- Page 1 TMC PRO OWNER’S MANUAL WEBSITE MANUAL...
-
Page 2: Motorized Treadmill
MOTORIZED TREADMILL... - Page 3 WARNING ----When using this treadmill, keep attaching the safety key rope to your clothes. ----When you are running, keep your hands swinging naturally, your eyes staring frontward, and never look down at your feet. ----Increase the speed step by step when running. ----When emergency happens, take away the “safety key”...
-
Page 4: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS 1. Plug the power cord of the treadmill directly into a dedicated grounded circuit. This product must be grounded. If it has breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. 2. - Page 5 18. Put your feet on the side rail before using the treadmill, and always attach the safety pull pin rope to your clothing. Hold the handle bar before the running belt moving well (feel the running speed by your single foot before using it). To avoid loss balance, please slow down the speed to the lowest or take off the safety.
-
Page 6: Assembly Steps
ASSEMBLY STEPS S S T T E E P P 1 1 : : 1. Open the package, take out all parts and place the main frame on the flat ground. 2. Connect the controller wire (97) with the lower extension wire (98). 2L/R) 3. - Page 7 S S T T E E P P 2 2 : : 1. Connect the upper extension wire (96) with the extension wire (97). 2L/R 2. Fix the computer frame (3) to the left and right upright tube ( ) with hex socket screws (67&68) and lock washers (89&90).
- Page 8 S S T T E E P P 3 3 : : 1. Lock the front handlebar (7) to the computer frame (3) tightly with hex socket screws (69) and lock washers (90). 2. Install the A of the left upright cover (25a/b) and right upright cover (26a/b) into the B of the computer (3), as the picture shown.
-
Page 9: Grounding Methods
GROUNDING METHODS This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. - Page 10 170KG INCLINE -5%-40% USER’S WEIGHT Operation Instructions Speed : display speed data. Time: display time Dis.: display distance INC.: display incline Prog/cal: display program and calories PUL.: display heart rate Middle dot matrix: display the runway and the number of turns, 400 meet per turn. Data display range of various parameters: TIME: 0:00 –...
- Page 11 SPEED: 1.0 – 20.0(KM/H) PULSE: 50 – 200 (BPM) INCLINE: -5 – 40% NOTE： - - 5 5 % % - - 1 1 5 5 % % S S P P E E E E D D R R A A N N G G E E ： ： 1 1 - - 2 2 0 0 K K M M / / H H 1 1 6 6 % % - - 2 2 5 5 % % S S P P E E E E D D R R A A N N G G E E ：...
- Page 12 ⑩ ⑩ Kilometer transform with mile: take off the safety key, press PROGRAM and MODE for three seconds at the same time. ⑪ ⑪ Software version of the query: Press the SPEED+ and SPEED-, two buttons for 1 second during the standby state, you could inquiry the information of current software version.
- Page 13 SPEED INCLINE S S P P E E E E D D P P 1 1 1 1 I I N N C C L L I I N N E E S S P P E E E E D D P P 1 1 2 2 I I N N C C L L I I N N E E S S P P E E E E D D...
- Page 14 ≧ ≧ 30 =(25--29) Over weight Obesity 1.8. Parameters for 3 modes Countdown initial set time is 30:00 min., the range: 5:00 ---99:00 min., add step: 1:00min.; Countdown cal. Initial set is 50 Kcal, set range 20-990 Kcal, add step 10 Kcal; Countdown distance initial set is 1.0 Km, set range 1.0-99.0 Km, add step 1.0 Km;...
- Page 15 1.11. Meanings of error message codes: - 13 -...
-
Page 16: Exercise Instructions
EXERCISE INSTRUCTIONS 1. The Warm Up Phase This stage helps get the blood flowing around the body and the muscles working properly. It will also reduce the risk of cramp and muscle injury. It is advisable to do a few stretching exercises as shown below. -
Page 17: Maintenance Instructions
your speed to keep your heart rate in the target zone. The important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal. -
Page 18: Tensioning The Belt
TENSIONING THE BELT If you can feel a slipping sensation when running on the treadmill, the running belt must be tightened. In most cases, the belt has stretched from use, causing the belt to slip. This is a normal and common adjustment. -
Page 19: Walking Belt And Deck Lubrication
WALKING BELT AND DECK LUBRICATION This treadmill is equipped with a pre-lubricated, low maintenance deck system. The belt/ deck friction may play a major role in the function and life of your treadmill, thus requiring periodic lubrication. We recommend a periodic inspection of the deck. We recommend lubrication of the deck according to the following timetable: ... -
Page 20: Exploded Drawing
EXPLODED DRAWING PARTS LIST Part Description Description Hex socket screw M10*60 Main frame Hex socket screw M10*65 2L/R L/R upright tube 1 p.r. Hex socket screw M10*20 Computer frame Hex bolt M10*65 Incline frame Hex bolt M10*35 5L/R Incline connection board Hex bolt M10*47 Support bracket Hex bolt M10*45... - Page 21 Hex socket screw M8*15 Front roller Rear roller Hex socket screw M8*30 Spacer 1 Hex socket screw M6*20 Spacer 2 Hex nut M6*35 Spacer 3 Cross pan head screw M5*8 Cross pan head screw M5*15 Spacer 4 Cross pan head screw M5*20 Spindle Spring Cross pan head screw M5*25...
- Page 22 Foam grip 112 Amplifier board（optional） Non-slip mat 113 Connecting wire of MP3 Square end cap 1 114 Audio jack（optional） Square end cap 2 Audio socket (optional) socket screw Inductor bracket (optional) M10*120 socket screw 117 USB/SD card（optional） M10*80 socket screw M10*75 - 20 -...
- Page 23 BLUETOOTH FUNCTION Check the DKN-Technology website for more information about which apps the Treadmill is compatible with. Turn on Bluetooth function on your tablet or smartphone to connect it with the machine (pairing is not required). Download the app, open it on your device and follow the steps to set it up. For any technical questions on third party app functionality do consult the FAQ section on the specific app developper’s website.
-
Page 24: Warranty
WARRANTY DKN-Technology warrants this product to be free from defects in material at the time of the product’s tender of delivery. This ‘Carry-in’ Limited Warranty applies for a period of two (2) years, beginning on the date mentioned on your product invoice or proof of purchase of product issue by DKN-Technology. - Page 25 WEBSITE Make an Appointment to Visit our Showroom...
