- Page 1 User manual WP220...
- Page 2 WP2xx - User manual...
-
Page 3: Table Of Contents
Table of contents Introduction Universal wall panel - Bluetooth receiver � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 05 Precautions Chapter 1 Overview front panel �... - Page 4 WP2xx - User manual...
-
Page 5: Introduction
The WP220 is a remote universal wall panel with Bluetooth receiver input that can be used in combination with various AUDAC devices. It was never easier connecting your Bluetooth enabled device with your audio installation using this wall plate. It will enable you to transfer high-quality audio over long distances between the wall panel and the loudspeaker, by just using inexpensive twisted-pair CAT5e or better cabling. -
Page 6: Precautions
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED ON THE APPARATUS DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. -
Page 7: Overview Front Panel
Chapter 1 Overview front panel On the front of the wall panel you will find a Bluetooth pair button with a convenient LED indicator to check if it is in pairing mode or already connected to a device. The Bluetooth pairing name can be customized as desired. -
Page 8: Overview Rear Panel
Overview rear panel The rear of the WP220 contains an 8-pin Terminal Block connector, which is used to connect the wall panel to the twisted pair cabling. Below of the 8-pin connector are some DIP switches. These switches allow certain functions to be turned on or off, depending on the situation the WP is in. -
Page 9: Quick Start Guide
You can connect your audio sources to the wall-panel with Bluetooth, and your sounds should be audible through the system. Connecting a remote input to a line input connection WP2xx series PRE116 PRE116 AUDAC 0 dBV output (DIP Switch) PSD241 Shielded balanced audio or CAT networking cable WP2xx - User manual... -
Page 10: Chapter 3 010
Chapter 3 Connections CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed according to international wiring standards for professional audio equipment Terminal block (Audio, +24V DC) For connection to Wall Panels The 8-pin Euro-Terminal Block on the rear side of the WP220 should be connected to twisted pair cabling. The maximum cable distance between the input unit and the speaker system can reach up to 100 meter. -
Page 11: Technical Specifications
Technical specifications Integrated Bluetooth receiver Inputs Type Version BT5.0 Frequency band 2.4 GHz Output Type Stereo Connector 8-pin terminal block 3.81mm Output level Switch between 0dBV and 12 dBV Power consumption < 1.5W Power supply 17V - 24V Phantom power 24V DC (depending on input voltage) Noisefloor -76.5 dBV...
