Cleaning Cart:
CC200
Before You Begin...
• Read instructions thoroughly prior to assembly.
This kit contains parts that can be damaged if assembled incorrectly or in the wrong sequence.
• Please follow instructions.
Suncast is not responsible for replacing parts lost or damaged due to incorrect assembly.
• Check for all parts before you begin assembly.
Using the provided parts check list, verify that you have all the parts required to construct your cart.
Caution
• This product is not a toy and is not intended for use by children.
• Exercise caution when moving fully loaded product.
• Do not sit or stand on product.
Care Instructions
• We recommend cleaning your product with soap and water. DO NOT use bleach, ammonia, or other caus-
tic cleaners, and DO NOT use stiff bristle brushes. Rinse and dry well before using.
Tools Needed
*
*Included in parts bag
© 2023 Suncast Corporation, Batavia, IL
To learn about other Suncast products please call
1-855-477-1260 or 1-630-879-2050.
Product Feedback? Email us at: feedback@suncastcommercial.com
High-Security Cleaning Cart:
CCH255
0361539B
Advertisement
Related Manuals for Suncast CC200
Summary of Contents for Suncast CC200
- Page 1 This kit contains parts that can be damaged if assembled incorrectly or in the wrong sequence. • Please follow instructions. Suncast is not responsible for replacing parts lost or damaged due to incorrect assembly. • Check for all parts before you begin assembly.
- Page 2 Parts - CC200 Cleaning Cart 10253310 0440842 Smaller Buckets Bag Wire 10252910 Large Bin 10252710 Folding Handle 10253510 Tool Rack/Top Frame 10252110 0510836 Side Wall Laundry Bag 10252210 Shelf 10252510 Base 10252810 10252310 Sign Hooks Roller Brackets 0463698 Roller Assembly...
- Page 3 Parts - CCH255 High-Security Cleaning Cart 0464022 Bin Cover and 0440842 Large Bin Bag Wire 0B0053110 Back Panel 10253310 10252710 Smaller Buckets Folding Handle 10253510 Tool Rack/Top Frame 10252110 Side Wall 0510836 Laundry Bag 10252210 Shelf 0510959 Bag Cover 10252510 Base 10252810 10252310...
- Page 4 Assembly Install cart sides (G) into slots on base (L). Turn cart assembly upside down, and secure sides to base (L) with eight screws (AA).
- Page 5 Assembly CC200, install Large Bin (W) to top panel (N). Secure CCH255 install Bin Cover with Large Bin (B) to top panel from below with four screws (AA). (N). Secure from below with four screws (AA). Stand cart upright and place top panel (N) onto side panels (G).
- Page 6 Assembly - Steps 5-8 are for CCH250, skip this page for CC200 Dowel Pin Dowel Pin On CCH255, at a slight angle, insert lower dowel pins On CCH255, sightly lift up top panel (N) and insert dowel of back panel (A) into holes in base (L). Skip this step for...
- Page 7 Assembly Secure top panel (N) with eight screws (AA). Install four screws on exterior, then four screws on interior corners. (Interior corner screws will be a blind installation.) Place cart carefully on its side. Install roller brackets (K) Install a long bolt (CC) and washer (FF) through each to front corners of base (L).
- Page 8 Assembly Attach swivel casters (O) to location shown in illustration above. Slide a wall guide (R) onto both fixed casters (P) and attach as shown on handle side. Secure each caster with four screws (AA).
- Page 9 Assembly (cont) Stand cart upright. Install sign hooks (J) to front side cart panel (G). Secure with two screws (BB) for each sign hook. Install charging wire (S) into front of base (L). Secure with nuts (DD). Note: Charging wire (S) is optional, and can be removed to fit bucket if needed.
- Page 10 Assembly (cont) At the desired height, insert shelf into cart at an angle. Install laundry bag (I) loops into slots on top frame (F) Once in position, lay flat on the shelf supports. Secure and snap closed to secure. with screw (BB) on each front side of shelf. Lift plastic bag wires (D) into upper position and remove Fold plastic bag wires (D) down into position on top tape securing wires together.
- Page 11 Assembly (cont) CCH255, open Bin Cover (B) and install Small Buckets CC200, install small buckets (C) into Large Bin (W). (C) into Large Bin. CCH255, place lid cover (HH) over bag.
