RV RANGE 3-BURNER COOKTOP
MODEL (LIPPERT PN)
FGH3Z23-BL (NA) FGH3Z23-SS(NA) FGH3Z25-BL(2021123561)
FGH3Z25-SS (NA) FGHWCLDA-BL (2021123893)
FGHWCLDA-SS (2021123926)
TROUBLESHOOTING AND SERVICE MANUAL
This manual contains the product's basic information, safety, maintenance,
replaceable parts, fault diagnosis and basic troubleshooting procedures.
* Picture shown here is for reference only.
Advertisement
Table of Contents
Related Manuals for Furrion FGH3Z23-BL
Summary of Contents for Furrion FGH3Z23-BL
- Page 1 RV RANGE 3-BURNER COOKTOP MODEL (LIPPERT PN) FGH3Z23-BL (NA) FGH3Z23-SS(NA) FGH3Z25-BL(2021123561) FGH3Z25-SS (NA) FGHWCLDA-BL (2021123893) FGHWCLDA-SS (2021123926) TROUBLESHOOTING AND SERVICE MANUAL * Picture shown here is for reference only. This manual contains the product's basic information, safety, maintenance, replaceable parts, fault diagnosis and basic troubleshooting procedures.
-
Page 2: Table Of Contents
Troubleshooting Specifications Introduction This document provides an overview on replaceable parts for Furrion® RV Range 3-Burner Cooktop, as well as basic troubleshooting and service information. NOTE: Images used in this document are for reference only when assembling, installing and/or operating this product. -
Page 3: Safety Precautions
Always wear eye protection when performing service, maintenance or installation procedures. Other safety equipment to consider would be hearing protection, gloves and possibly a full face shield, depending on the nature of the task. Safety Precautions If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. -
Page 4: Pressure Check
NOTE: Ensure the product is gas leak checked after the pressure check test is completed by also testing the pressure check port screw. If any leaks are detected around the pressure check port screw and gasket, a new one can be purchased. Call Furrion support for a replacement. Page 4 Rev: 01.31.25... -
Page 5: Gas Leak Check
Gas Leak Check Always perform a leak test for possible leaks according to the manufacturer's instructions before any operation. Pressure/Leak test using 11-13.8 WC pressure. Extinguish all open flames. NEVER Leak test when smoking. Do not use the oven until connection has been leak tested and does not leak. -
Page 6: Replacable Parts List
Replacable Parts List Page 6 Rev: 01.31.25 CCD-0008663... -
Page 7: Troubleshooting
^A – Wired grill is default to be sold with FGH3Z25-BL/SS and FGHWCLDA-BL/SS. But A & B are interchangeable. ^B - Die cast grill is default to be sold with FGH3Z23-BL/SS. But A & B are interchangeable. *J – Each cooktop needs 8pcs of cooktop grill holding gasket. -
Page 8: Specifications
Specifications Left and Right Burner: 6500 BTU BTU/HR Front Burner: 8000 BTU Fuel/Power Propane Inlet Pressure 10" WC Min to 13.8" WC Max Power input 12V DC <2 Amp This appliance conforms with the directives: ANSI Z21.57a-(2012) Rec / CAN1-1.16-M79 (R2016) Page 8 Rev: 01.31.25 CCD-0008663... - Page 9 This page is intentionally left blank. Page 9 Rev: 01.31.25 CCD-0008663...
