- Page 1 508GG1.23POF(C) / 58GG1.23POFC 508GG1.23POF(W) / 58GG1.23POFW/A5G(W) (EN) INSTRUCTION MANUAL IO-CFS-0845 / 8501100 (08.2018 / v1)
-
Page 2: Dear Customer
DEAR CUSTOMER, The cooker is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the cooker was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully. -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ......................4 Description of the appliance ................... 10 Installation ......................... 12 Operation ........................... 17 Cleaning and maintenance ....................21 Baking in the oven – practical hints ................24 Technical data ........................28... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... - Page 5 SAFETY INSTRUCTIONS Warning: Ensure that the appliance is switched off before replacing the lamp to avoid the possibillity of electric shock. Before opening the cover, cleaning it of any dirt is recom- mended. The cooker hob surface should be cooled down before closing the cover.
- Page 6 SAFETY INSTRUCTIONS Please pay attention to children whilst the cooker is in operation, as children do not know the rules of cooker use. In particular, hot surface burners, the oven chamber, grates, the door pane, and pans containing hot liquids standing on the hob may cause burns to children.
- Page 7 SAFETY INSTRUCTIONS Do not make your own alterations to the cooker in order to adapt it to a different type of gas, move the cooker to another place or make changes to the power supply. These operations may only be carried out by an authorised electrician or fitter. ...
-
Page 8: How To Save Energy
HOW TO SAVE ENERGY Using energy in a respon- Make sure the oven door is properly sible way not only saves closed. money but also helps the Heat can leak through spillages on the door environment. So let’s save seals. Clean up any spillages immediately. energy! And this is how you Do not install the cooker in the direct can do it:... - Page 9 DISPOSAL OF THE APPLIANCE UNPACKING During transportation, protec- Old appliances should not sim- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a...
-
Page 10: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE 1 Temperature regulator knob 2, 3, 4, 5 Gas burner control knobs 6 Oven door handle 7 Large burner 8 Medium burner 9 Auxiliary burner 10 Medium burner... -
Page 11: Specifications Of The Appliance
SPECIFICATIONS OF THE APPLIANCE Burner safety valve* Spark ignitor* Cooker fittings: Grill grate Baking tray* (drying rack) Roasting tray* *optional... -
Page 12: Installation
INSTALLATION The following instructions are addressed to the qualified specialist installing the cooker. These instructions aim at ensuring that hood OKAP installation and maintenance activities are performed as professionally as possible. Min. 600 mm Installing the cooker The kitchen should be dry and airy and have effective ventilation according to the existing technical provisions. -
Page 13: Gas Connection
INSTALLATION Mounting the overturning prevention Gas connection bracket. Caution! The bracket is mounted to prevent overtur- The cooker should be connected to a ning of the cooker. When the overturning gas supply of the particular type of gas prevention bracket is installed, a child who that the appliance is manufactured to climbs on the oven door will not overturn the function with. - Page 14 INSTALLATION Adapting the cooker to another Connection with a flexible steel hose If the cooker is connected according to the type of gas. class 2 specifications, sub-class I, only flex- This operation may only be carried out by an ible metal hose can be used which meet the appropriately authorised fitter.
- Page 15 INSTALLATION Burner of SOMIPRESS type (according to the “Somipress” symbol on burner compo- nents) Burner auxiliary medium large oven gas injector gas injector gas injector gas injector diameter diameter diameter diameter Type of gas [mm] [mm] [mm] [mm] nominal nominal nominal nominal thermal power...
- Page 16 INSTALLATION Surface burners applied do not require adjust- ment of primary air. A correct flame has dis- tinct internal cones of blue and green colour. A short, humming flame or long, yellow and Adjustment smoking one, without clearly outlined cones, valve shows improper quality of gas in the house- hold piping or a damaged or soiled burner.
-
Page 17: Operation
OPERATION Before first use remove packaging elements, gently (slowly) remove labels from the oven door, trying not to break the glue tape. If any visible trace is left on the glass, warm up the oven chamber (see below), spray the warmed-up glass with a glass cleaner, and wipe off with a soft cloth. -
Page 18: How To Use Surface Burners
OPERATION Ignition without an ignitor How to use surface burners light a match, Choice of cookware press in the knob to the end and turn it left to the “large flame” position Mind that the diameter of a pan base is always ... - Page 19 OPERATION Caution! Operation of the burner protection valve In cooker models equipped with a surface burner safety valve, hold the Some models are equipped with an automatic knob pressed down to the end when system that cuts off gas supply to a burner igniting for 10 seconds at the “large when the flame has disappeared.
-
Page 20: Oven Functions And Operation
OPERATION To ignite the oven: Oven functions and operation. strike a match, press down the knob to the stop and turn The oven can be heated by oven gas burner. left to the position corresponding to the tem- The oven function is controlled by one knob. perature chosen, put the match to the ignition opening (see the figure below) and keep the knob... -
Page 21: Cleaning And Maintenance
CLEANING AND MAINTENANCE By ensuring proper cleaning and mainte- nance of your cooker you can have a sig- CORRECT nificant influence on the continuing fault-free operation of your appliance. Before you start cleaning, the cooker must be switched off and you should ensure INCORRECT that all knobs are set to the “”/“0”... -
Page 22: Door Removal
CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Using a flat screwdriver unhook the up- per door slat, prying it gently on the sides In order to obtain easier access to the oven (fig. B). chamber for cleaning, it is possible to remove 2. -
Page 23: Regular Inspections
CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat (in the lower section of the door). Fig. D, D1. 4. Clean the panel with warm water with some cleaning agent added. Carry out the same in reverse order to reassemble the inner glass panel. -
Page 24: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking we recommend using the baking trays which were provided with your cooker which should be put on the drying rack; before the cake is taken out of the oven, check if it is ready using a wooden stick (if the cake is ready the stick should come out dry and clean after being inserted into the cake);... -
Page 25: Roasting Meat
BAKING IN THE OVEN – PRACTICAL HINTS Roasting meat cook meat weighing over 1 kg in the oven, but smaller pieces should be cooked on the gas burners. use heatproof ovenware for roasting, with handles that are also resistant to high temperatures;... - Page 26 BAKING IN THE OVEN – PRACTICAL HINTS Gas burner Type of Position on the Position on the Level Time dish knob knob From the [min] [large flame] [small flame] Bottom Preliminary Baking baking 12 - 15 Roast beef or fillet 5 min.
-
Page 27: Operation In Case Of Emergency
OPERATION IN CASE OF EMERGENCY In the event of an emergency, you should: switch off all working units of the cooker disconnect the mains plug call the service centre some minor faults can be fixed by referring to the instructions given in the table below. -
Page 28: Technical Data
TECHNICAL DATA Appliance category CZ, SK, BG, HR, RO II2H3B/P HU II2HS3B/P SI II2H3+ Cooker dimensions W/H/D 50/85/60 cm The product meets the requirements of European standards EN 60335- 1; EN60335-2-6, EN 30-1-1 Certificate of compliance CE The Manufacturer hereby declares that this product complies with the general requirements pursuant to the following European Directives: ... - Page 32 Amica Wronki S.A. ul.Mickiewicza 52, 64-510 Wronki, Poland tel. +48 67 25 46 100, fax +48 67 25 40 320 www.amica.pl...
