A.O. Smith 300 Series Instruction Manual
A.O. Smith 300 Series Instruction Manual

A.O. Smith 300 Series Instruction Manual

Commercial gas water heaters
Table of Contents

Advertisement

Quick Links

WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
Installation
performed by a
service agency or the gas supplier.
Thank you for buying this energy efficient water heater.
We appreciate your confidence in our products.
PLACE THESE INSTRUCTIONS ADJACENT TO HEATER AND NOTIFY OWNER TO KEEP FOR FUTURE REFERENCE.
KEEP THIS MANUAL IN THE POCKET ON HEATER FOR FUTURE REFERENCE WHENEVER MAINTENANCE ADJUSTMENT OR
PRINTED 0723
and
service
must
qualified
installer,
COMMERCIAL GAS WATER HEATERS
LOW LEAD
CONTENT
be
SERVICE IS REQUIRED.
Instruction Manual
120(A)/150(A)/199(A)/250(A)
INSTALLATION - OPERATION - SERVICE
- MAINTENANCE -TROUBLESHOOTING
Read and understand this instruction
manual and the safety messages
herein before installing, operating or
servicing this water heater.
Failure to follow these instructions and
safety messages could result in death
or serious injury.
This manual must remain with the
water heater.
For Your Safety
AN ODORANT IS ADDED TO THE GAS USED
BY THIS WATER HEATER.
MODELS:
SERIES 300-301
100368181_2000566096D
