Ysia Patio io
EN
Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ysia Patio io and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOMFY Ysia Patio io

Summary of Contents for SOMFY Ysia Patio io

  • Page 1 Ysia Patio io Instructions...

  • Page 2: Table Of Contents

    Ysia Patio io ORIGINAL INSTRUCTIONS These instructions apply to all Ysia Patio io, the different versions of which are available in the current catalogue. This complete instruction guide complements the short installation guide available with the product. Please also comply with the instructions set out in the Safety instructions document enclosed with this product and available online on www.somfy.info.

  • Page 3: Prior Information

    1.PRIOR INFORMATION 1.1.Introduction Ysia Patio io is a remote control that allows the user to control motorised products using io-homecontrol® radio technology, especially on the terrace. The user can control up to 16 channels which are made up either of a single motorised product, or of groups of homogeneous motorised products.

  • Page 4: Installation

    Activation button: the screen displays “New channel”. 3] Create the channels needed, starting with Pre-pairing channels (optional, if Please select Please select a language a language motorised products have been already pre-paired to Ysia Patio io by a  English English  ✓...

  • Page 5: Creation Of Pre-Pairing Channels (Optional)

    When the name is written, validate the text with a press on the checkbox with the Activation button. NOTICE If the name is too long (more than 20 characters), it appears shortened. © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 6 Do you have Do you have a new channel a new channel group which can now be controlled with Ysia Patio io. to configure? to configure?  12] The screen displays the question “Do you have a new channel to configure?”:...

  • Page 7: Creation Of Product Channels Or Group Channels

     Finish The channels are created and named: “Channel 1”, “Channel 2”,… ▪ By default, these channels are created as Venetian blind (in product type) and Autonomous Somfy (in type of motor). Channel 1 ..Channel 1 Then configure channels to match pre-paired motorised products: 5] Select “Channel 1”...
  • Page 8 NOTICE • To modify these settings, refer to Edit a channel in Channel settings, in 2.7. Settings menu. • The pictogram is linked to the product type and is not editable. © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.

  • Page 9: Pairing Already Set Products To A Product Channel Or A Group Channel

    • To program the first control point, refer to the instructions for the io drive or receiver. • If Ysia Patio io is the first control point, select the desired channel by scrolling the Variator and press on the Activation button to switch in control mode before pairing the product.

  • Page 10: Wall Mounting

    Ysia Patio io 2.6.Wall mounting CAUTION Even if Ysia Patio io is designed to pilot outdoor motorised products, it must be stored inside when not used, and therefore mounted indoors only. There are two possible ways of wall-mouting Ysia Patio io : 1] By fixing it with the provided screws.

  • Page 11: Settings Menu

    Automation manag... Automation manag... Delete a channel Delete a channel  Back Back Finish 2.7.1.1. New channel This menu allows to create a new Product channel or a new Group channel. © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.

  • Page 12: Edit A Channel

    This menu allows to modify an existing Product channel or Group channel. NOTICE The channel type (Product or Group) is not editable. If necessary, delete the channel and create a new channel of the desired type (Refer to 2.7.1.4. Delete a channel). © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 13 Activation button, the screen returns to the Edit menu of the channel. Change product Change product  Change name Change name Change the type of... Change the type of... Awning_ Awning _ Awning 1_ Awning 1_ © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.

  • Page 14: Automation Management

    In manual mode (M): the motorised product paired in this channel only responds to commands performed manually on Ysia Patio io, on other paired control points, automatisms or boxes. Orders sent automatically are inhibited in this mode (such as time programming, scene, smart programming, light sensor, etc…). Only so-called safety commands are still taken into account (e.g.

  • Page 15: Delete A Channel

    In case there are several control points that can change the mode: it is the last change that is taken into account. But if the change of mode is made by another control point, the display on the channel of Ysia Patio io is not refreshed.

  • Page 16: Remote Control Settings

    In manual mode: the user chooses an intensity of screen brightness that does not vary with ambient luminosity. Note that this setting may impact battery life. After battery replacement, this setting is retained but after a reset, Ysia Patio io returns to automatic mode (Refer to 2.7.2.3. Reset).
  • Page 17 • Check if the motorised products are paired to another control point because if a motorised product is only paired to Ysia Patio io, it cannot be unpaired. • Unpair all the motorised products from Ysia Patio io (Refer to 2.4.  Pairing already set products to a Product channel or a Group channel).

  • Page 18: Tips And Advice On Installation

    (refer to 3.6. Replacing the batteries). A battery pictogram appears at the top left of The control point batteries are low. Ysia Patio io can still be used the screen. normally before changing the batteries (refer to 3.6. Replacing the batteries).
  • Page 19 The type of pergola corresponding to the product is to be selected at the channel creation stage. To modify it, refer to Edit a channel in Channel settings, in 2.7. Settings menu. © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 20 - If the motorised product is being activated: briefly press my to stop the motorised product from activating. - If the motorised product is stopped: briefly press my to move the selected motorised product to its favourite position (my). © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 21 - Press the Up or Down button to switch on or switch off the light. - Scroll the Variator step by step to adjust the intensity of the light. - Briefly press my to go to the favourite intensity (my). © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 22 5] If the product is a “Heating” product: 2 types of heating products are available, so that the control mode is adapted to the ergonomics of the product: ▪ “On/Off” ▪ “Dimming” © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 23 (my). 7] If the product is a “Somfy plug”: - Press the Up or Down button to switch on or switch off the Somfy plug. 8] If the product is a “Solar Velux” or a “Velux”: 2 types of Velux products are available, so that the control mode is adapted to the ergonomics of the product: ▪...

  • Page 24: Saving, Modifying Or Deleting The Favorite Position (My)

    (my) is deleted. 3.3.Automatic/Manual mode management Ysia Patio io allows the user to select the mode for automatism management, channel by channel, only for Product channels. In automatic mode : the motorised product paired in this channel also responds to the automatisms, such as time programming, scene, smart programming, light sensor, etc...
  • Page 25 In manual mode (M): the motorised product paired in this channel only responds to commands performed manually on Ysia Patio io, on other paired control points, automatisms or boxes. Orders sent automatically are inhibited in this mode (such as time programming, scene, smart programming, light sensor, etc…). Only so-called safety commands are still taken into account (e.g.

  • Page 26: Screen Brightness

    3.6.Replacing the batteries NOTICE • When the battery level is low, a battery pictogram appears at the top left of the screen: Ysia Patio io can still be used normally but it is time to change the batteries. • When the batteries are worn out: Ysia Patio io no longer works: only a warning screen is displayed when it is awakened.

  • Page 27: Tips And Advice On Operation

    (refer to 3.6. Replacing the batteries). A battery pictogram appears at the top left of The control point batteries are low. Ysia Patio io can still be used the screen. normally before changing the batteries (refer to 3.6. Replacing the batteries).

  • Page 28: Technical Data

    The full text of the EU declaration of conformity is available at www.somfy.com/ce. Somfy limited, Yeadon LS19 7ZA UK, hereby declares that the radio equipment covered by these instructions is in compliance with the requirements of UK legislation: the Radio Equipment Regulations S.I. 2017 N°1206.
  • Page 29 © Copyright 2025 SOMFY ACTIVITES SA. All rights reserved.
  • Page 30 SOMFY ACTIVITES SA 50 avenue du Nouveau Monde 74300 CLUSES FRANCE www.somfy.com 5184245A...
