Installer and user reference guide
Madoka wired remote controller
BRC1HF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Madoka and is the answer not in the manual?

Questions and answers

Related Manuals for Daikin Madoka

Summary of Contents for Daikin Madoka

  • Page 1 Installer and user reference guide Madoka wired remote controller BRC1HF...

  • Page 2: Table Of Contents

    Closing the controller ..............................10.4.1 To close the controller........................... 10.5 Opening the controller..............................10.5.1 Precautions when opening the controller..................... 10.5.2 To open the controller........................... 11 Starting up the system Installer and user reference guide BRC1HF Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 3 Energy saving ..............................15.5.5 Scheduling..............................15.5.6 Configuration and operation ......................... 15.5.7 Maintenance ..............................16 Maintenance 16.1 Maintenance safety precautions ........................... 16.2 About maintenance................................ 16.3 To remove a warning screen............................BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 4 18 Technical data 18.1 Connection diagram ............................... 18.1.1 Typical layout ..............................18.1.2 Typical layout for group control ........................18.1.3 Controller + DIII central control equipment....................19 Glossary Installer and user reference guide BRC1HF Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 5: About The Documentation

    The controller only allows for basic settings and operation. Advanced settings and operation are performed via the Madoka Assistant app. For more information, see the app and its in-app documentation. The Madoka Assistant app is available from Google Play and the Apple Store.

  • Page 6: Meaning Of Warnings And Symbols

    Indicates a situation that could result in equipment or property damage. INFORMATION Indicates useful tips or additional information. DANGER: RISK OF EXPLOSION Indicates a situation that could result in explosion. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 7: General Safety Precautions

    WARNING Improper installation or attachment of equipment or accessories could result in electrical shock, short-circuit, leaks, fire or other damage to the equipment. ONLY use accessories, optional equipment and spare parts made or approved by Daikin unless otherwise specified. WARNING All field wiring and components MUST be installed by a licensed electrician and MUST comply with the applicable legislation.

  • Page 8: For The User

    Contact your dealer. WARNING Do NOT play with the unit or its remote controller. Accidental operation by a child may result in impairment of bodily functions and harm health. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 9: Specific Installer Safety Instructions

    Possible consequence: electrical shock or injury. WARNING Do NOT wash the remote controller. Possible consequence: electric leakage, electrical shock, or fire. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 10: For The User

    For the user BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 11: Remote Controller: Overview

    Madoka Assistant app. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and use of such marks by Daikin Europe N.V. is under license. Other trademarks and trade names are those of their respective owners. BRC1HF...

  • Page 12: Status Indicator

    For information on the operation mode icons, see "5.3 Operation mode" [  17]. ▪ Most icons are related to things set in the Madoka Assistant app. For more information, see the app, and the installer and user reference guide. 4.3 Status indicator BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 –...
  • Page 13 Remote controller: Overview a Status indicator BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 14: Operation

     78] (app settings). 5.1.2 To set date and time 1 Navigate to the date and time menu. 2 Press to activate Result: The fields become editable. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 15: Basic Usage

    The remote controller does NOT display negative indoor temperature values. When the indoor temperature is below 0°C, then the remote controller displays 0°C instead. In this case, the Madoka Assistant app also does not display any indoor temperature value. Home screen operation In certain conditions, the controller allows you to perform actions from the home screen.

  • Page 16: Main Menu

    ▪ The controller only allows for basic operation of the system. For advanced operation (setback, schedule timer, …), see the Madoka Assistant app. BRC1HF Installer and user reference guide Madoka wired remote controller...

  • Page 17: Operation Mode

    It is possible that menus are locked. When this is the case, they appear crossed-out in the main menu, and get accompanied by a lock icon. The locking of functions happens through the Madoka Assistant app. For more information, see the Madoka Assistant app and "Function...

  • Page 18: About The Operation Modes

    When operation modes are not available in the operation mode menu, it is additionally possible that they are locked. The locking of operation modes occurs through the Madoka Assistant app. For more information, see the Madoka Assistant app and "Function lock" [...

  • Page 19: To Set The Operation Mode

    The setpoint is the target temperature for the Cooling, Heating, and Auto operation modes. 5.4.1 About the setpoint Depending on configuration, the home screen displays the temperature setpoint either as a numerical value, or as a symbol. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 20 Operation INFORMATION For how to set the home screen setpoint, see the Madoka Assistant app. Also see "Screen" [  76]. Home screen setpoint: Numerical In case the home screen displays the temperature setpoint as a numerical value, you control the room temperature by raising or lowering the setpoint by 1°C increments.

  • Page 21: To Set The Setpoint

    21°C 5.4.2 To set the setpoint Prerequisite: The active operation mode is either 'Cooling', 'Heating', or 'Auto'. 1 In the home screen, use to adjust the setpoint. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 22: Airflow

    When the room temperature is higher than the controller's setpoint for Heating operation (including Auto operation). To set the airflow direction 1 Navigate to the airflow direction menu. 2 Use to adjust the airflow direction. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 23: Fan Speed

    The controller only allows for basic operation. For advanced operation, use the Madoka Assistant app. INFORMATION To operate the controller with the app, you need to connect the controller to a mobile device which installed. instructions, "15.2 Pairing" [  68]. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 24: Maintenance And Service

    The following warning screens are related to indoor unit maintenance: Clean the indoor unit filter Replace the indoor unit filter Empty the indoor unit dustbox — BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 25: Troubleshooting

    Error screen (example) BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 26: For The Installer

    For the installer BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 27: About The Box

    8.1 To unpack the controller 1 Open the box. 2 Separate the accessories. 1× 2× a Installation and operation manual b Wood screws + wall plugs (Ø4.0×30) BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 28: Preparation

    (L), according to the figure and the table. 2 Keep a 10 mm distance between the length of the 2 wires. 10 mm Wiring outlet ±150 mm Left ±120 mm Bottom ±100 mm Rear No requirements BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 29: Installation

    The wiring can be routed from the top, the rear, the left, or the bottom. Remove a piece of the rear casing according to the illustration: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 30: To Mount The Controller

    When mounting the rear casing to a flush-mounted electrical installation box inside a wall, make sure that that wall is completely flat. NOTICE Be careful not to deform the rear casing by overtightening the mounting screws. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 31: Connecting The Electrical Wiring

    (external noise). INFORMATION P1 and P2 have no polarity. 10.3.2 To connect the electrical wiring Connect controller terminals P1/P2 to indoor unit terminals P1/P2. From the top P1P2 BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 32: Closing The Controller

    To prevent damage, make sure the front of the controller is clicked into the rear casing securely. 10.4.1 To close the controller 1 Click the front of the controller into the rear casing. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 33: Opening The Controller

    NOTICE When the front and rear casing are separated, make sure the PCB does not come into contact with dust or moisture. 10.5.2 To open the controller BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 34: Starting Up The System

    INFORMATION For master and slave controllers to function together, they need to have the same value for the "Home screen setpoint" setting (Madoka Assistant app setting), i.e. all set to "Numerical" or all set to "Symbolic". 11.2 To designate a controller as slave Prerequisite: A master controller is already connected to the indoor unit.
  • Page 35 3 When the U5 or U8 error appears, press and keep it pressed until "2" appears on the screen. Result: The controller is now designated as slave. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 36: Remote Controller: Overview

    Madoka Assistant app. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and use of such marks by Daikin Europe N.V. is under license. Other trademarks and trade names are those of their respective owners. BRC1HF...

  • Page 37: Status Indicator

    For information on the operation mode icons, see "13.2 Operation mode" [  42]. ▪ Most icons are related to things set in the Madoka Assistant app. For more information, see the app, and the installer and user reference guide. 12.3 Status indicator BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 –...

  • Page 38: Behaviour

    Blinking Blinking unit INFORMATION Remote controller field setting R1-11 allows for changes to the behaviour of the status indicator, making the controller suitable for use in hotels. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 39: Operation

    For instructions on how to set screen brightness and contrast when the backlight is ON, see "14.1.2 Screen settings" [  52]. To turn ON the backlight 1 Press shortly. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 40: Home Screen

    The remote controller does NOT display negative indoor temperature values. When the indoor temperature is below 0°C, then the remote controller displays 0°C instead. In this case, the Madoka Assistant app also does not display any indoor temperature value. Home screen operation In certain conditions, the controller allows you to perform actions from the home screen.

  • Page 41: Main Menu

    13.1.4 Main menu From the home screen, press to enter the main menu. Use to cycle through the menus. Press again to enter one of the menus. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 42: Operation Mode

    It is possible that menus are locked. When this is the case, they appear crossed-out in the main menu, and get accompanied by a lock icon. The locking of functions happens through the Madoka Assistant app. For more information, see the Madoka Assistant app and "Function...

  • Page 43: About The Operation Modes

    To access the operation mode menu and change the operation mode, the function lock must first be released. The locking and releasing of functions happens through the Madoka Assistant app. For more information, see "Function...

  • Page 44: To Set The Operation Mode

    During Fan only operation, the indoor unit circulates air without heating or cooling. 13.2.2 To set the operation mode Prerequisite: The operation mode menu function lock is released. 1 Navigate to the operation mode menu. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 45: Setpoint

    Depending on configuration, the home screen displays the temperature setpoint either as a numerical value, or as a symbol. INFORMATION For how to set the home screen setpoint, see the Madoka Assistant app. Also see "Screen" [  76]. Home screen setpoint: Numerical In case the home screen displays the temperature setpoint as a numerical value, you control the room temperature by raising or lowering the setpoint by 1°C...
  • Page 46 28°C and lower it to 22°C. 28°C +3°C 25°C -3°C 22°C INFORMATION For how to set the reference setpoint, see the Madoka Assistant app. Also see "Screen" [  76]. Exceptions to this logic are possible in case of: ▪ Setpoint range limitations ▪...

  • Page 47: To Set The Setpoint

    Set the date and time for the indoor units connected to the controller. 13.4.1 About date and time Depending on daylight saving time settings, the date and time menu has the following daylight saving time indicators: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 48: To Set Date And Time

    13.5.1 Airflow direction The airflow direction is the direction in which the indoor unit blows its air. About airflow direction The following airflow directions can be set: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 49: Fan Speed

    The fan speed is the strength of the airflow coming out of the indoor unit. About fan speed Depending on the indoor unit, you can choose between either: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 50: Advanced Usage

    The controller only allows for basic operation. For advanced operation, use the Madoka Assistant app. INFORMATION To operate the controller with the app, you need to connect the controller to a mobile device which installed. instructions, "15.2 Pairing" [  68]. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 51: Configuration

    Force fan ON Cooling/Heating masterhood Information To enter the installer menu Prerequisite: The controller displays the home screen. 1 Press and keep it pressed until the information screen appears: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 52: Screen Settings

    Result: The screen adjusts its brightness and the controller returns to the installer menu. To set screen contrast Prerequisite: You are in the installer menu. 1 Navigate to the screen contrast menu. 2 Use to adjust screen contrast. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 53: Status Indicator Settings

    The controller allows for making field settings related to the indoor unit, and to the controller itself. Screen Field settings Indoor unit Remote controller In both cases, the setting procedure is the same. For instructions, see "Setting procedure" [  54]. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 54 When making field settings for grouped units, you do NOT set the unit number. The settings will then apply to all indoor units that are part of that group. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 55 , and 1 Use to move the highlighter. 2 Press to select a field setting component. 3 Use to change the value of that field setting component. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 56 6 In the second level, navigate and select in the same way as you did in the first level. 7 Select to confirm and activate made settings. SW 00 8 At all times, select to go back a level. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 57 Field settings that are not available for a connected indoor unit are not displayed. ▪ Field setting default values are different depending on the indoor unit model. For more information, see the service manual of the indoor units. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 58 Remote controller field settings INFORMATION Remote controller field setting R1-11 allows for changes to the behaviour of the status indicator, making the controller suitable for use in hotels. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 59 4: 4%, 5: 5%, Status indicator mode 0: Normal 1: Hotel setting 1 2: Hotel setting 2 Bluetooth Low Energy 0: Always advertising advertising 1: Enable manually BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 60: Miscellaneous Settings

    To assign an address to a group of indoor units Prerequisite: You are in the installer menu. 1 Navigate to the address settings menu. 2 Select "Group" 3 Confirm your selection. 4 Define the address. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 61 3 Define the indoor unit to which you want to assign the address. 4 Confirm your selection. 5 Define the address. 6 Before you confirm the address, make sure is selected. 7 Confirm the address. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 62 3 Select and press to force fan operation. Result: The fan of the indoor unit that corresponds to the selected indoor unit number starts operating. Cooling/Heating masterhood BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 63 "To set Cooling/Heating masterhood" [  64]. Status icon Cooling/Heating masterhood corresponds to the following status icon: The behaviour of this status icon is according to the following table: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 64 About the information menu In the information menu, you can see the following information: Information Description Controller software ID Controller software version Time UE878 software ID --:--:--:--:--:--: UE878 MAC address BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 65: Software Update

     66] INFORMATION ▪ When the software of a controller is out-of-date, the Madoka Assistant app will suggest a software update for that controller as soon as you try to connect it (the controller) to the app. ▪ Checking the current controller software version is possible from the information screen (see "13.1.3 ...

  • Page 66: Software Update With Updating Tool

    Configuration INFORMATION The Madoka Assistant app is available from Google Play and the App Store. INFORMATION When it is the first time you connect a remote controller to your device, app and user interface initiate a numeric comparison procedure. To successfully connect the controller to the app, follow the procedure.
  • Page 67 5 In Updater, go to "Update procedure". 6 Type in the model name of the controller. 7 Select the desired update procedure. 8 Follow the on-screen instructions. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 68: About The App

    About the app 15 About the app The Madoka Assistant app is a companion to the remote controller. Where the controller only allows for basic operation and configuration, the app offers advanced operation and configuration functionality. In this chapter 15.1 Operation and configuration overview ..........................

  • Page 69: To Pair The App With A Controller

    15.2.3 To make a Bluetooth connection Prerequisite: You have a mobile device on which the Madoka Assistant app is installed and running. Prerequisite: On that mobile device, Bluetooth is turned ON.

  • Page 70: To Terminate The Bluetooth Connection

    About the app Numeric comparison 5 In the Madoka Assistant app, tap the tile of the controller of which you want to update the software. Result: If it is the first time you make a connection, or when bonding information was removed, the operating system of your mobile device sends out a pairing request, including a numeric string.

  • Page 71: To Remove Bonding Information

    When you first install the app, this mode is enabled by default. To change to a different mode, see "15.3.3  Advanced mode" [  72] or "15.3.4 Installer mode" [  72]. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 72: Advanced Mode

    1 Go to the main menu. 2 Tap "About". 3 Tap "Application version" five times. Result: You are in the installer mode menu. Result: Installer mode is automatically activated. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 73: Demo Mode

    To try out the app's operation and configuration functions in a safe environment, it is possible to launch a demo version of the app. 15.4.2 To launch demo mode Prerequisite: You are not in demo mode. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 74: To Exit Demo Mode

    Operation Turn ON/OFF unit operation Read out temperature sensor information Change the operation mode Change the setpoint Change the fan speed Change the airflow direction See notifications BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 75: Maintenance

    Available in advanced or installer mode only. For more information, see "15.3.3 Advanced mode" [  72] and "15.3.4 Installer mode" [  72]. Available in installer mode only. For more information, see "15.3.4 Installer mode" [  72]. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 76: General

    For instructions on how to change a controller's master/slave status, see "11  Starting up the system" [  34]. Screen Make remote controller screen settings: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 77 The remote controller does NOT display negative indoor temperature values. When the indoor temperature is below 0°C, then the remote controller displays 0°C instead. In this case, the Madoka Assistant app also does not display any indoor temperature value. Status indicator...

  • Page 78: Energy Saving

    5 timed actions for each day of the week. It is possible to create up to 3 different schedules, though only 1 schedule can be active at the same time. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 79 The holiday function can be enabled or disabled. When enabled, it applies to any schedule that is set to be active. INFORMATION For more information, see "Schedule" [  78]. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 80: Configuration And Operation

    When Setback is active and the "Home screen setpoint" setting is set to "Symbolic", then there is no indication of Setback operation on the remote controller home screen. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 81 Make functions and operation modes unavailable by locking them, or release a function lock if it is no longer required. It is possible to lock the following functions and operation modes: Remote controller ▪ Menu button BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 82 When locking operation modes, the controller simply omits them from the operation mode menu. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 83: Maintenance

    To use this function, it is required that you use the app in installer mode. For instructions on how to activate installer mode, see "15.3.4 Installer mode" [  72]. Contact information Enter the phone number of the system's service contact. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 84 Define the setting by tapping the right tile in the app. In the field settings table, find settings in the SW column. ▪ Define a value for that setting. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 85 ▪ Connection of electrical wiring. Typical workflow Performing a test operation typically consists of the following stages: Activating the test operation (Madoka Assistant app), Testing the indoor unit functions according to the instructions set out in "To perform a test operation" [...
  • Page 86 This can be due to the expansion valve (or the like) blocking the refrigerant, and does not obstruct the test run. 2 Open the Madoka Assistant app. 3 Navigate to the operation screen of the controller that is connected to the indoor unit(s) on which you want to perform a test run.
  • Page 87 The information retrieval function is only present in the menu when you use the app in installer mode. For instructions on how to activate installer mode, see "15.3.4 Installer mode" [  72]. Operating hours Monitor indoor and outdoor unit operating hours. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 88: Maintenance

    Go to the warning screen to see which component needs maintenance, perform the maintenance, and remove the warning screen. The following warning screens are related to indoor unit maintenance: BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...
  • Page 89 2 Press and keep it pressed. Result: The controller displays the information screen. 3 Press and keep it pressed. Result: The controller displays the warning screen. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 90: Brc1Hf

    Prerequisite: On trying to enter the main menu from the home screen, you are confronted with the 'Time to clean filter' screen. 1 Clean the filter. 2 Press to remove the 'Time to clean filter' indication. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 91: Troubleshooting

    2 Press and keep it pressed. Result: The controller displays the information screen. 3 Press and keep it pressed. Result: The controller displays the error screen. BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 92: Technical Data

    Technical data 18 Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of the latest technical data is available on the Daikin Business Portal (authentication required). 18.1 Connection diagram 18.1.1 Typical layout...

  • Page 93: Controller + Diii Central Control Equipment

    Technical data 18.1.3 Controller + DIII central control equipment F1 F2 P1 P2 P1 P2 F1 F2 BRC1HF Installer and user reference guide Madoka wired remote controller 4P771765-1 – 2024.05...

  • Page 94: Glossary

    Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
  • Page 96 4P771765-1 2024.05...
