Assembly Instructions for the CF Racer1 Add-on Battery
This written guide will walk you through assembling and attaching the CF Racer1 Dual Battery
Add-On
Refer to the YouTube assembly video by scanning the QR code below:
Materials Needed
● Add on Battery
● Dual Battery Splitter
● Add on Battery Connector Cable
● Bolts & Washers
● Cable Guide Sticker
● Ride1Up Hex Key Set (provided with bike)
● Screwdriver
● Torx Screw Set
● Torque Wrench
● Picks (optional)
Step-by-Step Instructions
Step 1: Remove Bottom Bracket Cover & Non-Drive Side Crank Arm
1. Ensure the bike is stable on the ground upside down resting on the saddle and
handlebars.
2. Using a 4mm Hex Key, unscrew the bottom bracket cover found on the bottom of the
downtube.
3. Using a 6mm Hex Key, unscrew the non-drive side crankarm retention bolt.
4. Using a 5mm Hex Key, unscrew the two crank arm bolts found on the opposing ends of
the crankarm.
5. Remove the non-drive side crank arm and place it on a clean flat surface.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CF Racer1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ride1up CF Racer1

Summary of Contents for Ride1up CF Racer1

  • Page 1 Assembly Instructions for the CF Racer1 Add-on Battery This written guide will walk you through assembling and attaching the CF Racer1 Dual Battery Add-On Refer to the YouTube assembly video by scanning the QR code below: Materials Needed ● Add on Battery ●...
  • Page 2 Step 2: Remove Chain and Crank. 1. Release tension on the chain by pulling the rear derailleur pulley cage towards the chainwheel. 2. Remove the chain, ensuring to not scratch crank arms. Let the chain hang from the rear derailleur. 3.
  • Page 3 2. Install the Crankset by sliding in the drive-side crank and spindle through the bottom bracket. 3. Align the non-drive side crank arm opposite (180 degrees) to the drive side. 4. Secure the cranks by inserting and hand-tighten the crank bolts to avoid cross threading. 5.
