Assembly Instructions for the Revv 1 Passenger Kit
This written guide will walk you through assembling and attaching the Revv1 Passenger Kit.
Refer to the YouTube assembly video by scanning the QR code below:
Materials Needed
● Ride1Up Hex Keys (3mm, 4mm, 5mm, 6mm)
● 8mm open-end wrench
● Wire cutters or scissors
● Two Zip Ties
Step-by-Step Instructions
Step 1: Unpack and Gather Components
1. Work in a spacious area with enough room to move around the bike.
2. Remove the battery to prevent the bike from tipping over during installation.
3. Open all packaging and confirm you have all tools and parts before starting.
4. Keep all hardware secure to avoid losing any small pieces.
Advertisement
Related Manuals for Ride1up Revv 1 Passenger Kit
Summary of Contents for Ride1up Revv 1 Passenger Kit
- Page 1 Assembly Instructions for the Revv 1 Passenger Kit This written guide will walk you through assembling and attaching the Revv1 Passenger Kit. Refer to the YouTube assembly video by scanning the QR code below: Materials Needed ● Ride1Up Hex Keys (3mm, 4mm, 5mm, 6mm) ●...
- Page 2 Step 2: Remove the Light, Bracket, and Rear Frame Plug 1. Cut the zip tie securing the rear light cable. 2. Unplug the light and remove it using an 8mm wrench to remove the nuts (save the hardware). 3. Unbolt the bracket using a 3mm and 4mm Allen wrench and remove it. 4.
- Page 3 Step 3: Slide & Secure the Passenger Kit 1. Slide the passenger kit into the frame until you can see through the front hole. 2. Hold the side plates in place, ensuring the thicker end is facing down. 3. Insert the long bolt through one side plate and into the front hole in the frame. 4.
- Page 4 Step 4: Install the Rear Light & Extension Cable 1. Mount the rear light onto the passenger kit’s light mount. 2. Secure the light using two 8mm nuts and washers. 3. Plug the extension cable into the light and route it along the frame. 4.
- Page 5 Step 5: Install the Foot Pegs 1. Attach the pegs on each side using the provided hex bolts and a hex wrench. 2. Ensure the pegs fold up when properly installed. Step 6: Removing the Basket 1. To remove the basket, pull the Connect+ latch located under the basket. 2.
- Page 6 ● Revv1’s max weight capacity is 360lbs. ● Riding with a passenger affects bike handling—ride with caution. ● Periodically check bolts to ensure they remain secure. ● The passenger must keep their feet on the pegs while riding. Fold pegs up when not in use to avoid pedal striking.
