20" 3-BURNER COOKTOP WITH FFD
MODEL (LIPPERT PN)
FGH20W3MA1B-BL (2023045678) FGH20W3MA1B-SS (2023045679)
TROUBLESHOOTING AND SERVICE MANUAL
* Picture shown here is for reference only.
This manual contains the product's basic information, safety, maintenance,
replaceable parts, fault diagnosis and basic troubleshooting procedures.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FGH20W3MA1B-BL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Furrion FGH20W3MA1B-BL

  • Page 1 20" 3-BURNER COOKTOP WITH FFD MODEL (LIPPERT PN) FGH20W3MA1B-BL (2023045678) FGH20W3MA1B-SS (2023045679) TROUBLESHOOTING AND SERVICE MANUAL * Picture shown here is for reference only. This manual contains the product's basic information, safety, maintenance, replaceable parts, fault diagnosis and basic troubleshooting procedures.
  • Page 2: Table Of Contents

    Specifications Introduction This document provides an overview on replaceable parts for Furrion® 20" 3-Burner Cooktop with FFD, as well as basic troubleshooting and service information. NOTE: Images used in this document are for reference only when assembling, installing and/or operating this product.
  • Page 3: Safety Precautions

    Safety Precautions If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do NOT store or use gasoline or other flammable vapors or liquids near this or any appliance. What to do if you smell gas: •...
  • Page 4: Pressure Check

    NOTE: Ensure the product is gas leak checked after the pressure check test is completed by also testing the pressure check port screw. If any leaks are detected around the pressure check port screw and gasket, a new one can be purchased. Call Furrion support for a replacement. Page 4 Rev: 01.22.25...
  • Page 5: Gas Leak Check

    Gas Leak Check Always perform a leak test for possible leaks according to the manufacturer's instructions before any operation. Pressure/Leak test using 11-13.8 WC pressure. Extinguish all open flames. NEVER Leak test when smoking. Do not use the oven until connection has been leak tested and does not leak.
  • Page 6: Replacable Parts List

    Replacable Parts List Callout Part # Description Model 2021124428 Wired Grate 2021124174 Top-Tray Module 2023048887 Left Burner Module (includes Burner, Ignitor, FFD, Bracket) 2023048888 Middle Burner Module (includes Burner, Ignitor, FFD, Bracket) 2023048890 Right Burner Module (includes Burner, Ignitor, FFD, Bracket)) Front Panel Module with FFD (Stainless Steel) (Silver Knobs and 2023048891 Ignitor Included)
  • Page 7: Troubleshooting

    Troubleshooting Trouble/Symptom Cause/Solution Surface control knob has not been fully rotated to the LIGHT position. Check to see if gas valve is open. If not, open it. Surface burners do not Burners are clogged. Make sure burner is off. Use a small wire toothbrush or needle light or burn evenly to clean burner slots.
