- Page 1 Installation and operation manual Madoka wired remote controller Installation and operation manual English Madoka wired remote controller BRC1HF...
-
Page 2: General Safety Precautions
ONLY use 8 Preparation accessories, optional equipment and spare parts made or Wiring requirements ..............approved by Daikin unless otherwise specified. 9 Installation WARNING Mounting the controller .............. All field wiring and components MUST be installed by a 9.1.1... -
Page 3: About This Document
BRC1H is in compliance with the Directive 2014/53/EU. The original declaration of conformity is Do NOT use flammable materials (e.g. available from the BRC1H product pages. hairspray or insecticide) near the The documentation set is available from the BRC1HF product controller. pages. BRC1HF WARNING To prevent electric shocks or fire: ▪... -
Page 4: For The User
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and use of such marks by Daikin Europe N.V. is under license. Other trademarks and trade names are those of their respective owners. -
Page 5: Basic Usage
Result: The indoor unit changes its operation mode and the controller returns to the home screen. Setpoint The setpoint is the target temperature for the Cooling, Heating, and Auto operation modes. BRC1HF Installation and operation manual Madoka wired remote controller 4P771932-1 – 2024.05... -
Page 6: Date And Time
The airflow direction is the direction in which the indoor unit blows its air. INFORMATION For more information, see the installer and user reference guide. To set the airflow direction 1 Navigate to the airflow direction menu. Installation and operation manual BRC1HF Madoka wired remote controller 4P771932-1 – 2024.05... -
Page 7: Troubleshooting
Wiring requirements All wiring must comply with the following requirements: Wire specification Value Type Sheathed vinyl cord or cable (2 wires) Section 0.75~1.25 mm Maximum length 500 m BRC1HF Installation and operation manual Madoka wired remote controller 4P771932-1 – 2024.05... -
Page 8: Connecting The Electrical Wiring
When closing the controller, be careful not to pinch the wiring. NOTICE To prevent damage, make sure the front of the controller is clicked into the rear casing securely. Installation and operation manual BRC1HF Madoka wired remote controller 4P771932-1 – 2024.05... -
Page 9: Starting Up The System
Afterwards, wipe dry with a dry cloth. 11.2 To clean the controller 1 Wipe the screen and other surface parts of the controller with a dry cloth. BRC1HF Installation and operation manual Madoka wired remote controller 4P771932-1 – 2024.05... - Page 12 4P771932-1 2024.05...
