BOXER G2 & R9
Installation Instructions
Table of Contents
Antenna Versions......................................................................................................................................................................................... 2
Required Tools & Accessories ................................................................................................................................................................ 2
Battery Installation-Boxer G2 & R9 ....................................................................................................................................................... 3
Router Installation-Boxer G2 ................................................................................................................................................................... 4
Router Installation-Boxer R9 ................................................................................................................................................................... 5
Connection: Boxer G2 & R9 ...................................................................................................................................................................... 7
Connection: Boxer G2 & R9 ...................................................................................................................................................................... 8
Final Assembly: Boxer G2 & R9 ............................................................................................................................................................. 16
Operational Setup ..................................................................................................................................................................................... 21
Battery Operation and Safety Guidelines ...................................................................................................................................... 24
Disclaimer .................................................................................................................................................................................................... 25
Support Contact & Version # ............................................................................................................................................................. 25
Boxer Installation Instructions
Page 1 of 25
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Parsec Antennas BOXER G2
Summary of Contents for Parsec Antennas BOXER G2
-
Page 1: Table Of Contents
Router Installation-Boxer R9 ................................... 5 Connection: Boxer G2 & R9 ..................................7 Connection: Boxer G2 & R9 ..................................8 Final Assembly: Boxer G2 & R9 ................................16 Operational Setup ..................................... 21 Battery Operation and Safety Guidelines ............................24 Disclaimer ........................................25 Support Contact &... -
Page 2: Antenna Versions
Antenna Versions The Boxer case antenna comes in multiple versions with the features listed below. Boxer G2 & R9 • 2x RJ-45 Ports • USB-C Charger • Battery Operated – OmniCharge 30C+ Custom Battery, OP3CPA01 (battery not included) • 40mm Fan Required Tools &... -
Page 3: Battery Installation-Boxer G2 & R9
Battery Installation-Boxer G2 & R9 Step 1: Mount the Omnicharge 30C+ battery pack to the battery tray. A. Remove the cover plate from the enclosure. B. Insert the battery pack into the battery tray, as shown in Figure 1. Ensure that the battery pack ports are at the open end of the battery tray, as shown below. -
Page 4: Router Installation-Boxer G2
Router Installation-Boxer G2 Step 1: Mount the router to the bottom plate. A. If it is not already done, remove the cover plate from the enclosure. B. Install the SIM Card/s into the Router. C. Align the router with the holes on the bottom plate. -
Page 5: Router Installation-Boxer R9
Router Installation-Boxer R9 Step 1: Mount the router to the bottom and secure using the router plate. A. If not already done, remove the cover plate from the enclosure. B. Install the SIM Card/s into the Router. C. Place the router on the bottom of the case. Ensure the router orientation is correct, as shown in the images below. - Page 6 Figure 6: Secure the Router Plate using the PTA0393 Screws Figure 7: Secure the Router using the PTA1121 Screws Boxer Installation Instructions Page 6 of 25...
- Page 7 Connection: Boxer G2 & R9 Figure 8: Connection Diagram for Boxer G2 Boxer Installation Instructions Page 7 of 25...
-
Page 8: Connection: Boxer G2 & R9
Connection: Boxer G2 & R9 Step 1: Connect the antenna cables to the router. A. Use canned air/isopropyl alcohol to clean the connectors & ensure there is no dust in the terminals. B. Connect the antenna cables to the terminals on the router, as shown in the tables/images below. - Page 9 CELL 1 Wi-Fi 1 Wi-Fi 2 CELL 2 Power Supply Figure 9: Ericsson S700 Connections CELL 1 Wi-Fi 1 Wi-Fi 2 CELL 2 Bluetooth Power Supply Figure 10: Ericsson R920 Connections Boxer Installation Instructions Page 9 of 25...
- Page 10 CELL 3 CELL 4 CELL 1 CELL 2 Power Supply Wi-Fi 2 Wi-Fi 1 Figure 11: Ericsson R980 Connections Boxer Installation Instructions Page 10 of 25...
- Page 11 Figure 12: Peplink MAX BR1 Pro 5G Connections Boxer Installation Instructions Page 11 of 25...
- Page 12 CELL 3 CELL 1 CELL 2 CELL 4 LAN 1 LAN 2 Power Supply Figure 13: Peplink MAX BR1 Mini 5G Connections Boxer Installation Instructions Page 12 of 25...
- Page 13 CELL 1 Wi-Fi 1 CELL 3 CELL 2 CELL 4 Wi-Fi 2 LAN 1 LAN 2 Power Supply Figure 14: Semtech XR60 Connections Boxer Installation Instructions Page 13 of 25...
- Page 14 Step 2: Connect the power supply to the router. A. Connect the power to barrel adapter to the router power supply port and to the USB-C to barrel adapter. Connect the USB-C to barrel adapter to the Power Adapter and plug in the Power Adapter to the Battery, as shown in Figure 16.
- Page 15 Note: The stickers/labels may need to be trimmed for the Boxer Case using scissors. Figure 17: Panel Mount Sticker Sheet Figure 18: Right Side of the Boxer G2 Case with Stickers installed Figure 19: Left Side of the Boxer G2 Case with Stickers installed...
-
Page 16: Final Assembly: Boxer G2 & R9
Ensure that the antenna cables are not excessively bent (1/2” minimum bend radius). Ensure that no antenna cables are running across the top of the router. Figure 20: Fully Connected 5in1 Boxer G2 with Ericsson S700 Router Boxer Installation Instructions... - Page 17 Figure 21: Fully Connected 7in1 Boxer G2 with Peplink MAX BR1 Pro 5G Router Figure 22: Fully Connected 4in1 Boxer G2 with Peplink MAX BR1 Mini Router Boxer Installation Instructions Page 17 of 25...
- Page 18 Figure 23: Fully Connected 5in1 Boxer R9 with Ericsson R920 Router Figure 24: Fully Connected 7in1 Boxer R9 with Ericsson R980 Router Boxer Installation Instructions Page 18 of 25...
- Page 19 Step 2: Fasten the cover plate to the case. A. Place the cover plate onto the bottom half of the case. Ensure that no cables are pinched between the cover plate and the case. B. Fasten the bottom and sides of the cover plate to the case using the eight PTA0099 long screws provided in the kit, as shown in Figure 25.
- Page 20 C. Fasten the top of the cover plate to the case using the four PTA0071 screws provided in the kit, as shown in Figure 26. Figure 26: Fasten the cover plate to the case using PTA0071 screws. Boxer Installation Instructions Page 20 of 25...
-
Page 21: Operational Setup
Operational Setup Step 1: Open the fan and vent caps. A. Before turning the antenna ON, always open the fan and vent caps. The type of cap may vary. Ensure that the antenna is away from any liquids when the caps are open. Figure 27: Open the fan and vent caps. - Page 22 Step 3: Connect the router to a computer. A. Use an ethernet cable to connect a computer to one of the LAN ports on the router. Router Page Ericsson Step 4, Page 22 Peplink Step 5, Page 23 Step 4: Login to Ericsson NetCloud. A.
- Page 23 Step 5: Login to PEPWAVE. A. This step only applies for Peplink Routers. B. Open a web browser on the computer and type 192.168.50.1 into the address bar. This will bring up the PEPWAVE, shown in Figure 30. C. Login to PEPWAVE. The username is “admin”, and the password is “admin”. Figure 30: Access PEPWAVE.
-
Page 24: Battery Operation And Safety Guidelines
Battery Operation and Safety Guidelines A. To manually power ON/OFF, press and hold the power button for 3 seconds. All LED lights/display should turn ON/OFF. B. Make sure the battery is at least 30% charged before operating. If the battery is not charged, charge the battery using the USB-C Port on the Case. -
Page 25: Disclaimer
Disclaimer CAUTION To comply with FOC RF Exposure requirements in section 1.1310 of the FCC Rules, antennas used with this device must be installed to provide a separation distance of at least 20 cm from all persons to satisfy RF exposure compliance. DO NOT: •...
