS SRAM and two 82C59 compatible Interrupt controllers. Besides, the I/O APIC managing up to 14 interrupts with both Serial and FSB interrupt delivery modes is...
  • Page 19 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL The integrated power management module incorporates the ACPI 1.0b compliance functions, the APM 1.2 compliance functions, and the PCI bus power management interface spec. v1.1. Numerous power-up events and power down events are also supported. 21 general purposed I/O pins are provided to give an easy to use logic for specific application.
  • Page 20 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Ultra ATA/100/66/33, BMIDE and PIO modes Tri-state modes to enable swap bay Includes three UHCI host controllers that support six external ports New: Includes one EHCI high-speed USB 2.0 Host Controller that supports all six ports New: Supports a USB 2.0 high-speed debug port...
  • Page 21 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Supports serial interrupt protocol Supports processor system bus interrupt delivery New: 1.5 V operation with 3.3 V I/O 5 V tolerant buffers on IDE, PCI, USB over current and legacy signals Timers Based on 82C54 System timer, refresh request, speaker tone output Power Management Logic ACPI 2.0 compliant...
  • Page 22 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.5 CH7011A The CH7011 is a Display controller device which accepts a digital graphics input signal, and encodes and transmits data to a TV output (analog composite, s-video or RGB). The device accepts data over one 12-bit wide variable voltage data port which supports five different data formats including RGB and YCrCb.The TV-Out processor will...
  • Page 23 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Fully programmable through serial port Complete Windows and DOS driver support Low voltage interface support to graphics device 1.1.2.6 Super I/O_NS PC87393 National Semiconductor’s PC8739x family of LPC Super I/O devices is targeted for a wide range of portable applications.

  • Page 24: Keyboard Controller Hitachi H8/3437

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.7 Keyboard controller Hitachi H8/3437 The H8/3437 Series is a series of high-performance micro-controllers with a fast H8/300 CPU core and a set of on- chip supporting functions optimized for embedded control. These include ROM, RAM, four types of timers, a serial...
  • Page 25 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 32bit PCI Bus-Master Interface VIA Rhine based CSR definition provides efficiency PCI bus-mastering Low power 100base-TX transceiver embedded Support 10Mbps and 100Mbps N-way Auto-negotiation operation Support Auto-MDIX function Enhancement MAC functions for 802.3 networking 802.1 Priority Transmit Maximum eight priority queues by drivers programmable 802.1q Multiple VLAN support VLAN long frames support (1518+4bytes) VLAN tag...

  • Page 26: Fax/Modem Module

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.9 Fax/Modem module Made by Billionton Computer corporation Integrated PCI v2.2 Interface Host-based ITU V.70 DSVD. Operation support: Windows 95/NT/ME/2000 K56flex for internet connection rates approaching 56kbits/s. Data Modes capabilities On Chip PnP Logic ACPI support “On Now”...

  • Page 27: Cardbus Controller

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.10 PCMCIA controller_ ENE CB710 + ENE CP2211 CB710 It’s function as a signal-slot PCI-to-Cardbus bridge and also PCI-interface smart card and MS/SD/SM flash card readers. Features : One Cardbus slot and all reader interfaces may operate simultaneously.
  • Page 28 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - Support 4-bit data lines, write protect switch, card detection by DAT3 or a dedicated switch. • Memory Stick (MS) Reader: - Compliant with Memory Stick Standard Format Specification Version 1.3 - Max 2.5MBps data rate with 16-byte data buffer and optional clock source.
  • Page 29 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.11 AC”97 Codec _ STAC9750 High performance CODEC with high S/N ratio (>90 dB). Compliant with AC’97 2.2 specifications 20-bit stereo Digital-to-Analog Converter with variable sampling rate. 20-bit stereo Analog-to-Digital Converter with variable sampling rate.
  • Page 30 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.12 Thermal Sensor_ ADM1021A On-Chip and Remote Temperature Sensing No Calibration Necessary 1_C Accuracy for On-Chip Sensor 3_C Accuracy for Remote Sensor Programmable Over/Under Temperature Limits Programmable Conversion Rate 2-Wire SMBus Serial Interface Supports System Management Bus (SMBus) Alert...

  • Page 31: System Flash Memory (Bios)

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.1.2.13 System Flash Memory (BIOS) 4M bit Flash memory Flashed by 5V only User can upgrade the system BIOS in the future just running flash program. 1.1.2.14 IEEE1394a Controller VT6307L The VIA Fire IIM VT6307 is a single-chip, low power 2-port IEEE 1394 host controller providing PC systems with high speed, flexible connectivity to a wide range of peripherals and consumer electronics.
  • Page 32 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL - Full 1394a P2000 support - Logic performs bus initialization and arbitration functions - 2KV ESD protection 32-Bit Power-Managed PCI Bus-Interface - Compliant with PCI specification v2.2 - Supports CardBus interface Supports I2C EEPROM and 4-Wire Serial ROM with GUID PROM Shadow to EEPROM...

  • Page 33: Other Functions

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.2 Other Functions 1.2.1 Hot Key Function Keys Feature Meaning combination Fn + F1 Reserve Fn + F2 Reserve Fn + F3 Volume Down Fn + F4 Volume Up Fn + F5 LCD/External CRT...

  • Page 34: Power On/Off/Suspend/Resume Button

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.2.2 Power On/Off/Suspend/Resume Button 1.2.2.1 APM Mode At APM mode, Power button is on/off system power. 1.2.2.2 ACPI Mode At ACPI mode. Power button behavior was set by windows power management control panel. You could set “standby” , “power off” or “hibernate”(must enable hibernate function in power management) to power button function.

  • Page 35: Led Indicators

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.2.4 LED Indicators System has eight status LED indicators to display system activity, which include three at front side and five above keyboard. 1.2.4.1 Three LED indicators on LCD panel: From left to right that indicate: AC POWER, BATTERY POWER and BATTERY STATUS.

  • Page 36: Battery Warning

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.2.4.2 Five LED indicators at front side: From left to right that indicates CD-ROM/HARD DISK DRIVE, NUM LOCK, CAPS LOCK and SCROLL LOCK. 1.2.5 Battery status 1.2.5.1 Battery Warning System also provides Battery capacity monitoring and gives user a warning so that users have chance to save his data before battery dead.

  • Page 37: Cmos Battery

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.2.6 Fan Power On/Off Management FAN is controlled by H8 embedded controller using ADM1021A to sense CPU temperature and PWM control fan speed. Fan speed is depended on CPU temperature. Higher CPU temperature faster Fan Speed.
  • Page 38 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.2.8 I/O Port One Power Supply Jack. One External CRT Connector For CRT Display One S-Video TV Output Connector Supports three USB2.0 port for all USB devices. One MODEM RJ-11 phone jack for PSTN line One RJ-45 for LAN.

  • Page 39: Peripheral Components

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.3 Peripheral Components 1.3.1 LCD Panel Source QDI 14.1” TFT: QD141X1LH03-MP01 Source: Chi-Mei 14.1 TFT : N141X6-L0 1.3.2 Ext. Floppy Disk Drive External USB 3.5” 1.44MB /1.2 MB/720KB FDD (Option) Source :Mitsumi D353FUE Source :NEC UF0002 1.3.3 HDD...

  • Page 40: Dvd-Rom Drive

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.3.5 DVD ROM Drive source :TEAC DV-28E-B93 source: QSI SDR-083 1.3.6 COMBO Drive source : KME UJDA730-MT-A source : QSI SBW-161(16X Combo) source : NEC CB2100A 1.3.7 Track Pad : Synaptics TM41PUM311-2 Accurate positioning...
  • Page 41 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Software configurable Low weight Operating temperature: 0 to 60 degree C Operating humidity : 5%-95% relative humidity, non condensing Storage temperature: -40 to +65 degree C ESD: 15KV applied to front surface SEE ESD Testing specification PN 520-000270-01 Power supply voltage : 5.0Voltage ±...

  • Page 42: Power Management

    1.4 Power Management The Prestigio Nobile 141 system has built in several power saving modes to prolong the battery usage for mobile purpose. User can enable and configure different degrees of power management modes via ROM CMOS setup (booting by pressing F2 key).

  • Page 43: Standby Mode

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.4.1.3 Standby Mode For more power saving, it turns of the peripheral components. In this mode, the following is the status of each device: CPU: Stop grant LCD: backlight off HDD: spin down 1.4.1.4 Suspend to DRAM and HDD The most chipset of the system is entering power down mode for more power saving.

  • Page 44: Other Power Management Functions

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.4.2 Other Power Management Functions 1.4.2.1 HDD & Video Access System has the ability to monitor video and hard disk activity. User can enable monitoring video and/or hard disk individually. When there is no video and/or hard disk activity, system will enter next PMU state depending on the...

  • Page 45: Appendix 1: Intel 82801Dbm Ich4-M Gpio Definitions

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.5 Appendix 1: Intel 82801DBM ICH4-M GPIO Definitions Pin Name MUX Function GPIO Function Power Plane Pin Name MUX Function GPIO Function Power Plane GPIO0 CRT_IN# MAIN GPIO23 MAIN GPIO1 MAIN GPIO24 PCLKRUN# GPIO...

  • Page 46: Appendix 2 : Product Specification

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 1.6 Appendix 2: Prestigio Nobile 141 Product Specification - Intel Banias Processor CPU Support 1.4GHz ~ 1.7GHz or above - FSB 400MHz Chipset - Montara-GM + ICH4-M L2 Cache - 1M System BIOS - Flash EPROM (Include System BIOS and VGA BIOS) - ACPI 1.0b;...
  • Page 47 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Continued to the previous table - Sound Blaster Pro compatible - Built-in mono microphone - Support AC97 2.1 Audio System - 2X Speakers (2 Watt each) - Standard USB2.0 port x 3 I/O Port...

  • Page 48: System View And Disassembly

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2. System View and Disassembly 2.1 System View 2.1.1 Front View Hold Switch Audio Play Button Card Reader Slot Audio Output Microphone Input Top Cover Latch 2.1.2 Left-side View Power Jack VGA Port S-Video Output Connector...

  • Page 49: Right-Side View

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.1.3 Right-side View CD-ROM/DVD-ROM Drive USB Port 1394 Port IR Module 2.1.4 Rear View RJ-11 Connector Battery Charging LED Indicator Battery Power LED Indicator AC Power LED Indicator...

  • Page 50: Bottom View

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.1.5 Bottom View Extend SO-DIMM Cover CPU Cover Hard Disk Drive Cover Battery Pack 2.1.6 Top-open View LCD Screen Stereo Speaker Battery Pack Power Button Keyboard Touch Pad Device Indicators...

  • Page 51: System Disassembly

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2 System Disassembly The section discusses at length each major component for disassembly/reassembly and show corresponding illustrations. Use the chart below to determine the disassembly sequence for removing components from the notebook. NOTE: 1. Before you start to install/replace these modules, disconnect all peripheral devices and make sure the notebook is not turned on or connected to AC power.
  • Page 52 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.1 Battery Pack 2.2.2 Keyboard 2.2.3 CPU Modular Components 2.2.4 HDD Disk Drive 2.2.5 CD/DVD-ROM Drive 2.2.6 DDR SDRAM 2.2.7 LCD Assembly 2.2.8 Inverter Board NOTEBOOK LCD Assembly Components 2.2.9 LCD Panel 2.2.10 System Board Base Unit Components 2.2.11 Modem Card...

  • Page 53: Battery Pack

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.1 Battery Pack Disassembly 1. Carefully put the notebook upside down. 2. Pull the battery pack out of the compartment ( ) while sliding and holding the release levers outwards to the “unlock” ( ) position ( ).
  • Page 54 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.2 Keyboard Disassembly 1. Remove the battery pack. (See section 2.2.1 Disassembly) 2. Open the top cover. Remove three screws fastening the keyboard. (Figure 2-2) Figure 2-2 Remove three screws Figure 2-3 Disconnect the cable 4.
  • Page 55 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.3 CPU Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove five screws fastening the heatsink and DDR SDRAM’s compartment covers. (Figure 2-4) Figure 2-4 Remove five screws Figure 2-5 Remove the CPU compartment cover 4.
  • Page 56 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5. Remove four spring screws fastening the heatsink. (Figure 2-6) Figure 2-6 Unscrew four screws Figure 2-7 Disconnect the fan’s cord 6. Disconnect the fan’s power cord to detach the heatsink from the CPU compartment. (Figure 2-7)
  • Page 57 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 7. Loosen the screw by a flat screwdriver,upraise the CPU socket to unlock the CPU. (Figure 2-8) Figure 2-8 Remove the CPU Reassembly 1. Carefully, align the arrowhead corner of the CPU with the beveled corner of the socket, then insert CPU pins into the holes.

  • Page 58: Hdd Module

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.4 HDD Module Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove two screws fastening the HDD compartment cover. Then sliding it outward. (Figure 2-9)
  • Page 59 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5. Unscrew four screws to remove the hard disk drive from the holding. (Figure 2-11) Figure 2-11 Free the hard disk Reassembly 1. Fit the hard disk drive into the holding and secure with four screws.

  • Page 60: Cd/Dvd-Rom Drive

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.5 CD/DVD-ROM Drive Disassembly Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Pull the CD/DVD-ROM out of the compartment ( ) while sliding and holding the release lever outwards to the “unlock”...

  • Page 61: Ddr Sdram

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.6 DDR SDRAM Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove one screw to access the DDR-SARAM’s socket. (Figure 2-13) 4. Pull the retaining clips outwards ( ) and remove the SO-DIMM ( ). (Figure 2-14)

  • Page 62: Lcd Assembly

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.7 LCD Assembly Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove nine screws. (Figure 2-15) 4. Remove the heatsink. (See the steps 3, 4, 5 of section 2.2.3 Disassembly) 5.
  • Page 63 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 6. Carefully turnover the notebook. Close the top cover, remove three hinge covers. Then lift up the LCD ASSY. (Figure 2-17) Figure 2-17 Remove the hinge covers Reassembly 1. Replace the LCD Assembly and reconnect two wires.

  • Page 64: Inverter Board

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.8 Inverter Board Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove the LCD Assembly. (See section 2.2.7 Disassembly) 4. Remove the five rubber pads and five screws. (figure 2-18) 5.
  • Page 65 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Reassembly 1. Fit the inverter board back into place and secure with two screws, and reconnect the wire to the inverter board. . 2. Fit the LCD top cover back into the housing and secure with five screws and five rubber pads 3.
  • Page 66 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.9 LCD Panel Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove the LCD Assembly. (See section 2.2.7 Disassembly) 4. Remove the inverter board. (See section 2.2.8 Disassembly) 5.
  • Page 67 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Reassembly 1. Attach the LCD panel holding to panel and secure with six screws. 2. Fit the LCD panel into place and secure with four screws. 3. Replace the inverter board. (See section 2.2.8 Reassembly) 4.

  • Page 68: System Board

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.10 System Board Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove the keyboard, CPU, hard disk drive, CD/DVD-ROM drive, DDR-SDRAM and LCD Assembly. (See the previous sections Disassembly) 4.
  • Page 69 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 6. Carefully, turnover the notebook. Then remove seven screws. (Figure 2-24) Figure 2-24 Unscrew seven screws Figure 2-25 Disconnect the cord 7. Lift notebook up carefully. Disconnect the speaker’s cord. (Figure 2-25)
  • Page 70 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8. Disconnect the touch pad’s cable. Then lift up the system top cover. (Figure 2-26) Figure 2-27 Unscrew screws and hex nuts Figure 2-26 Disconnect the cable 9. Remove five screws and two hex nuts beside the VGA port. Now you can lift up system board from housing.
  • Page 71 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Reassembly 1. Fit the system board back into housing and secure with five screws and two hex nuts. 2. Reconnect the touch pad’s cable to system board. 3. Reconnect the speaker’s cord to system board.

  • Page 72: Modem Card

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.11 Modem Card Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove the keyboard, CPU, hard disk drive, CD/DVD-ROM drive, DDR-SDRAM and LCD Assembly. (See the previous sections Disassembly) 4.

  • Page 73: Touch Pad

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 2.2.12 Touch Pad Disassembly 1. Carefully put the notebook upside down. 2. Remove the battery pack. (See section 2.2.1 Disassembly) 3. Remove the keyboard, CPU, hard disk drive, CD/DVD-ROM drive, DDR-SDRAM and LCD Assembly. (See the previous sections Disassembly) 4.
  • Page 74 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Reassembly 1. Fit the touch pad panel and click holder 2. Then fit the touch pad bracket and secure with four screws. 3. Reassemble the notebook. (See the previous sections Reassembly)

  • Page 75: Definition & Location Of Connectors / Switches

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 3. Definition & Location of Connectors / Switches 3.1 Main Board (Side A) – 1 PJ501 : AC Power Jack J509 J506 J501 : Battery Connector J518 J501 J502 : Fan Connector J519 J520...
  • Page 76 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 3. Definition & Location of Connectors / Switches 3.1 Main Board (Side A) – 2 ------ Continued to previous page ------ J511 : RTC Battery Connector J509 J506 J512 : USB Port Connector J518...

  • Page 77: Main Board (Side B)

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 3. Definition & Location of Connectors/ Switches 3.1 Main Board (Side B) J1 : Internal Keyboard Connector J2 : Touch-Pad Connector J3 : MDC Jump Wire Connector J4 : Primary EIDE Connector SW2 : LCD ID Select Switch...

  • Page 78: Dc To Dc Board

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 3. Definition & Location of Connectors / Switches 3.2 DC to DC Board J1 : DC to DC Board Connector J2 : Modem Daughter Board (MDC) Connector J3 : USB Port Connector J4 : Right Internal Speaker Connector...

  • Page 79: Definition & Location Of Major Components

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 4. Definition & Location of Major Components 4.1 Main Board (Side A) U501 : Intel Banais Micro-FCPGA Processor U502 : Intel 82855GM GMCH U504 U511 U504 : H8/F3437 Micro Controller U509 U509 : STAC9570 Audio Codec...
  • Page 80 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 4. Definition & Location of Major Components 4.1 Main Board (Side B) U3 : Intel 82801DBM ICH4-M U4 : PLL207-151 Clock Generator U7 : CH7011A TV Encode U9 : VT6307 IEEE1394 Controller U11 : LF-H80P LAN Buffer U15 : VT6105-LOM LAN Controller U17 : CB710 CardBus &...

  • Page 81: Pin Description Of Major Component

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5. Pin Descriptions of Major Components 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description A[31:3]# (Address) define a 2 32 -byte physical memory address space. BPRI# (Bus Priority Request) is used to arbitrate for ownership of the...
  • Page 82 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description DBSY# (Data Bus Busy) is asserted by the agent responsible for driving DPWR# is a control signal from the Intel 855PM and Intel 855GM...
  • Page 83 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description INIT# (Initialization), when asserted, resets integer registers inside the PWRGOOD (Power Good) is a processor input. The processor requires INIT# PWRGOOD processor without affecting its internal caches or floating-point registers.
  • Page 84 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.1 Intel Pentium M Processor Signal Name Type Description Signal Name Type Description Processor core power supply. SMI# (System Management Interrupt) is asserted asynchronously by SMI# VCCA provides isolated power for the internal processor core PLL’s.

  • Page 85: Intel 82855Gm Memory Controller Hub (Gmch)

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.2 Intel 82855GM Graphics and Memory Controller Hub (GMCH) Host Interface Signals Signal Name Type Description Signal Name Type Description Address Strobe: The system bus owner asserts ADS# to indicate Dynamic Bus Inversion: Driven along with the HD[63:0]# signals.
  • Page 86 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.2 Intel 82855GM Graphics and Memory Controller Hub (GMCH) Host Interface Signals (Continued) Signal Name Type Description Signal Name Type Description Host Request Command: Defines the attributes of the request. Write Enable: Used with SCAS# and SRAS# (along with SCS#) to...
  • Page 87 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.2 Intel 82855GM Graphics and Memory Controller Hub (GMCH) Hub Interface Signals Signal Name Type Description Signal Name Type Description Packet Data: Data signals used for HI read and write operations. Differential DVO Clock Output: These pins provide a differential HI_[10:0] DVOCC.LK...
  • Page 88 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.2 Intel 82855GM Graphics and Memory Controller Hub (GMCH) Dedicated LVDS LCD Flat Panel Interface Signals (Continued) Digital Video Output C (DVOC) Port Signals Signal Name Type Voltage Description Signal Name Type Description 1.25 V±...
  • Page 89 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.2 Intel 82855GM Graphics and Memory Controller Hub (GMCH) Analog CRT Display Signals Signal Name Type Description GPIO I/F Total Type Comments CRT Vertical Synchronization: This signal is used as the vertical SSC Chip Clock Control: Can be used to control an external clock...
  • Page 90 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.2 Intel 82855GM Graphics and Memory Controller Hub (GMCH) Voltage Reference, PLL Power Signals Signal Name Type Description Signal Name Type Description Host Processor Hub Interface Analog Host RCOMP: Used to calibrate the Host AGTL+ I/O buffers.

  • Page 91: Intel 82801Dbm I/O Controller Hub Mobile (Ich4-M)

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Hub Interface Signals Firmware Hub Interface Signals Signal Name Type Description Signal Name Type Description Firmware Hub Signals. Muxed with LPC address signals. HI[11:0] Hub Interface Signals...
  • Page 92 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) PCI Interface Signals (Continued) Signal Name Type Description Signal Name Type Description Cycle Frame: The current Initiator drives FRAME# to indicate the Stop: STOP# indicates that the ICH4, as a Target, is requesting the...
  • Page 93 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) PCI Interface Signals (Continued) Signal Name Type Description Signal Name Type Description I/OD PCI Power Management Event: PCI peripherals drive PME# to Primary and Secondary IDE Device Data: These signals directly...
  • Page 94 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) IDE Interface Signals (Continued) LPC Interface Signals Signal Name Type Description Signal Name Type Description Primary and Secondary I/O Channel Ready (PIO): This signal LPC Multiplexed Command, Address, Data: For the LAD[3:0]...
  • Page 95 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Power Management Interface Signals Signal Name Type Description Signal Name Type Description LAN Reset: This signal must be asserted at least 10 ms after the...
  • Page 96 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Power Management Interface Signals (Continued) Signal Name Type Description Signal Name Type Description Deeper Sleep - Voltage Regulator: This signal is used to lower the...
  • Page 97 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) Processor Interface Signals (Continued) Real Time Clock Interface Signals Signal Name Type Description Signal Name Type Description CPU Power Good: This signal should be connected to the Special Crystal Input 1: This signal is connected to the 32.768 kHz crystal.
  • Page 98 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 5.3 Intel 82801DBM I/O Controller Hub 4 Mobile (ICH4-M) AC’97 Link Signals Power and Ground Signals Signal Name Type Description Signal Name Description AC ’97 Reset: This signal is a master hardware reset to external 3.3 V supply for core well I/O buffers.

  • Page 99: System Block Diagram

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 6. System Block Diagram U501 Thermal Sensor Intel Banais Processor ADM1021A Micro-FCPGA CRT Connector U502 200/266MHz Memory Controller LVDS TFT Flat Panel 200 pin DDR SO-DIMM Socket * 2 J520 DVOC TV S-Video Montara - GM...

  • Page 100: Maintenance Diagnostics

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Maintenance Diagnostics 7.1 Introduction Each time the computer is turned on, the system bios runs a series of internal checks on the hardware. This power-on self test (post) allows the computer to detect problems as early as the power-on stage. Error messages of post can alert you to the problems of your computer.

  • Page 101: Error Codes

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 7.2 Error Codes Following is a list of error codes in sequent display on the PIO debug board. Code POST Routine Description Code POST Routine Description Test keyboard Some type of lone reset Test keyboard controller...
  • Page 102 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 7.2 Error Codes Following is a list of error codes in sequent display on the PIO debug board. Code POST Routine Description Code POST Routine Description Special init of keyboard ctlr Configure the COMM and LPT ports...

  • Page 103: Debug Tool

    MB would not support Parallel Port, then we could not plug the Debug Card to PIO Port to get the Port 378 error code. For this cause, Nobile 141 MB have reserved eight LEDs that are parallel connection with PIO output lines (Figure 1), when the system BIOS write the error code to Port 378, the LEDs can show the messages.

  • Page 104: Trouble Shooting

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8. Trouble Shooting 8.1 No Power 8.2 No Display 8.3 VGA Controller Failure LCD No Display 8.4 External Monitor No Display 8.5 Memory Test Error 8.6 Keyboard (K/B) Touch-Pad (T/P) Test Error 8.7 Hard Driver Test Error 8.8 CD-ROM Driver Test Error...

  • Page 105: No Power

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. No Power Is the Check following parts and signals: notebook connected...
  • Page 106 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. DD_CPU Main Voltage Map +3V_FIR (D/D Board) PL6,PL7 PU501,PU504~PU507,PU509,PL506,PR35 +VCC_CORE +3VCLK66...
  • Page 107 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. PWR_VDDIN BAV70LT1 120Z/100M ADINP SI4835DY PR24 PJ501 SBM1040 BAV70LT1 6.5A/32VDC 120Z/100M...
  • Page 108 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. PQ504 PU1A PU1B SI4835DY SI4925DY SI4925DY PL501 PL502 PD503 120Z/100M 33UH...
  • Page 109 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. 120Z/100M J501 BATT 6.5A/32VDC 120Z/100M VDD5 0.1µ 0.1µ VDD5 301K PR504...

  • Page 110: No Display

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.2 No Display There is no display on both LCD and VGA monitor after power on although the LCD and monitor is known-good. No Display Monitor Replace monitor or LCD module or LCD. Board-level...
  • Page 111 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.2 No Display ****** System Clock Check ****** U501 R541 8.2K R121 HCLK_CPU MULTSEL0 R116 HCLK_CPU# VTT_PWRGD# Pentium-M 120Z/100M L517 +3VCLKCPU 46,50 J513, J514 R138 HCLK_MCH U502 L513 120Z/100M +3VCLKPCI 8,14 CLK_DDR[0:5] R130 HCLK_MCH#...
  • Page 112 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.2 No Display ****** Power Good & Reset Circuit Check ****** +VCCP +3V_P MAX809 U502 U501 PWROK RESET# HCPURST# MMBT3904L Memory VDD5 MAX809 Pentium-M BAW56 MCH_PCIRST# 100K Controller RESET# Montara-GM 100K VDD5 PWROK JL10...

  • Page 113: Vga Controller Failure Lcd No Display

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.3 VGA Controller Failure LCD No Display There is no display or picture abnormal on LCD although power-on-self-test is passed. VGA Controller Failure LCD No Display Check if 1. Confirm LCD panel or monitor is good U502, J505 are cold Re-soldering.
  • Page 114 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.3 VGA Controller Failure LCD No Display There is no display or picture abnormal on LCD although power-on-self-test is passed. J505 TXOUT[0:5]+ TXOUT]0:5]- TXCLKOUT[0,1]+ TXCLKOUT[0,1]+ SI4800DY mircoSMDC110 120Z/100M LCDVCC U502 C690 0.1µ 10µ 0.1µ...

  • Page 115: External Monitor No Display

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.4 External Monitor No Display There is no display or picture abnormal on CRT monitor, but it is OK for LCD. External Monitor No Display Check if 1. Confirm monitor is good and check...
  • Page 116 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.4 External Monitor No Display There is no display or picture abnormal on CRT monitor, but it is OK for LCD. J507 mircoSMDC110 D1FS4 120Z/100M DDC2B VGA_DDC2B R533 R508 2.2K 2.2K L506 120Z/100M CRT_DDDA...

  • Page 117: Memory Test Error

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.5 Memory Test Error Extend DDRAM is failure or system hangs up. Memory Test Error 1.If your system installed with expansion SO-DIMM module then check them for One of the following components or signals on the motherboard proper installation.
  • Page 118 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.5 Memory Test Error Extend DDRAM is failure or system hangs up. +1.25V_DDR RP14,RP16~RP19,RP21,RP23 RP24,RP26,RP27,RP29,RP30 RP32 56*8 R194,R200,R221,R231,R215 J513 RR219,R226 CKE [0:3], CS# [0:3], SMA [1,2,4,5], SMAB [1,2,4,5] CKE [0,1], CS# [0,1], SMA[1,2,4,5] NB_MA [0,3,6:12]...

  • Page 119: Keyboard (K/B) Touch-Pad (T/P) Test Error

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.6 Keyboard (K/B) Touch-Pad (T/P) Test Error Error message of keyboard or touch-pad failure is shown or any key does not work. Keyboard or Touch-Pad Test Error Check Re-soldering. U504, J1, J2 Board-level for cold solder?
  • Page 120 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.6 Keyboard (K/B) Touch-Pad (T/P) Test Error Error message of keyboard or touch-pad failure is shown or any key does not work. VDD5 RP502 47K*8 120/100M KI[0:7] 9,59,4 17~24 VDD5 VCC[1,2,B] C607 C611 C269...

  • Page 121: Hard Driver Test Error

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.7 Hard Drive Test Error Either an error message is shown, or the drive motor spins non-stop, while reading data from or writing data to hard disk. Hard Driver Test Error 1. Check if BIOS setup is OK?.
  • Page 122 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.7 Hard Drive Test Error Either an error message is shown, or the drive motor spins non-stop, while reading data from or writing data to hard disk. R349 CL-190G HDD_LED# SI4788CY +5V_HDD 120Z/100M 41, 42...

  • Page 123: Cd-Rom Drive Test Error

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.8 CD-ROM Drive Test Error An error message is shown when reading data from CD-ROM drive. CD-ROM Driver Test Error Board-level 1. Try another known good compact disk. Troubleshooting 2. Check install for correctly.
  • Page 124 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.8 CD-ROM Drive Test Error An error message is shown when reading data from CD-ROM drive. +5V_CDROM J509 R352 CL-190G SI4788CY CD_LED# 120Z/100M SOURCE[1:3] DRAIN[1:3] C255 C262 C264 C115 C125 C124 1µ 10µ 1µ...

  • Page 125: Usb Port Test Error

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.9 USB Test Error An error occurs when a USB I/O device is installed. USB Test Error Check if the USB device is installed properly. (Including charge board.) Check the following parts for cold solder or one of the following...
  • Page 126 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.9 USB Test Error An error occurs when a USB I/O device is installed. RT9701-CBL +5V_P VIN0,1 VOUT0,1 C187 C679 R204 1µ 330µ USBOC0# C166 R205 1000P J510 90Z/100M +VCC_USB0 USBP0- USBP0+ J512 90Z/100M...

  • Page 127: Audio Failure

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.10 Audio Failure No sound from speaker after audio driver is installed. Audio Failure 1. Check if speaker cables are connected properly. 2. Make sure all the drivers are Board-level Check the following parts for cold solder or one of the following parts on the installed properly.
  • Page 128 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.10 Audio Failure – Audio IN No sound from speaker after audio driver is installed. MIC1 H8_AVREF Internal R328 C340 R340 R654 4.7K 4.7K AVDDAD C331 C665 L538 120Z/100M 4.7µ 2.2µ 600Z/100M 600Z/100M 25,38...
  • Page 129 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.10 Audio Failure – Audio OUT No sound from speaker after audio driver is installed. From previous page Q513 C326 C327 R645 R650 DTA144WK AOUT_R 4.7µ 4.7µ SPK_OFF ROUT+ R314 4.7K From previous page...

  • Page 130: Lan Test Error

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.11 LAN Test Error An error occurs when a LAN device is installed. LAN Test Error Check the following parts for cold solder or one of the following 1.Check if the driver is installed properly.
  • Page 131 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.11 LAN Test Error An error occurs when a LAN device is installed. +LAN_D2.5V +3V_P R303 NM93C46 +2.5V_DDR +LAN_D2.5V EECS +2.5V_DDR +LAN_A2.5V +3V_P VCCRAM C311 EESK C290 0.1µ EEDI 1µ C316 +LAN_D2.5V +2.5V_DDR +LAN_A2.5V 0.1µ...

  • Page 132: Pc Card & Card Reader Socket Failure

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.12 PC Card & Card Reader Socket Failure An error occurs when a PC card or SD Card device is installed. PC Card & Card Reader Socket Failure 1. Check if the PC Card or Card Reader Check the following parts for cold solder or one of the following device is installed properly.
  • Page 133 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.12 PC Card & SD Card Socket Failure An error occurs when a PC card or SD Card device is installed. R342 5VA,B R339 SHDN VCC5_EN# +CARD_VCC +VPPOUT VCCD0 PCICLK_CARD J517 3.3VA,B VCC3_EN# VCCD1...

  • Page 134: Ieee1394 Failure

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.13 IEEE 1394 Failure An error occurs when a IEEE 1394 device is installed. IEEE1394 Fail 1. Check if the 1394 device is installed properly. 2. Confirm 1394 driver is installed ok. Check the following parts for cold solder or one of the following...
  • Page 135 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 8.13 IEEE 1394 Failure An error occurs when a IEEE 1394 device is installed. 1394_VCC 120Z/100M EECS EECK C234 C241 C250 C249 C248 C224 C252 0.1µ 0.1µ 0.1µ 0.1µ 0.1µ 0.1µ EEDI 1µ NM93C46...

  • Page 136: Spare Parts List

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 1 Part Number Description Location(US) Part Number Description Location(US) 441999900215 AC ADPT ASSY OPT ION;8080 272072104702 CAP;.1U ,16V,+80-20%,0603,Y5V,S C149,C151,C152,C153,C185,C218 442672600031 AC ADPT ASSY;19V,3.16A,DELT A,706 272073104703 CAP;.1U ,25V,+80-20%,0603,X7R,S 361400003030 ADHESIVE;ABS+PC PACK,G485,CEMIDA 272073104501 CAP;.1U ,25V,+80-20%,0603,Y5V,S...
  • Page 137 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 2 Part Number Description Location(US) Part Number Description Location(US) 272991107502 CAP;100u,6.3V,20%,18m,SMT,MASTUS 272075220301 CAP;22P ,50V ,5% ,0603,COG,SMT C279,C284 272075100701 CAP;10P ,50V ,+-10%,0603,NPO,SM C227,C235,C299,C302 272011226701 CAP;22U ,CR,10V,1206,Y5V,+80~20% C131,C155,C540,C545,C559,C590 272011106701 CAP;10U ,10V,+80-20%,1206,Y5V,S...
  • Page 138 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 3 Part Number Description Location(US) Part Number Description Location(US) 310111103007 CFM-BAT;T HERMISTOR,10K,1%DISK,50 291000010209 CON;HDR,MA,2P*1,1.25MM,H4.2,ST ,S J511 273000111002 CHOKE COIL;120OHM/100MHZ,20%,321 L26,L27,L525 291000010209 CON;HDR,MA,2P*1,1.25MM,H4.2,ST ,S 273000111002 CHOKE COIL;120OHM/100MHZ,20%,321 L5,L6 291000000203 CON;HDR,MA,2P*1,3.5MM,R/A,SMT ,SM 273000150313 CHOKE COIL;90OHM/100MHZ,20%,2012...
  • Page 139 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 4 Part Number Description Location(US) Part Number Description Location(US) 340675300006 COVER ASSY;8080 288100056001 DIODE;RLZ5.6B,ZENER,5.6V,5%,LL34 D1,D504 340675300013 COVER ASSY;DIMM,8080 288101040006 DIODE;SBM1040,10A,SCHOT T KY,POWER 340675300010 COVER ASSY;HDD,8080 288100056005 DIODE;UDZ5.6B,ZENER,5.6V,UMD2,SM 340675300008 COVER ASSY;LCD,8080 288100018003 DIODE;UDZS18B,ZENER,18V,SOD-323,...
  • Page 140 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 5 Part Number Description Location(US) Part Number Description Location(US) 295000010048 FUSE;0.5A/15V,POLY SWIT CH,SMD 340675300007 HOUSING ASSY;8080 295000010014 FUSE;1.1A/6V,POLY SWITCH,PT C,SMD F1,F2,F501 340675300009 HOUSING ASSY;LCD,8080 295000010105 FUSE;1A,NORMAL,1206,SMT F502,PF501 451675300001 HOUSING KIT;8080 295000010114 FUSE;FAST ,1.75A,63VDC,1206,SMT,P...
  • Page 141 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 6 Part Number Description Location(US) Part Number Description Location(US) 284583437003 IC;H8/F3437S,KBD CTRL,T QFP,100P, 273000990159 INDUCTOR;4.7UH,SPC-1205P,H6.0,TM PL513 286100393004 IC;LMV393,DUAL COMPART OR,SSOP,8P 273000990127 INDUCTOR;IHLP5050CE-01-0.68uH,VI PL506 286303728002 IC;LTC3728LX,PWM CT RL,LTC,5X5 QF PU23,PU502 346675300019 INSULATOR;...
  • Page 142 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 7 Part Number Description Location(US) Part Number Description Location(US) 242600000439 LABEL;25*6,HI-TEMP,COMMON 294011200016 LED;GREEN,H0.8,0603,CL-190G,SMT D10,D11,D12,D13,D14,D15,D16,D 242600000439 LABEL;25*6,HI-TEMP,COMMON 294011200070 LED;RED/GREEN,19-22SRVGC/TR8,LED 242600000378 LABEL;27*7MM,HI-TEMP 260'C 526267530024 LTXNX;8080/T4XX/XXX/3XX9/L1C3A/X 242668300028 LABEL;32*7MM,POLYESTER FILM,HOPE 561567530003 MANUAL KIT;EU,8080,N-B 624200010140 LABEL;5*20,BLANK,COMMON...
  • Page 143 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 8 Part Number Description Location(US) Part Number Description Location(US) 316675300001 PCB;PWA-8080/MOT HER BD 271002000301 RES;0 ,1/10W,5% ,0805,SMT L13,L32,L36,L529,L6,R202,R310, 316675300004 PCB;PWA-8080/T RANS BD 271002000301 RES;0 ,1/10W,5% ,0805,SMT 316503400101 PCB;PWA-ST INGRAY/INVERT ER BD 271071000002 RES;0 ,1/16W,5% ,0603,SMT...
  • Page 144 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 9 Part Number Description Location(US) Part Number Description Location(US) 271071103302 RES;10K ,1/16W,5% ,0603,SMT R20,R21 271071249111 RES;2.49K,1/16W,1% ,0603,SMT PR26 271071106301 RES;10M ,1/16W,5% ,0603,SMT R52,R59 271071272101 RES;2.7K ,1/16W,1% ,0603,SMT PR538 271071131101 RES;130 ,1/16W,1% ,0603,SMT...
  • Page 145 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List – 10 Part Number Description Location(US) Part Number Description Location(US) 271071309311 RES;309K ,1/16W,1% ,0603,SMT 271071487811 RES;48.7 ,1/16W,1% ,0603,SMT 271071324012 RES;324K ,1/16W,1% ,0603,SMT PR506 271071487211 RES;48.7K,1/16W,1% ,0603,SMT 271071330302 RES;33 ,1/16W,5% ,0603,SMT...
  • Page 146 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 11 Part Number Description Location(US) Part Number Description Location(US) 271071751101 RES;750 ,1/16W,1% ,0603,SMT R180 340675300005 SCREW ASSY;CPU,8080 271071750311 RES;750K,1/16W,1% ,0603,SMT PR84 341675300007 SHIELDING;HDD,8080 271071787311 RES;787K ,1/16W,1% ,0603,SMT PR16 333050000120 SHRINK T UBE;600V,105'C,D0.8*9MM,...
  • Page 147 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 12 Part Number Description Location(US) Part Number Description Location(US) 370103010405 SPC-SCREW;M3L4,NIW,K-HD,T 0.3 288200144001 T RANS;DT C144WK,NPN,SOT -23,SMT PQ503,Q20,Q23,Q24,Q34,Q5,Q51 340675300026 SPEAKER ASSY; R, 8080 288206694002 T RANS;FDS6694,N-MOSFET ,SO8,SMT PU507,PU509 340675300004 SPEAKER ASSY;L, 8080...
  • Page 148 Prestigio Nobile 141 TECHNICAL SERVICE MANUAL 9. Spare Parts List - 13 Part Number Description Location(US) 332110028163 WIRE;#28,UL1061,80MM,BLUE,YIYI,P 273001050039 XSFORMER;10/100 BASE,LF-H80P,SMT 273001050062 XSFORMER;CI8.5,SIT 16260,16/2600T 274011431408 XT AL;14.318M,50PPM,32PF,7*5,4P,S 274011431424 XT AL;14.318MHZ,20PPM,20PF,7*5,SM X501 274011600408 XT AL;16MHZ,16PF,50PPM,8*4.5,2P X502 274012457406 XT AL;24.576MHZ,16PF,50PPM,8*4.5, 274012500401 XT AL;25MHZ,30PPM,18PF,4P,SMT 274013276103 XT AL;32.768KHZ,20PPM,12.5PF,CM20...

  • Page 150: Circuit Diagram

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL...
  • Page 151 Change detail DATE ECR No. Initail release (base on Banias + Odem + ICH4-M) 2002/10/28 1.Correcting the error pin definition in EVT(include DIMM, HDD, VT6307L KBD & TV connector) Comp 0.5 oz Cu 2.Add +3V_P for VT6105LOM to support wake on LAN. IDSEL: AD21 4 mil PCI REQ0#...
  • Page 152 U501C VCC : PROCESSOR CORE POWER SUPPLY. VSS_0 VSS_73 VSS_1 VSS_74 VCCA : ISOLATE POWER FOR INTERNAL PLL. +VCC_CORE VSS_2 VSS_75 VSS_3 VSS_76 U501B VCCP : PROCESSOR I/O POWER SUPPLY. VSS_4 VSS_77 HCLK_CPU BCLK0 VCC_0 VSS_5 VSS_78 VCCQ : QUIET POWER SUPPLY FOR ON DIE COMP CKT. HCLK_CPU# BCLK1 VCC_1...
  • Page 153 +VCC_CORE +VCCP R113 R174 R173 4.7K/NA 4.7K/NA 4.7K VCC-Core VCC-Core R518 R517 R512 0603 0603 0603 51/NA 1.708 1.196 0603 0603 0603 0603 0603 0603 0603 0603 1.692 1.180 HPREQ# 1.676 1.164 HPRDY# R114 R158 R157 HBPM#1 1.660 1.148 4.7K 4.7K 4.7K/NA HBPM#0...
  • Page 154 ADD ID : 0x7Fh +1.5V R175 R562 8.2K/NA R563 8.2K R568 8.2K R560 8.2K R558 8.2K R565 8.2K R554 8.2K 8.2K HA#[3..31] HD#[0..63] U502B U502A HA#[3..31] HD#[0..63] 3 HA#3 HD#0 R553 HA[3]# HD[0]# ADDID[0] DVOBCLK HA#4 HD#1 +1.5V R564 330/NA HA[4]# HD[1]# ADDID[1]...
  • Page 155 NB_MA0 NB_MA0 NB_MA3 NB_MA3 +1.2V +2.5V_DDR U502E U502D NB_MD[0..63] U502C AG29 AA29 NB_MD[0..63] 7 VCC_0 VCCSM_0 VSS_0 VSS_91 NB_MA0 NB_MD0 AC18 AA19 AF29 SMA[0] SDQ[0] VCC_1 VCCSM_1 VSS_1 VSS_92 SMA[1..2] SMA1 NB_MD1 AD14 C172 C176 C181 AA17 AC29 C200 C583 C213 SMA[1..2] SMA[1]...
  • Page 156 +1.25V_DDR NB_BA0 NB_BA0 NB_BA1 +2.5V_DDR NB_BA1 NB_MD2 RP11 10*8 NB_RAS# +2.5V_DDR NB_RAS# NB_WE# NB_MD6 RPX8 RP12 NB_WE# NB_CAS# NB_DQS0 DQS0 56*8 +DDR_VREF NB_CAS# NB_DM0 RPX8 +DDR_VREF NB_MD1 CKE0 CKE0 J513 NB_MD5 CKE1 CKE1 NB_MD0 CKE2 J514 CKE2 CKE3 NB_MD4 CKE3 NB_DQS1 RP13 10*8...
  • Page 157 +1.5V 120Z/100M C201 C198 C576 C148 C147 C184 C202 1608 0.1U 0.1U 0.1U 0.1U 0.1U R189 1206 0603 0603 0603 0603 0603 1206 0603 RDDP recommend DVOVREF 1K ohm resistor +1.5V R193 C165 Place near 0.1U to 7011. 0603 0603 C144 C199 0.1U...
  • Page 158 Dedicate for USB2.0 can't use as ICH_ R122 0/NA 0603D_DFS GPIO5 R136 0/NA 0603D_DFS LPC_PCIRST# 19 R161 0/NA 0603D_DFS JP_NET10 VCC3_3 AD[0..31] AC23 AD[0..31] 15,16,17,18 VCC3_3 INT_PIRQA# AD31 AC18 PIRQA# AD31 VCC3_3 AD30 AC14 INT_PIRQB# PIRQB# AD30 PCIRST#0 11,22 VCC3_3 INT_PIRQC# AD29 JP_NET10...
  • Page 159 VDD3 +VCCP HUB_HI[0..10] SIDE_IN# 0603 R524 HUB_HI[0..10] 9,20 EXTSMI# HUB_HI0 R361 0603 USBP0+ USBP_0 HI 0 HUB_HI1 0603 R523 USBP0- 9,18,19 SERIRQ 9,20 SCI# USBP_0# HI 1 HUB_HI2 R103 8.2K 0603 USBP1+ USBP_1 HI 2 HUB_HI3 0603 USBP1- USBP_1# HI 3 9,17,18,19 PCLKRUN# 9,20...
  • Page 160 PD_D[0..15] PD_D[0..15] RP42 PD_D9 C_PD_D9 PD_D8 C_PD_D8 Primary EIDE Connector PD_D10 C_PD_D10 For Hard-Disk PD_D11 C_PD_D11 PD_D7 C_PD_D7 PD_D5 C_PD_D5 R0A reverse the pin definition PD_D6 C_PD_D6 PD_D4 C_PD_D4 PD_D0 C_PD_D0 PD_D1 C_PD_D1 RP43 PD_D15 C_PD_D15 R256 PD_D14 RPX8 C_PD_D14 RPX8 C_RSTDRV1# PD_D3...
  • Page 161 AVDDAD SHORT-SMT4 120Z/100M C644 C633 C315 2012 0.1U 0.1U C618 C619 C323 0.1U/NA 0.1U/NA 0603 0603 1206 0.1U 0603 0603 0603 R281 AGND AGND AGND MODEM_SPK MODEM_SPK 22 U509 0603 R284 C310 C637 2.2U 0805 +80-20% 0.1U/NA LINE/IN/L 0603 0603 C312 2.2U 0805...
  • Page 162 C326 C327 R645 AOUT_R RHP_IN ROUT+ AOUT_R R650 0603 4.7U 4.7U 0603 1206 1206 C325 R646 RLINE_IN R651 0603 0.1U 0603 0603 C318 C324 R648 AOUT_L LHP_IN LOUT+ AOUT_L R652 0603 4.7U 4.7U 0603 1206 1206 C646 R649 LLINE_IN R653 0603 0.1U 0603...
  • Page 163 2.7K*4 1206 LCD_ID0 LCD_ID1 LCD_ID2 SI4800DY LCD CONNECTOR HDS404E J505 47K*4 LCDVCC LCDVCC 120Z/100M 2012 1206 TXCLKOUT1+ TXCLKOUT0+ MICROSMDC110 TXCLKOUT1+ TXCLKOUT0+ 5 TXCLKOUT1- TXCLKOUT0- 0.1U 10U/NA TXCLKOUT1- TXCLKOUT0- 5 1000P 1000P 0.1U C690 0603 1206 TXOUT3+ TXOUT4+ DVMAIN 0603 0603 0603 1206 0.1U...
  • Page 164 VT6307L 1394_AVCC 1394_VCC IDSEL: AD21 PCI REQ0# PCI GNT0# 120Z/100M C242 C219 C220 C222 C230 C238 PCI INTG# 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 2012 0603 0603 0603 0603 0603 0603 1394_VCC 1394_VCC 1394_AVCC C234 C241 C250 C249 C248 C224 0.1U 0.1U 0.1U...
  • Page 165 RJ45 VT6105L J515 IDSEL: AD18 PCI REQ1# +LAN_D2.5V +2.5V_DDR PJRX- +LAN_A2.5V PCI GNT1# GND1 GND1 PJRX+ GND2 PCI INTE# GND2 PJTX- AD[0..31] CBE#[0..3] GND3 GND3 9,15,17,18 AD[0..31] CBE#[0..3] 9,15,17,18 PJTX+ GND4 120Z/100M 120Z/100M GND4 2012 2012 8PX1/1.016MM +LAN_D3V 291000810806 CONN_PJS-AST_8 GND_45 JO34 JO35...
  • Page 166 JS501 SHORT-SMT3 CBE#[0..3] 9,15,16,18 CBE#[0..3] AD[0..31] 9,15,16,18 AD[0..31] Mini PCI J520 IDSEL: AD17 PCI REQ3# PCI GNT3# 0/NA 0603D_DFS PCI INTD# INTF# INTEL_PD# R535 R514 0/NA 9,18 INT_PIRQF# INT_PIRQD# 9 0/NA 0603D_DFS R519 0603D_DFS 0603 PCICLK_MINIPCI MINIPCI_PCIRST# PCI_REQ3# PCI_GNT3# 9 AD31 PCI_PME# 9,10,15,16,18,20 10P/NA...
  • Page 167 +CARD_VCC CB710 +CARD_VCC IDSEL: AD20 PCI REQ2# PCI GNT2# +CARD_VCC R332 R333 R258 PCI INTB# INTF# C297 0.1U VPPD1 0603 0603 0603 0603 VPPD0 C317 0.1U R261 0603 J517 CB_PCIRST# GND[0] GND[2] CRST# CAD0 CCD1# CAD0 CCD1# CAD1 CAD2 0/NA CAD1 CAD2 CCLKRUN#...
  • Page 168 Reserve for FWH TP25 LAD0 TP26 LAD1 TP27 LAD2 TP28 LAD3 LFRAME# R655 TP29 8.2K 0603 RP504 SIO_GPIO35 PIO_D0 C647 C661 C667 C626 PIO_D1 PIO_D7 0.1U 0.1U 0.1U 0.1U 0603 0603 0603 0603 PIO_D2 PIO_D6 PIO_D3 PIO_D5 PIO_D4 1K*8/NA 1206 U510 20,21 SA[0..17]...
  • Page 169 VDD3 H8_AVREF L544 RESET# C278 R526 0.1U/NA R247 H8_VDDA 0/NA GND_H8 JP_BEAD_DFS 0603 100K/NA 0603D_DFS 0603D_DFS MAX809/NA 0603 VDD5 R609 SOT23N VDD3 VDD3 0/NA C602 C680 RSMPWRON H8_PWRON 0603D_DFS 0.1U 0.1U C603 RSMPWRON 0.1U 0603 0603 R242 120Z/100M R238 0603 4.7K 1608 VDD5...
  • Page 170 TOUCH_PAD +3V_P +3V_P +3V_P 17,20 17,20 KI5 20 SCRL_LEFT SCRL UP U20A U20B U20C TC010-PSS11CET TC010-PSS11CET 74AHC14_V 74AHC14_V 74AHC14_V TSSOP14 TSSOP14 TSSOP14 KI6 20 KI7 20 JO53 JO54 JO56 JO60 SCRL_DN SCRL_RIGHT TC010-PSS11CET TC010-PSS11CET 0.5A/POLYSW miniSMDC050 JO51 JO57 JO62 JO52 GNDGND GNDGND 120Z/100M...
  • Page 171 +5V_P For Lan JO50 +3V_P SOURCE3 DRAIN3 J506 SOURCE2 DRAIN1 SOURCE1 DRAIN2 +3V_ON +1.25V_DDR_F +1.25V_DDR OPEN-SMT4 C267 C342 C343 PWRSW# 20,21 LID# USBOC1# 10 0603 SI4788CY 1206 0603 SOURCE3 DRAIN3 IRRX SOURCE2 DRAIN1 IRTX R377 0/NA SOURCE1 DRAIN2 SIDE_IN# 0603 0/NA USBP2+ 10 C285...
  • Page 172 PWR_VDDIN BAV70LT1 BAV70LT1 120Z/100M 2012 SI4835DY ADINP 24 DVMAIN OPEN-SMT4 PJ501 6.5A/32VDC PR24 SBM1040 120Z/100M PR29 PC30 PC507 JACK-3P/D2.0/H7 2012 2512 PR30 PR37 4.7K IDJ-D22-6T PC16 PC23 1000P 0.1U 4.7K 0.1U 0.1U 470K 0805 0603 0603 0805 0603 0805 0603 RLZ24D 0603 PR507...
  • Page 173 CHARGING PQ504 SI4835DY PU1A PU1B SI4925DY SI4925DY PL502 PL501 ADINP BATT 23 BEAD_120Z/100M PD503 0805D 33UH B340LA CDRH124 PC503 DC2010 PC505 PC506 PC504 PC509 PC508 PC570 0.01U 15U/NA 15U/NA 0.01U PR510 PR509 0.1U 10U_NA PR15 0603 0.1U 7243 7243 0603 1210 4.7K 4.7K...
  • Page 174 DVMAIN DVMAIN_D 120Z/100M 2012 PC63 PC62 PC59 PC58 PC60 0.1U 0.1U PC90 7243 0603D 0603D 1210 7243 0.1U 0603D PC513 1000P 0603D BAW56 SOT23N PC92 PR89 INTVCC +5V_P PC61 1000P 0603D PU19A 0603D 1206 AO4900 PC101 0.1U 0603D PC87 PC88 0.1U 0.1U 0603D...
  • Page 175 PL517 2.5V_IN +2.5V_DDR 120Z/100M PC543 PC542 PC545 2012 0.1U PU15 1210 1210 0603 SI4800DY +1.5V_P +1.8V_P PC540 PC539 150U 150U PC538 PC541 PC537 0.1U 7343 7343 0.1U_NA 2.5V 2.5V 0603 1210 PC43 0603 PU14 0.1U_NA SI4800DY 0603 PR57 PC42 PR58 0.1U_NA 26.1K 0603...
  • Page 176 DVMAIN DVMAIN_D1 120Z/100M PC69 2012 PC72 PC68 1000P 1000P/NA PC563 0.01U 0603 PC65 VDD5 0603 15U/NA 7243 7243 0603D PR90 0603 PU21 SI4800DY PC100 PC96 2.5DH1 4.7U PR84 0805 PD11 1206 750K PD10 +80-20% BAS32L 0603 BAS32L TP20 +5V_P TOUCHPAD_10 +2.5V_DDR_P PL513 2.5V_DDR_1...
  • Page 177 DVMAIN PL509 DVMAIN_D2 PC44 120Z/100M 2012 1000P PC46 PC554 0603D PC553 PC48 0.1U PC53 0603D 0.1U PC55 7243 0603D 1210 7243 0.1U 0603D PD509 BAW56 SOT23N PC560 PR65 INTVCC1 +5V_P PC47 PU16A 1000P TBG1 0603D 0603D AO4900 TBG2 1206 PC56 0.1U 0603D PC562...
  • Page 178 PR49 PR38 0603 0603 REF_CORE 120Z/100M DVMAIN 2012 DD_CPU PR34 PR40 +5V_P 0603 0603 PR42 PR43 0_NA 120Z/100M PC524 0603 0603 2012 PC526 PC525 PC519 PC512 PC522 PC510 PC511 PC523 PC22 1000P 1000P 10U/NA* 0.1U PC27 0603 0603 1210 1210 1210 1210 1210...
  • Page 179 W/S=16/12/12/16 mils W=12 mils A15_A2 A26_B3 C_SD_D8 C_SD_D7 C_SD_D9 C_SD_D6 C_SD_D10 C_SD_D5 C_SD_D11 C_RSTDRV2# C_SD_D4 C_SD_D12 C_SD_D7 C_SD_D8 C_SD_D3 C_SD_D13 C_SD_D6 C_SD_D9 C_SD_D2 C_SD_D14 C_SD_D5 C_SD_D10 C_SD_D1 C_SD_D15 C_SD_D4 C_SD_D11 C_SD_D0 C_SDDREQ C_SD_D3 C_SD_D12 B26_B12 C_SDIOR# C_SD_D2 C_SD_D13 C_SDIOW# C_SD_D1 C_SD_D14 C_SIORDY C_SDDACK#...
  • Page 180 W/S=16/12/12/16 mils W=12 mils A15_A2 A26_B3 C_SD_D8 C_SD_D7 C_SD_D9 C_SD_D6 C_SD_D10 C_SD_D5 C_SD_D11 C_RSTDRV2# C_SD_D4 C_SD_D12 C_SD_D7 C_SD_D8 C_SD_D3 C_SD_D13 C_SD_D6 C_SD_D9 C_SD_D2 C_SD_D14 C_SD_D5 C_SD_D10 C_SD_D1 C_SD_D15 C_SD_D4 C_SD_D11 C_SD_D0 C_SDDREQ C_SD_D3 C_SD_D12 B26_B12 C_SDIOR# C_SD_D2 C_SD_D13 C_SDIOW# C_SD_D1 C_SD_D14 C_SIORDY C_SDDACK#...
  • Page 181 W/S=16/12/12/16 mils W=12 mils J501 CDROM_LEFT CDROM_RIGHT CDROM_LEFT CDROM_RIGHT CDROM_COM M A15_A2 CDROM_COM M A26_B3 C_SD_D8 C_RSTDRV2# C_SD_D8 C_SD_D7 C_SD_D9 C_SD_D7 C_SD_D9 C_SD_D10 C_SD_D10 C_SD_D6 C_SD_D6 C_SD_D11 C_SD_D11 C_SD_D5 C_SD_D5 C_SD_D4 C_SD_D12 C_SD_D4 C_SD_D12 C_SD_D3 C_SD_D13 C_SD_D3 C_SD_D13 C_SD_D2 C_SD_D14 C_SD_D2 C_SD_D14 C_SD_D15...
  • Page 182 MTG1 MTG2 ID2.2/OD6.5 ID2.2/OD6.5 0.1U 0603 0603 4.7K 4.7K 0603 0603 120Z/100M USB_DP 1608 120Z/100M 120Z/100M 1608 USB_GND 1608 SCLK +5V_USB USB_DM CBL_GND USB_D+ 120Z/100M 1608 USB_D- 1.5K 0603 AT24C64N HDR/MA-5 ACES 87152-0507 0603 0603 0603 USB_VCC 0.1U 0603 0.1U 0603 2012 DATA0...

  • Page 183: Reference Material

    Prestigio Nobile 141 TECHNICAL SERVICE MANUAL Reference Material Intel Pentium M Processor Intel, INC Intel 82855GM Memory Controller Hub (GMCH) Intel, INC Intel 82801DBM I/O Controller Hub Mobile (ICH4-M) Intel, INC...
  • Page 184 w w w . p r e s t i g i o . c o m...

Table of Contents
