- Page 1 INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS BUILT-IN GAS HOBS P90 series Models: DGHS90W - DGHS90WF distributed by DèLonghi Pty Ltd...
-
Page 2: Product Label
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL APPLIANCES Use of any electrical appliance implies the necessity to follow a series of fundamental rules. In particular: Never touch the appliance with wet hands or feet; do not operate the appliance barefooted; do not allow children or other incapable people to use the appliance without supervision. -
Page 4: Installation
INSTALLATION CAUTION: This appliance must be installed in accordance with these installation instructions, local gas fitting regulations, municipal building codes, water supply regulations, electrical wiring regulations, AS5601 / AG 601 - Gas Installations and ony other relevant statutory regulations. This appliance shall only be serviced by authorized personnel. This appliance is to be installed only by an authorised person. - Page 5 This cooktop has been designed and constructed in accordance with the following codes and specifications: AGA101 (AS 4551) Approval Requirements for Domestic Gas cooking appliances AS/NZS 3350-1 General Requirements for Domestic electrical appliances AS/NSZ 3350-2-6 Particular Requirements for Domestic electrical cooking appliances AS/NSZ 1044 Electromagnetic Compatibility Requirements.
- Page 6 The installation shall comply with the dimensions in Figures 1 and 2, bearing in mind that: A minimum clearance of 20 mm has to be kept between the bottom of the cooking hob and the top of an appliance or a shelf. To ensure this clearance mount the spacers, supplied with the appliance, as shown in the figure below.
- Page 7 INSTALLATION (Refer to Figure 4) 1. Spread out the gasket “C” over the workbench at the edge of the cut out tak- ing care to overlap the gasket at the corners. 2. Slot in the cooking hob into the cut out of the workbench and locate it cor- rectly.
-
Page 8: Gas Supply
GAS SUPPLY: The connection must be executed by an authorised person according to the relevant standards. Before connecting the appliance to the gas main, mount the brass conical adaptor onto the gas inlet pipe, upon which the gasket has been placed (figures 5a-5b). Conical adaptor and gasket are supplied with the appliance (packed with conversion kit for use with Natural gas or Universal LPG). - Page 9 Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent. 7. Where the appliance data plate cannot be easily read with the appliance in the...
- Page 10 CONVERSION PROCEDURE (to convert to Universal LPG) REPLACING THE INJECTORS The conversion procedure must be carried out only by an authorised person. This appliance is suitable for use with Natural gas or Universal LPG (check the “gas type” sticker attached to the appliance). The nominal gas consumption and injector size details are provided in table at page 9.
-
Page 11: Minimum Burner Setting Adjustment
MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position. -
Page 12: Electrical Requirements
INSTALLATION ELECTRICAL REQUIREMENTS The appliance must be connected to the mains checking that the voltage corresponds to the value given in the rating plate and that the electrical cable sections can withstand the load specified on the plate. The plug must be connected to an earthed socket in compliance with safety standards. - Page 13 Replacing the power cord must be done by a qualified electrician in accordance with the instructions supplied by the manufacturer and in compliance with established electrical regulations. Figure 10a ELECTRIC DIAGRAMS KEY PA Ignition switch Ignition coil M Terminal block Earth conductor Figure 10b CA Spark electrode...
- Page 14 USE and CARE CAUTION: This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be con- sidered as inappropriate and therefore dangerous. Do not use this appliance as a space heater.
-
Page 15: Gas Burners
GAS HOBS Figure 11a This appliance is class 3 Model: DGHS90W rated The electric ignition is incorporated into the knobs GAS BURNERS Natural Gas Universal LPG MJ/h MJ/h 1. Auxiliary burner (A) 2. Rapid burner (R) 10.3 10.8 3. Central triple ring burner (TR) 13.0... - Page 16 Figure 11b This appliance is class 3 Model: DGHS90WF rated The electric ignition is incorporated into the knobs The appliance has a safety valve system fitted (beside every burner there is the “T” probe as in fig. 16 - not confuse with the “S”...
-
Page 17: Using Gas Burners
If after relighting the burner, the flame is still abnormal, turn the burner off and contact our Customer Service Centre to obtain the nearest authorized Delonghi Service Agent. In the case of a mains failure light the burner with a match or lighted taper. -
Page 18: Lighting The Burners
Whenever lighting any of the burners produces an abnormal flame, switch that burner off and relight using the minimum setting. If after relighting the burner, the flame is still abnormal, turn the burner off and contact our Customer Service Centre to obtain the nearest authorized Delonghi Service Agent. LIGHTING THE BURNERS... - Page 19 COOKING HINTS FOR GAS HOBS The burner must be chosen according to the diameter of the pans and energy required. For optimum efficiency use a wok or pan no smaller than 230mm diameter. Figure 13 do not use pans with concave or convex bases Burners Pan diameter Auxiliary...
- Page 20 Saucepans with handles which are excessively heavy, in relationship to the weight of the pan, are safer as they are less likely to tip. Pans which are positioned centrally on burners are more stable than those which are offset. It is far safer to position the pan handles in such a way that they cannot be accidentally knocked.
-
Page 21: Correct Use Of Triple-Ring Burner
CORRECT USE OF TRIPLE-RING BURNER The flat-bottomed pans are to be placed directly onto the pan-support. To use the WOK, you must place the wok stand in the CORRECT position as shown in fig. 15. Figure 15 WRONG CORRECT... - Page 22 GAS TAPS Regular lubrication of the gas taps must only be performed by Authorized person. If the gas taps are not working properly, call our Customer Service Centre to obtain the nearest Authorized Delonghi Service Agent.
-
Page 23: Correct Positioning Of The Burners
CORRECT POSITIONING OF THE BURNERS It is very important to check that spreader “F” and cap “C” of the burner (see Figures 16 and 17) are perfectly in place because if they move out of place serious problems could arise. Make sure that electrode "S"... - Page 24 CORRECT POSITIONING OF THE TRIPLE-RING BURNER The triple ring burner must be correctly positioned (see fig. 20); the burner rib must be located in position as shown by the arrow (see fig. 18). The burner correctly positioned must not rotate (fig. 19). Then position the cap “A”...
- Page 25 CORRECT POSITIONING OF THE FISH BURNER (model DGHS90WF only) This burner must be correctly positioned as shown in the figure 21. Check that the electrode “S” (fig. 21) is always clean to ensure trouble-free sparking. In the models with safety device, check that the probe “T” (fig. 21) next to the burner is always clean to ensure correct operation of the safety valve.
-
Page 26: Service And Maintenance
Servicing the appliance: Service may be obtained by contacting our Customer Service Centre to locate the nearest Authorised Delonghi Service Agent: LUBRICATION OF THE GAS TAPS If the gas tap becomes stiff, it is necessary to dismantle it carefully and clean it with petroleum spirit. - Page 28 Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs. Cod.
